Jeep Commander XK 2006-2010 OEM Factory Shop Service Repair Manual

Regular price: $17.99
Sale price: $17.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Jeep Model: Commander Model Code: XK Model Years Covered: 2006, 2007, 2008, 2009, 2010 Generation Generation Code: XK Generation Years: 2006-2010 👋 Introduction Market Position...

23 people are viewing this right now

Type: Car

Vendor:

Sku: 349723

Tags: 2006 2007 2008 2009 2010 Car Cars Commander (XK) Featured Jeep

Product variants

Description

🏷️ Basic Information

Identification

Make:

Model:

Commander

Model Code:

Model Years Covered:

2006, 2007, 2008, 2009, 2010

Generation

Generation Code:

Generation Years:

2006-2010

👋 Introduction

Market Position

Vehicle Segment:

Mid-size SUV (Sport Utility Vehicle), often categorized as a 'Compact/Mid-size' based on platform sharing

Jeep Lineup Placement:

Positioned as a family-oriented, three-row SUV alternative within the Jeep lineup, distinct from the more rugged, off-road focused models like the Wrangler.

Competitive Analysis

Key Competitors:

Ford Explorer, Toyota Highlander, Honda Pilot, Chevrolet TrailBlazer, Nissan Pathfinder

Unique Selling Proposition:

Jeep's brand recognition for capability and durability, combined with a comfortable and practical family SUV package, though it lacked the extreme off-road prowess of other Jeeps.

Key Features

Body Style:

Two-box, four-door SUV with an optional third-row seat

Platform Sharing:

Shares platform components with the Dodge Nitro and Jeep Liberty (KJ), with a longer wheelbase for the three-row seating.

📋 Manual Details

Coverage Areas

Coverage Scope:

Bumper-to-bumper

Version Coverage:

All versions

Page Count

Estimated Page Count:

Extensive (specific count not provided, but described as comprehensive)

Manual Type

Type:

Factory Shop Service Repair Manual

Language

Language:

English

Format

File Format:

Software Dependency:

None (self-contained PDF)

Internet Requirement:

No internet access required

📖 Manual Coverage

Systems Covered

Powertrain:

Engine, Transmission, Drivetrain (including 4WD systems)

Chassis:

Suspension, Steering, Brakes, Wheels, Tires

Electrical:

Body Electrical, Powertrain Electrical, Lighting, Instrumentation, HVAC Electronics

Body:

Body panels, Interior trim, Doors, Windows, Seating

HVAC:

Heating, Ventilation, and Air Conditioning system

Restraints:

Airbag system, Seat belts

Procedures Included

Maintenance:

Routine maintenance, Tune-ups, Fluid changes, Filter replacements

Repair:

Engine disassembly and reassembly, Transmission repair, Brake servicing, Suspension component replacement, Electrical system diagnosis and repair

Diagnostics:

Troubleshooting guides, Diagnostic trouble codes (DTCs), Symptom-based diagnostics

Specifications:

Torque values, Clearances, Fluid capacities, Diagnostic parameters

Installation:

Component installation and removal procedures

Technical Depth

Depth:

Comprehensive (from basic maintenance to major component overhaul)

Audience:

Professional technicians and DIY enthusiasts with basic mechanical knowledge

📊 Manual Specifications

File Format

File Type:

Searchability:

Searchable text

Interactivity:

Index included

Print Quality

Readability:

Accurate, clear, and concise text with illustrations

Visuals:

Comprehensive diagrams and in-depth illustrations

Binding Type

Binding:

Digital (PDF)

Paper Type

Paper:

N/A (Digital)

Compatibility

Operating Systems:

Windows (95-98-ME-XP-7), MAC, iPhone, iPad, iPod, LINUX

⚙️ Engine Specifications

Primary Engine

Engine Option 1 Displacement:

3.7 L (3701 cc)

Engine Option 1 Cylinders:

Engine Option 1 Architecture:

Engine Option 1 Horsepower:

Approx. 210-215 hp @ 5200 rpm (varies by year)

Engine Option 1 Torque:

Approx. 235-240 lb-ft @ 4000 rpm (varies by year)

Engine Option 1 Fuel Delivery:

Sequential Multi-Port Fuel Injection (MPI)

Engine Option 1 Block Material:

Engine Option 1 Head Material:

Aluminum

Optional Engine

Engine Option 2 Displacement:

5.7 L (5654 cc)

Engine Option 2 Cylinders:

V8 (HEMI)

Engine Option 2 Architecture:

OHV (HEMI design)

Engine Option 2 Horsepower:

Approx. 330-350 hp @ 5000-5200 rpm (varies by year)

Engine Option 2 Torque:

Approx. 370-375 lb-ft @ 4000 rpm (varies by year)

Engine Option 2 Fuel Delivery:

Multi-Displacement System (MDS) with Sequential MPI

Engine Option 2 Block Material:

Engine Option 2 Head Material:

Aluminum

🔧 Transmission

Standard

Transmission Type Standard:

4-speed Automatic Transmission (42RLE)

Optional

Transmission Type Optional:

5-speed Automatic Transmission (5-45RFE for 5.7L HEMI models)

Features

Drivetrain Options:

Rear-Wheel Drive (RWD), Full-time 4-Wheel Drive (4WD) with various configurations (e.g., Selec-Trac II, NV245 transfer case)

Transmission Fluid Spec:

Refer to manual for specific ATF specification (e.g., ATF+4 or equivalent for 42RLE, specific fluid for 5-45RFE)

📐 Dimensions

Exterior

Wheelbase:

Approx. 116.1 inches (2950 mm)

Length:

Approx. 192.5 inches (4890 mm)

Width:

Approx. 72.4 inches (1839 mm)

Height:

Approx. 67.9 inches (1725 mm)

Cargo

Cargo Volume Behind 2Nd Row:

Approx. 39.0 cubic feet

Cargo Volume Behind 1St Row:

Approx. 69.0 cubic feet

Weights

Curb Weight Min:

Approx. 4,300 lbs (1950 kg) for 3.7L RWD

Curb Weight Max:

Approx. 4,800 lbs (2177 kg) for 5.7L 4WD

Towing Capacity:

Up to 3,500 lbs (1588 kg) with standard towing package, up to 6,500 lbs (2948 kg) with optional heavy-duty towing package (engine dependent).

Wheel Bolt Pattern:

5x114.3 mm (5x4.5 inches)

Wheel Size Standard:

17-inch

Tire Size Standard:

P245/65R17 (varies by trim and options)

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

Good (2007 model year)

NHTSA Front Impact Passenger:

Good (2007 model year)

NHTSA Side Impact Front Seat:

Good (2007 model year)

NHTSA Side Impact Rear Seat:

Good (2007 model year)

IIHS Front Offset:

Good (2007 model year)

IIHS Side Impact:

Good (2007 model year)

Active Features

Traction Control:

Standard on most models (Electronic Traction Control)

Stability Control:

Standard Electronic Stability Control (ESC) with Roll Mitigation

Antilock Brakes:

Standard Anti-lock Braking System (ABS)

Passive Features

Airbags Front:

Standard advanced multi-stage front airbags

Airbags Side:

Optional or standard supplemental side-curtain airbags for front and third-row occupants (coverage varies by year and trim)

Seatbelts:

3-point seat belts with pretensioners for all seating positions

💡 Technology Features

Infotainment

Infotainment System:

Uconnect infotainment system with touch screen, navigation, and entertainment options available on higher trims or as an upgrade.

Audio System:

Available premium Boston Acoustics audio system with multiple speakers, subwoofer, and amplifier.

Connectivity Options:

Auxiliary audio input, optional SiriusXM Satellite Radio, optional Bluetooth hands-free communication.

Driver Assistance

Parking Assistance:

Optional rear park assist sensors.

Cruise Control:

Standard cruise control.

Remote Start:

Optional remote keyless entry and remote start system.

🔧 Maintenance

Service Intervals

Oil Change Interval Gasoline:

Every 3,000-6,000 miles or 3-6 months, depending on driving conditions and oil type (refer to manual for exact recommendation and oil specification).

Engine Air Filter Replacement:

Every 15,000-30,000 miles or as needed based on inspection.

Cabin Air Filter Replacement:

Every 15,000-30,000 miles or annually.

Spark Plug Replacement 3.7L:

Approximately 100,000 miles (check specific spark plug type recommended in manual).

Transmission Fluid Change:

Every 30,000-60,000 miles, depending on driving conditions (refer to manual for specific fluid and interval).

Coolant Flush:

Every 30,000-60,000 miles or 2-4 years (check manual for coolant type and interval).

Fluid Specifications

Engine Oil 3.7L:

SAE 5W-30, API SN/SM or equivalent (refer to manual for exact specification and capacity).

Engine Oil 5.7L:

SAE 5W-20 (for MDS models), SAE 5W-30 (for non-MDS), API SN/SM or equivalent (refer to manual for exact specification and capacity).

Coolant Type:

Mopar OAT (Organic Additive Technology) Antifreeze/Coolant, HOAT (Hybrid Organic Additive Technology) or equivalent (refer to manual for specific color and type).

Known Issues

Engine Common Issues:

Coolant leaks from the water pump and thermostat housing, oil filter housing leaks, occasional valve cover gasket leaks.

Transmission Common Issues:

Occasional rough shifting or delayed engagement with the 42RLE transmission. Transmission fluid cooler line leaks can occur.

Suspension Common Issues:

Worn front suspension components (ball joints, control arm bushings), especially with higher mileage. RWD models may experience driveshaft vibrations.

Electrical Common Issues:

Power window regulator failures, HVAC blower motor resistor issues, occasional ABS/ESP warning lights due to wheel speed sensor failures.

Brake Wear:

Front brake pads and rotors can wear relatively quickly depending on driving style and load.

📚 Vehicle History

Brand Heritage

Jeep Legacy:

Jeep, a brand with a long history of producing rugged and capable vehicles, particularly known for its military origins and off-road prowess.

Model Evolution

Commander Introduction:

Introduced for the 2006 model year as Jeep's first three-row SUV, aimed at expanding the brand's appeal to families.

Design Influences:

Boxy, upright styling reminiscent of classic Jeep Wagoneers, with a premium interior focus for its segment.

Facelift:

Received minor updates throughout its production run, including feature adjustments and powertrain enhancements.

Production

Production Period:

2006-2010

Manufacturing Location:

Jefferson North Assembly Plant, Detroit, Michigan, USA

Discontinuation:

Discontinued after the 2010 model year, with its role in the Jeep lineup largely succeeded by the Grand Cherokee (with its expanded capacity) and later, the Wagoneer/Grand Wagoneer.

🏆 Awards & Recognition

Recognitions

Safety Awards:

Earned 'Good' ratings in IIHS front and side impact tests for 2007 model year.

Consumer Reviews:

Generally received mixed reviews, praised for its spacious interior and optional HEMI V8, but criticized for fuel economy, handling, and some reliability concerns compared to competitors.

Ratings

Fuel Economy Rating:

Below average for its class, particularly with the 5.7L HEMI engine. Manual provides fuel efficiency optimization tips.
