KIA Sportage 2008 Factory Service Repair Manual & Electronic Troubleshooting Manual

Regular price: $16.99
Sale price: $16.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Kia Model: Sportage Year: 2008 Codes Engine Codes: FE (2.0L), BV (2.7L) Chassis Codes: KM 👋 Introduction Market Position Segment: Compact SUV Target Audience: Budget-conscious...

22 people are viewing this right now

Type: Car

Vendor:

Sku: 363346

Tags: 2008 Car Cars Kia Misc Sportage

Product variants

Description

🏷️ Basic Information

Identification

Make:

Model:

Sportage

Year:

Codes

Engine Codes:

FE (2.0L), BV (2.7L)

Chassis Codes:

👋 Introduction

Market Position

Segment:

Compact SUV

Target Audience:

Budget-conscious SUV buyers, families, individuals seeking versatility

Competitive Analysis

Key Competitors:

Honda CR-V, Toyota RAV4, Ford Escape, Nissan Xterra, Hyundai Tucson

Value Proposition:

Affordable pricing, strong warranty (at time of release), practical interior, availability of AWD

Key Features

Engine Options:

Choice between fuel-efficient 2.0L and more powerful 2.7L V6

Drivetrain Options:

Available AWD system for enhanced traction

Interior Practicality:

Foldable rear seats for increased cargo space, comfortable seating for up to five

📋 Manual Details

Coverage Areas

Engines Covered:

2.0L (1998cc) DOHC Inline-4, 2.7L (2656cc) DOHC V6

Transmission Types:

5-Speed Manual, 4-Speed Automatic

Drive Types:

Front-Wheel Drive (FWD), All-Wheel Drive (AWD)

Page Count

Factory Service Manual:

Estimated 1500+ pages (comprehensive)

Electronic Troubleshooting Manual:

Estimated 500+ pages (focused on diagnostics)

Manual Type

Primary Manual:

Factory Service Repair Manual

Secondary Manual:

Electronic Troubleshooting Manual (ETM)

Language

Language:

English

Format

Format:

Digital (PDF likely, searchable)

File Format:

Likely PDF with bookmarking and search functionality

Print Quality:

High resolution for clear diagrams and text

Binding Type:

N/A (Digital Format)

Paper Type:

N/A (Digital Format)

📖 Manual Coverage

Systems Covered

Powertrain:

Engine mechanical, engine management (ECM/PCM), fuel system, ignition system, exhaust system, lubrication system, cooling system

Transmission:

Manual transmission (clutch, gearbox), Automatic transmission (ATF, valve body, torque converter, electronic controls)

Drivetrain:

Front axle, rear axle, transfer case (for AWD), driveshafts, CV joints, differentials

Chassis:

Suspension (front struts, rear multi-link), steering system (power steering pump, rack and pinion), braking system (ABS, EBD, brake lines, calipers, rotors), wheels and tires

Electrical:

Battery, starting system, charging system, lighting system, interior/exterior lighting, power windows/locks, mirrors, wipers, horn, fuses, relays, wiring diagrams

Body:

Body panels, doors, glass, interior trim, seats, exterior trim, bumpers, body sealing

HVAC:

Air conditioning, heating system, ventilation, climate control (manual and automatic)

Safety Systems:

Airbag system (SRS), seat belts

Procedures Included

Maintenance:

Scheduled maintenance intervals, fluid changes (oil, coolant, brake fluid, ATF), filter replacements, spark plug replacement, belt inspections/replacement

Diagnostics:

Troubleshooting guides based on symptoms, diagnostic trouble codes (DTCs) interpretation, scan tool procedures, component testing

Repair:

Step-by-step repair procedures for all major components, component removal and installation, sub-assembly repair, torque specifications for critical fasteners

Specifications:

Tightening torques, fluid capacities and types, electrical specifications, performance data, engine compression test specs

Wiring:

Detailed electrical wiring diagrams for all systems, connector pinouts, circuit descriptions

Technical Depth

Depth:

Comprehensive (covers everything from basic maintenance to major component overhauls and electrical diagnostics)

Diagnostic Focus:

Advanced, with specific diagnostic trees and troubleshooting flowcharts for electrical and mechanical issues

⚙️ Engine Specifications

Primary Engine

Engine 2.0L:

2.0L (G4JP) DOHC Inline-4, 140 hp @ 6000 rpm, 136 lb-ft @ 4500 rpm

Engine 2.7L:

2.7L (G6BA) DOHC V6, 173 hp @ 6000 rpm, 180 lb-ft @ 4000 rpm

Performance

Compression Ratio 2.0L:

9.5:1

Compression Ratio 2.7L:

9.8:1

Fuel System

Fuel Delivery 2.0L:

Multi-point Fuel Injection (MPI)

Fuel Delivery 2.7L:

Multi-point Fuel Injection (MPI)

Fuel Type:

Unleaded Gasoline

Engine Management:

OBD-II Compliant ECU

🔧 Transmission

Standard

Standard Transmission 2.0L:

5-Speed Manual

Standard Transmission 2.7L:

4-Speed Automatic

Optional

Optional Transmission 2.0L:

4-Speed Automatic

Features

AWD System:

Electronically controlled with viscous coupling (optional on most trims)

📐 Dimensions

Exterior

Length:

170.0 inches (4315 mm)

Width:

70.1 inches (1780 mm)

Height:

64.8 inches (1645 mm)

Wheelbase:

103.1 inches (2619 mm)

Interior

Passenger Volume:

Approx. 96.8 cu ft (2741 L)

Cargo

Cargo Volume Behind Rear Seat:

Approx. 23.7 cu ft (671 L)

Cargo Volume With Rear Seat Folded:

Approx. 66.5 cu ft (1883 L)

Weights

Curb Weight 2.0L FWD Manual:

Approx. 3373 lbs (1530 kg)

Curb Weight 2.7L AWD Auto:

Approx. 3726 lbs (1690 kg)

🛡️ Safety Features

Ratings

NHTSA Front Crash Test Driver:

5 Stars (for models with side airbags)

NHTSA Front Crash Test Passenger:

5 Stars (for models with side airbags)

NHTSA Side Impact Front Seat:

5 Stars

NHTSA Side Impact Rear Seat:

5 Stars

IIHS Front Offset Crash Test:

Good (for models with side airbags)

IIHS Side Impact Crash Test:

Good (for models with side airbags)

Active Features

Standard Anti-lock Braking System

Standard Electronic Brake-force Distribution

Traction Control:

Available Traction Control System (TCS)

Passive Features

Airbags:

Standard front airbags, Optional front-seat side airbags and side-curtain airbags

Seatbelts:

Front pretensioner seatbelts

💡 Technology Features

Infotainment

Audio System:

Standard AM/FM/CD player with 4 or 6 speakers. Optional SiriusXM satellite radio.

Display:

Basic LCD display for audio information. Optional navigation system on some higher trims.

Driver Assistance

Cruise Control:

Standard on most trims.

Stability Control:

Available Electronic Stability Control (ESC) on some higher trims.

Connectivity

Auxiliary Input:

Standard auxiliary audio input jack for connecting external music devices.

🔧 Maintenance

Service Intervals

Engine Oil And Filter:

Every 5,000-7,500 miles (8,000-12,000 km) or 6 months, whichever comes first. Check manual for specific conditions.

Engine Coolant:

First replacement at 60,000 miles (96,000 km) or 4 years, then every 30,000 miles (48,000 km) or 2 years.

Transmission Fluid Auto:

Inspect every 30,000 miles (48,000 km), replace if necessary based on condition. Kia recommended interval often 60,000 miles (96,000 km) or 4 years.

Spark Plugs 2.0L:

Iridium type: 105,000 miles (168,000 km)

Spark Plugs 2.7L:

Iridium type: 105,000 miles (168,000 km)

Fluid Specifications

Engine Oil 2.0L:

API SM or higher, SAE 5W-20 (preferred) or SAE 5W-30. Capacity: Approx. 4.4 US quarts (4.2 L) with filter.

Engine Oil 2.7L:

API SM or higher, SAE 5W-20 (preferred) or SAE 5W-30. Capacity: Approx. 4.5 US quarts (4.3 L) with filter.

Engine Coolant:

Ethylene Glycol based coolant, Kia genuine or equivalent (long-life pink/red).

Automatic Transmission Fluid:

Kia Genuine ATF SP-III or equivalent (e.g., Dexron III H compliant with SP-III characteristics). Capacity: Approx. 7.6 US quarts (7.2 L) for change/fill.

Manual Transmission Fluid:

GL-4, SAE 75W-90. Capacity: Approx. 2.1 US quarts (2.0 L).

Brake Fluid:

DOT 3 or DOT 4.

Power Steering Fluid:

ATF Dexron III or Kia Genuine Power Steering Fluid.

Known Issues

Engine Oil Consumption:

Some reports of increased oil consumption on higher mileage 2.7L V6 engines, potentially related to piston rings or valve stem seals.

Automatic Transmission Shifting:

Occasional reports of harsh shifting or delayed engagement on the 4-speed automatic, often improved by fluid service or software update if available.

Cv Joint Boots:

Wear and tear on CV joint boots can lead to failure if not addressed promptly.

Suspension Components:

Squeaks or rattles from front struts or rear suspension components can occur with age and mileage.

Cabin Air Filter:

Location behind glove box can be tricky to access for DIY replacement, but essential for HVAC performance.

📚 Vehicle History

Brand Heritage

Kia Automotive History:

Kia Motors Corporation, founded in 1944, initially produced steel tubing and bicycle parts, later moving into motorcycle and automotive manufacturing. Known for offering value-oriented vehicles.

Model Evolution

Sportage Generation 1:

First generation (1993–2002), based on Mazda Bongo/Ford Econovan platform, body-on-frame construction. Not sold in all markets.

Sportage Generation 2:

Second generation (2005–2010), this model. Unibody construction, developed with Hyundai. Shared platform with Hyundai Tucson (first generation).

Production

Production Years:

2004-2010 (Second Generation)

Manufacturing Locations:

South Korea (Gwangmyeong), Malaysia (Ahmad & Hussein Sdn Bhd)

🏆 Awards & Recognition

Recognitions

IIHS Top Safety Pick Potential:

Achieved 'Good' ratings in IIHS frontal and side impact tests for models equipped with side airbags, indicating strong safety performance for its class and era.

NHTSA Safety Ratings Overall:

Achieved 5-star ratings in NHTSA frontal and side impact tests for models equipped with side airbags, underscoring its safety credentials.

Ratings

Value For Money:

Consistently recognized for its competitive pricing and feature set compared to rivals at its introduction.
