Land Rover Discovery 2 1998 Factory Service Repair Manual

Regular price: $16.99
Sale price: $16.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Land Rover Model: Discovery 2 Year: 1998 👋 Introduction Market Position Segment: Mid-size Luxury SUV / Off-Road Vehicle Competitive Analysis Key Competitors: Jeep Grand Cherokee,...

21 people are viewing this right now

Type: Car

Vendor:

Sku: 357592

Tags: 1998 Car Cars Discovery Discovery 2 Land Rover

Product variants

Description

🏷️ Basic Information

Identification

Make:

Land Rover

Model:

Discovery 2

Year:

👋 Introduction

Market Position

Segment:

Mid-size Luxury SUV / Off-Road Vehicle

Competitive Analysis

Key Competitors:

Jeep Grand Cherokee, Toyota Land Cruiser (similar era), Ford Explorer, Chevrolet Blazer

Key Features

Off Road Capability:

Renowned for its robust off-road prowess, featuring permanent four-wheel drive and advanced suspension systems.

Utility:

Practicality and versatility, offering ample passenger and cargo space, suitable for families and adventurers.

Manual Value Proposition

Dealer Equivalence:

Identical information to that used by official Land Rover dealers.

📋 Manual Details

Coverage Areas

Primary Focus:

Service and Repair

Secondary Focus:

Maintenance, Diagnostics, Troubleshooting

Page Count

Estimated Page Count:

Extensive (typical factory service manuals are 1000+ pages)

Manual Type

Type:

Factory Service Manual / Workshop Manual

Language

Language:

English

Format

Format:

📖 Manual Coverage

Systems Covered

Powertrain:

Engine, Transmission, Drivetrain (including differentials, transfer case, driveshafts)

Chassis:

Suspension (including ACE system), Steering, Brakes, Wheels and Tires

Electrical:

Engine Management, Lighting, Instrumentation, HVAC, Audio, SRS (Supplementary Restraint System), Body Electrical

Body And Interior:

Body Panels, Doors, Glass, Seats, Trim, Body Sealing

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection/replacement

Engine Repair:

Engine overhaul, cylinder head service, piston and ring replacement, crankshaft and bearing service, timing system repair

Transmission Repair:

Automatic and manual transmission service and overhaul, clutch replacement, transfer case service

Suspension And Steering:

Component replacement (shocks, springs, control arms, ball joints, tie rods), power steering system service, ACE system diagnostics and repair

Brake System:

Brake pad/shoe replacement, rotor replacement, caliper service, bleeding procedures, ABS system diagnostics

Electrical Diagnostics:

Wiring diagrams, troubleshooting guides for various electrical faults, component testing

Air Conditioning:

System servicing, component replacement (compressor, evaporator, condenser), refrigerant handling

Technical Depth

Depth:

Comprehensive (covers from basic maintenance to complete engine and transmission rebuilds)

Diagnostics:

Detailed diagnostic procedures, fault code interpretation, specific component testing methods

Specifications:

Torque settings, fluid capacities, tolerances, electrical specifications, diagnostic parameter ranges

📊 Manual Specifications

File Format

Requirements:

Adobe PDF Reader & WinZip

Interactivity:

Zoom In/Out functionality

Compatibility:

All Versions of Windows & Mac

Print Quality

Printability:

High-resolution, printable pages

Binding Type

Physical Manual Analogue:

Wire-O or perfect binding (typical for service manuals)

Paper Type

Physical Manual Analogue:

Durable, shop-friendly paper (e.g., matte finish, heavier stock)

⚙️ Engine Specifications

Primary Engine

Engine Code:

Typically the 4.0L V8 (e.g., 40D) or the 2.5L TD5 Diesel (e.g., 25D) for this era, though the manual may cover both or specific variants.

Displacement Petrol:

4.0 Liters (3947 cc)

Cylinders Petrol:

8 (V-configuration)

Bore Stroke Petrol:

88.9 mm x 78.9 mm (typical for the 4.0L V8)

Compression Ratio Petrol:

Approx. 8.3:1 (typical for the 4.0L V8)

Horsepower Petrol:

Approx. 182 hp @ 4750 rpm (for 4.0L V8)

Torque Petrol:

Approx. 235 lb-ft @ 3200 rpm (for 4.0L V8)

Displacement Diesel:

2.5 Liters (2495 cc)

Cylinders Diesel:

5 (Inline)

Bore Stroke Diesel:

94.0 mm x 90.0 mm (typical for TD5)

Compression Ratio Diesel:

Approx. 19.5:1 (typical for TD5)

Horsepower Diesel:

Approx. 136 hp @ 4200 rpm (for TD5)

Torque Diesel:

Approx. 220 lb-ft @ 1900 rpm (for TD5)

Fuel System

Fuel Type:

Unleaded Petrol (for V8) or Diesel

Injection System Petrol:

Multi-point Fuel Injection (MPI)

Injection System Diesel:

Direct injection with electronic control (GEMS or Bosch for TD5)

Engine Management

GEMS ECU (for V8), Bosch EDC (for TD5)

🔧 Transmission

Standard

Type:

4-speed automatic transmission (e.g., ZF 4HP22) for V8, 5-speed manual (e.g., R380) for TD5, or 4-speed automatic for TD5.

Optional

Type:

5-speed manual transmission (often for TD5 models).

Features

Drivetrain:

Permanent Four-Wheel Drive (4WD) with center differential lock and optional rear differential lock.

Transfer Case:

2-speed LT230 transfer case (high/low range).

📐 Dimensions

Exterior

Length:

Approx. 4709 mm (185.4 in)

Width:

Approx. 1880 mm (74.0 in)

Height:

Approx. 1930 mm (76.0 in)

Wheelbase

Wheelbase:

Approx. 2540 mm (100.0 in)

Weights

Curb Weight:

Approx. 2000-2200 kg (4400-4850 lbs), varies by engine and specification.

Gross Vehicle Weight Rating:

Typically around 2800 kg (6170 lbs)

🛡️ Safety Features

Ratings

Passive Safety Features:

Front airbags, optional side airbags, seatbelt pre-tensioners, reinforced body structure.

Active Features

Braking:

ABS (Anti-lock Braking System), ventilated front discs, rear solid discs.

Traction Control:

Optional ETC (Electronic Traction Control) or DTC (Dynamic Traction Control) depending on trim and options.

Electronic Stability:

Not commonly equipped on 1998 models, but the manual would detail any such systems if present.

Srs Precautions

Srs Handling:

Specific precautions for handling SRS components, airbag module replacement, and system deactivation/activation procedures.

💡 Technology Features

Infotainment

Audio System:

Factory fitted radio/cassette or CD player, potentially with CD changer.

Driver Assistance

Cruise Control:

Optional on some models.

Connectivity

Vehicle Diagnostics:

OBD-II diagnostic port for engine and system fault retrieval.

🔧 Maintenance

Service Intervals

Oil Change Petrol:

Typically every 6,000 miles or 12 months (refer to manual for exact schedule).

Oil Change Diesel:

Typically every 6,000 miles or 12 months (refer to manual for exact schedule).

Timing Belt Chain:

V8 uses a timing chain, TD5 uses a timing belt (replacement interval varies, typically 80,000-100,000 miles).

Fluid Specifications

Engine Oil Petrol:

API SJ or better, SAE 5W-30 or 10W-40 (check manual for specific grade and capacity).

Engine Oil Diesel:

API CF-4 or CG-4, SAE 5W-30 or 10W-40 (check manual for specific grade and capacity).

Transmission Fluid Automatic:

ESR-M2C164-A or equivalent DEXRON-III (check manual for exact specification and capacity).

Transmission Fluid Manual:

API GL-4, SAE 75W-90 or 80W-90 (check manual for exact specification and capacity).

Coolant:

OAT (Organic Acid Technology) coolant, ethylene glycol-based, with corrosion inhibitors. Refer to manual for specific type and capacity (typically green or orange/red).

Known Issues

Engine V8:

Head gasket failure (GEMS engine), oil leaks, common for early V8s to require regular inspection.

Engine Td5:

Head gasket failure, injector seal washers, oil pressure switch failure, starter motor issues.

Suspension:

Air suspension (SLS) compressor failure, leaky air springs, ACE system pipe leaks, ball joint wear.

Electronics:

Wiring harness issues (especially under the bonnet), ABS sensor failures, BECM (Body Electrical Control Module) faults.

Drivetrain:

Center differential wear, rear propshaft UJ failure.

📚 Vehicle History

Brand Heritage

Land Rover Legacy:

Built on Land Rover's long history of producing rugged, capable off-road vehicles.

Model Evolution

Discovery Series Ii Introduction:

Introduced in 1998 as a significant update to the original Discovery, featuring a longer wheelbase, improved interior, and updated technology.

Production

Manufacturing Location:

Solihull, United Kingdom

🏆 Awards & Recognition

Recognitions

Off Road Acclaim:

Consistently recognized for its off-road capabilities and durability.
