Target Audience:
DIY enthusiasts, home mechanics, professional technicians, restoration specialists.
Value Proposition:
Provides professional-level repair and maintenance information at a fraction of the cost of dealer service or multiple specialized manuals.
Content Highlights:
Part layouts, wiring schematics, part numbers, troubleshooting guides, step-by-step instructions, comprehensive coverage.
Accessibility:
Instant download, usable on multiple devices, no physical shipping.
Engine:
Detailed diagnostics, repair, overhaul, and tune-up procedures for all engine variants.
Transmission:
Service, repair, and overhaul procedures for automatic transmission.
Electrical:
Comprehensive wiring diagrams, troubleshooting guides, component testing, and repair for all electrical systems.
Suspension Steering:
Diagnosis, repair, and component replacement for suspension, steering systems, and alignment procedures.
Brakes:
Service, overhaul, and troubleshooting of ABS systems, brake components, and fluid replacement.
Cooling Heating Ac:
Repair and maintenance of the cooling system, heating, ventilation, and air conditioning (HVAC) systems.
Fuel Exhaust:
Service and repair of the fuel delivery system, emissions control, and exhaust systems.
Body Chassis:
Information on body panel repair, structural components, and chassis maintenance.
Routine Maintenance:
Oil changes, filter replacements, fluid checks, belt tensioning, spark plug replacement, lubrication.
Troubleshooting:
Diagnostic procedures for common and uncommon issues, fault code interpretation, symptom-based troubleshooting.
Engine Repair:
Detailed steps for engine disassembly, component replacement (pistons, valves, bearings), reassembly, and tuning.
Transmission Service:
Fluid and filter changes, seal replacements, valve body diagnosis, and transmission overhaul.
Electrical Diagnostics:
Testing circuits, diagnosing electrical faults, replacing sensors, actuators, and control modules.
Brake System Repair:
Calibrating ABS, replacing brake pads, rotors, lines, and flushing brake fluid.
Restoration Rebuild:
Guidance for complete vehicle restoration and component rebuilding.
Diagnostic Capabilities:
Advanced diagnostic procedures, including component testing and electrical schematic interpretation.
Rebuild Instructions:
Comprehensive instructions for engine, transmission, and major component rebuilding.
Factory Procedures:
Details factory-recommended procedures and specifications for all repairs.
Secondary Formats:
ZIP, RAR (for potentially large files)
Compatibility:
Windows, macOS, Linux (via PDF reader), iPad
Searchability:
Likely searchable text within PDF (depending on original scan quality)
Printability:
Printable on any computer and printer
Illustration Quality:
Illustrated with clear step-by-step instructions, zoomable illustrations, component explosions, exploded views.
Binding:
Not Applicable (Digital Download)
Paper:
Not Applicable (Digital Download)
Maximum Size:
Up to 4000 MB (suggests very comprehensive content)
Engine Options 1996:
4.0L AJ6 Inline-6 (AJ6), 6.0L V12 (V12)
Inline 6 Power:
Approx. 237 hp (177 kW; 240 PS) @ 5000 rpm
Inline 6 Torque:
Approx. 284 lb-ft (385 Nm) @ 3600 rpm
V12 Power:
Approx. 318 hp (237 kW; 322 PS) @ 5300 rpm
V12 Torque:
Approx. 369 lb-ft (500 Nm) @ 3800 rpm
Injection System:
Electronic Fuel Injection (EFI) for both engines.
Wheelbase:
Coupe: 102.4 in (2601 mm) / Convertible: 100.1 in (2543 mm)
Length:
Coupe: 195.7 in (4971 mm) / Convertible: 189.6 in (4816 mm)
Height:
Coupe: 50.7 in (1288 mm) / Convertible: 50.0 in (1270 mm)
Curb Weight Inline 6:
Approx. 3,700 - 3,900 lbs (1678 - 1769 kg)
Curb Weight V12:
Approx. 4,000 - 4,200 lbs (1814 - 1905 kg)
Gvw:
Varies by model and engine
Crash Test Data:
Limited public crash test data available for 1996 models, but equipped with standard safety features of the era.
ABS:
Standard Anti-lock Braking System (ABS).
Traction Control:
Optional or standard depending on engine/trim (Traction Control System - TCS).
Airbags:
Driver and passenger front airbags.
Seat Belts:
Three-point front and rear seat belts.
Audio System:
Factory-fitted premium audio system (e.g., Clarion, Alpine) with cassette and/or CD player.
Climate Control:
Automatic climate control (climate control system operation and repair covered).
Cruise Control:
Standard cruise control system.
Early Systems:
Limited by modern standards, focus is on mechanical and electrical systems.
Oil Change Interval:
Typically every 5,000-7,500 miles (8,000-12,000 km) or 12 months, whichever comes first (refer to manual for specifics).
Coolant Flush:
Every 2-3 years or 30,000 miles (48,000 km).
Transmission Fluid:
Check fluid level regularly, change fluid and filter per manual recommendation (often 50,000-70,000 miles).
Engine Oil Recommendation:
Refer to manual for specific API service classification and viscosity grade (e.g., 10W-40, 15W-50 depending on climate).
Transmission Fluid Type:
Jaguar Specification JLM 20272, or equivalent (e.g., Dexron III for ZF 4HP22).
Coolant Type:
Ethylene glycol-based coolant with corrosion inhibitors (e.g., Jaguar recommended coolant or equivalent).
Common Faults:
Jaguar XJS models can be prone to electrical gremlins, aging rubber components (bushings, hoses), fuel injector issues, and potential head gasket leaks on the V12, though these were improved by 1996. The manual will provide detailed diagnosis for these.
Jaguar Legacy:
Jaguar has a long history of producing luxury grand tourers with a focus on performance, comfort, and style.
Xjs Lifecycle:
Introduced in 1975, the XJS was developed to replace the iconic E-Type. The 1996 model represents the final year of production, featuring significant updates and refinements from earlier models, including chassis revisions and engine improvements.
Production End Year:
1996
Manufacturing Location:
Coventry, England
