Kia Sportage 2017 2018 2.0T 2.4L Factory Service Repair Manual
- Regular price
- $17.99
- Sale price
- $17.99
- Regular price
-
- Unit price
- / per
🏷️ Basic Information Identification Make: Kia Model: Sportage Model Years Covered: 2017, 2018 Engine Variants Covered: 2.0T (Turbocharged), 2.4L (Naturally Aspirated) Codes Platform Code: QL 👋 Introduction Market Position Segment:...
19 people are viewing this right now
Type: Car
Vendor:
Sku: 489642
Couldn't load pickup availability
Share
🏷️ Basic Information
Identification
Make:
Kia
Model:
Sportage
Model Years Covered:
2017, 2018
Engine Variants Covered:
2.0T (Turbocharged), 2.4L (Naturally Aspirated)
Codes
Platform Code:
QL
👋 Introduction
Market Position
Segment:
Compact SUV / Crossover
Target Audience:
Families, individuals seeking versatile utility and modern features
Competitive Analysis
Key Competitors 2017 2018:
Honda CR-V, Toyota RAV4, Ford Escape, Nissan Rogue, Hyundai Tucson, Mazda CX-5
Key Features
Design:
Sporty and distinctive styling, refined interior
Powertrain Options:
Choice between efficient 2.4L naturally aspirated and powerful 2.0T turbocharged engines
Drivetrain Options:
Available with front-wheel drive (FWD) and all-wheel drive (AWD)
Technology Availability:
Modern infotainment, safety, and convenience features
📋 Manual Details
Coverage Areas
General Coverage:
Comprehensive factory service and repair
Page Count
Estimated Page Count:
Extensive (typical factory manuals for this era are 2000+ pages)
Manual Type
Manual Type:
Factory Workshop Service Repair Manual
Language
Language:
English
Format
Format:
Digital Download (likely PDF)
📖 Manual Coverage
Systems Covered
Powertrain:
Engine mechanical, lubrication, cooling, fuel, exhaust, ignition, engine management (ECM), turbocharger system (for 2.0T)
Transmission:
Manual and Automatic Transmission (including torque converter, valve body, control modules)
Drivetrain:
Front Wheel Drive (FWD), All Wheel Drive (AWD) system, differentials, driveshafts, CV joints
Brakes:
Hydraulic system, ABS, EBD, traction control, parking brake (mechanical/electronic), brake component overhaul
Suspension:
Front suspension (struts, control arms), Rear suspension (multi-link/independent), shock absorbers, springs, wheel alignment specifications
Steering:
Power steering system (electric/hydraulic), steering rack, tie rods, steering column
Body:
Body structure, exterior panels, doors, hood, tailgate, interior trim, glass, seals
HVAC:
Heating, Ventilation, and Air Conditioning system, components, refrigerant, diagnosis
Electrical:
Battery, charging system, starter, lighting, body electrical, comfort/convenience features, fuse box diagrams, wiring schematics
Powertrain Control Module (PCM) / Engine Control Module (ECM):
Diagnostic trouble codes (DTCs), sensor inputs/outputs, actuator control
Infotainment & Navigation:
System operation, troubleshooting (likely basic)
Safety Systems:
Airbag system (SRS), seatbelt pre-tensioners, seat occupancy sensors
Procedures Included
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks/changes, belt inspections/replacements
Troubleshooting:
System diagnosis, symptom-based troubleshooting charts, DTC interpretations
Repair:
Component removal and installation, adjustments, calibration, overhaul procedures for major systems
Diagnostics:
Diagnostic port locations, scan tool usage, data stream interpretation, specific sensor/actuator testing
Torque Specifications:
Detailed torque values for critical fasteners across all systems
Special Tools:
Identification and usage of specific tools required for certain repair procedures
Technical Depth
Depth:
Factory-level technical detail suitable for professional technicians and advanced DIY enthusiasts.
Illustrations Quality:
High-resolution illustrations, photos, and diagrams
Readability:
Designed to be read and printed, facilitating on-the-bench or on-vehicle use.
📊 Manual Specifications
File Format
Digital Format:
Likely PDF
Print Quality
Print Compatibility:
Printable pages
Binding Type
Binding Type:
N/A (Digital Download)
Paper Type
Paper Type:
N/A (Digital Download)
⚙️ Engine Specifications
Primary Engine 2.4L
Engine Code:
G4FJ (Theta II)
Displacement:
2.4 Liters (2359 cc)
Configuration:
Inline 4-cylinder
Valve Train:
Dual Overhead Camshafts (DOHC), 16 valves, Continuously Variable Valve Timing (CVVT)
Horsepower:
181 hp @ 6000 rpm
Torque:
179 lb-ft @ 4000 rpm
Fuel Injection:
Multi-point Fuel Injection (MPI)
Recommended Fuel:
87 Octane Regular Unleaded Gasoline
Primary Engine 2.0T
Engine Code:
G4KH (Theta II Turbo)
Displacement:
2.0 Liters (1998 cc)
Configuration:
Inline 4-cylinder
Valve Train:
Dual Overhead Camshafts (DOHC), 16 valves, Continuously Variable Valve Timing (CVVT)
Horsepower:
240 hp @ 6000 rpm
Torque:
260 lb-ft @ 1450-3500 rpm
Fuel Injection:
Direct Injection (GDI) with Turbocharging
Recommended Fuel:
87 Octane Regular Unleaded Gasoline (premium may be recommended for optimal performance)
🔧 Transmission
Standard 2.4L
Type:
6-speed Automatic Transmission
Drive Modes:
Available in FWD and AWD
Fluid Type Specification:
ATF SP-IV
Fluid Capacity Approximate:
Refer to manual for exact capacity, typically around 7-9 quarts for drain and fill.
Optional 2.0T
Type:
6-speed Automatic Transmission
Drive Modes:
Available in FWD and AWD
Fluid Type Specification:
ATF SP-IV
Fluid Capacity Approximate:
Refer to manual for exact capacity, typically around 7-9 quarts for drain and fill.
📐 Dimensions
Exterior
Length:
Approx. 171.5 inches (4355 mm)
Width:
Approx. 73.0 inches (1855 mm)
Height:
Approx. 64.8 inches (1645 mm)
Wheelbase:
Approx. 105.5 inches (2680 mm)
Cargo
Cargo Volume Behind Rear Seats:
Approx. 30.7 cu ft (870 L)
Cargo Volume With Rear Seats Folded:
Approx. 60.0 cu ft (1700 L)
Weights
Curb Weight Range:
Approx. 3500 - 3800 lbs (1588 - 1724 kg), varies by configuration
Towing Capacity:
Typically not rated for towing in North America, consult specific market documentation.
🛡️ Safety Features
Ratings
NHTSA Overall Safety Rating:
Generally rated 4 out of 5 stars (varies by year and specific test results)
IIHS Top Safety Pick Status:
May qualify for Top Safety Pick or Top Safety Pick+ depending on specific equipment and test results in prior years, verify for 2017-2018.
Active Features
ABS:
Anti-lock Braking System
Ebs:
Electronic Brake-force Distribution
Esc:
Electronic Stability Control
Traction Control:
Traction Control System (TCS)
Hill Start Assist:
Hill-start Assist Control (HAC)
Passive Features
Airbags:
Front airbags, front side-impact airbags, full-length side curtain airbags
Seatbelts:
3-point active front seatbelts with pretensioners and load limiters, rear 3-point seatbelts
Child Seat Anchors:
LATCH (Lower Anchors and Tethers for CHildren) system
💡 Technology Features
Infotainment
Available Systems:
UVO eServices infotainment system, touchscreens (5-inch, 7-inch, 8-inch), Apple CarPlay, Android Auto (on certain trims/options)
Audio Options:
Standard audio systems, available Harman Kardon premium sound system
Driver Assistance
Available Adas:
Autonomous Emergency Braking (AEB), Lane Departure Warning (LDW), Blind-Spot Detection (BSD), Rear Cross-Traffic Alert (RCTA), Forward Collision Warning (FCW), Surround View Monitor
Connectivity
Smartphone Integration:
Available Apple CarPlay and Android Auto support
Telematics:
UVO eServices telematics system for remote access and diagnostics
🔧 Maintenance
Service Intervals General
Oil Change Interval:
Every 7,500 miles (12,000 km) or 6 months, whichever comes first (under normal driving conditions). Refer to manual for severe driving conditions.
Air Filter Replacement Interval:
Every 30,000 miles (48,000 km) or as needed based on inspection.
Cabin Air Filter Replacement Interval:
Every 15,000 miles (24,000 km) or 12 months.
Engine Coolant Replacement Interval:
Initial replacement at 105,000 miles (168,000 km), then every 45,000 miles (72,000 km) or 48 months thereafter.
Transmission Fluid Change Interval:
Refer to manual. Often listed as 'lifetime' but recommended periodic checks and changes, especially under severe use. Typically around 60,000 miles for drain and fill.
Fluid Specifications
Engine Oil Type 2.4L:
SAE 0W-20, API SN or ILSAC GF-5 certified
Engine Oil Capacity 2.4L:
Approx. 4.8 US quarts (4.6 Liters) with filter change
Engine Oil Type 2.0T:
SAE 0W-20, API SN or ILSAC GF-5 certified
Engine Oil Capacity 2.0T:
Approx. 5.0 US quarts (4.7 Liters) with filter change
Engine Coolant Type:
Genuine Kia Long Life Coolant (or equivalent Asian vehicle OAT coolant, typically blue)
Brake Fluid Type:
DOT 3 or DOT 4
Known Issues
Engine Knock Sensor Concern:
Some reports of engine knock sensor issues leading to check engine lights. Manual will cover diagnosis.
Transmission Shifting Concerns:
Occasional reports of rough shifting or hesitation. Manual will provide diagnostic procedures and software updates.
Interior Rattles And Squeaks:
Common in many vehicles of this class. Manual will detail interior panel removal and potential fixes.
📚 Vehicle History
Brand Heritage
Kia History:
Kia Motors Corporation is a South Korean automobile manufacturer, founded in 1944. Known for its value, reliability, and increasingly stylish and technologically advanced vehicles.
Model Evolution
Sportage Generations:
The 2017-2018 Sportage belongs to the fourth generation (QL), which debuted for the 2017 model year. This generation saw a significant redesign with a more mature and European-inspired aesthetic.
Production
Production Location:
Primary manufacturing plants in South Korea (Gwangmyeong, Hwaseong) and Slovakia (Žilina).
🏆 Awards & Recognition
Recognitions
Auto Express Driver Power Survey 2017:
Kia Sportage ranked highly in the 'Family SUV' category in some markets for owner satisfaction.
Kes Awards 2017:
Kia Sportage has received various design awards and safety accolades in different regions.
Ratings
Fuel Economy Ratings:
EPA estimates vary by engine and drivetrain. Typically in the range of 20-23 MPG city / 27-30 MPG highway.
