Positioning:
The Land Rover Discovery 2 (LT platform) was positioned as a capable and versatile off-road and family SUV, known for its robustness and go-anywhere ability.
Competitors:
Competed with vehicles like the Toyota Land Cruiser, Jeep Grand Cherokee, and Mercedes-Benz ML-Class in its segment.
Vehicle Strengths:
Advanced four-wheel-drive system (including center and rear differential locks on some models), robust chassis, comfortable ride, spacious interior, strong towing capacity.
Benefit:
Provides the necessary information to perform maintenance and repairs, saving money on labor costs and ensuring proper upkeep.
Primary Coverage:
Maintenance, Repair, Diagnostics, Troubleshooting
Secondary Coverage:
Specifications, Capacities, Lubricants, Wiring Diagrams
Estimated Pages:
Varies (typically 2000-3000+ for comprehensive factory manuals)
Type:
Factory Service Repair Manual
Powertrain:
V8 Engine (various variants), R380 Manual Gearbox, ZF 4HP22-24 Automatic Gearbox, LT230SE Transfer Box, Propeller Shafts
Chassis:
Front Axle, Rear Axle, Steering System, Front Suspension, Rear Suspension
Brakes:
Brake System (including ABS, if applicable)
Body And Interior:
Doors, Exterior Fittings, Interior Trim, Screens, Seats, Sunroof, Chassis and Body Dimensions, Panel Repairs, Body Sealing, Corrosion Prevention, Painting
HVAC And Electrical:
Heating and Ventilation, Air Conditioning, Wipers and Washers, Charging and Starting, Lighting, Body Control Unit, Alarm System, Windows, In-Car Entertainment, Harnesses, Navigation System, Instruments
Engine Management:
Engine Management System (V8)
Emissions:
Emission Control (V8)
Maintenance Tasks:
Scheduled maintenance, fluid changes, filter replacements, lubrication
Diagnostic Procedures:
Troubleshooting guides, fault code interpretation, system checks
Repair Procedures:
Step-by-step instructions for component removal, installation, and repair
Technical Specifications:
Torque wrench settings, capacities, fluid specifications, electrical specifications
Special Procedures:
Lifting and towing, chassis and body dimensions, panel repairs, corrosion prevention
Depth:
Comprehensive (covering routine maintenance to major component overhauls and diagnostics)
Engine Type:
V8 (likely the 4.0L or 4.6L Rover V8)
Engine Code:
Rover V8 (e.g., 40D, 46D)
Displacement Liters:
4.0L and 4.6L (typical for the era)
Horsepower Approximate:
Approx. 190-225 hp (depending on exact engine variant)
Torque Approximate:
Approx. 225-270 lb-ft (depending on exact engine variant)
Induction:
Multi-point fuel injection (MPI)
Coolant Type:
Ethylene Glycol based (e.g., Texaco Havoline XLC or equivalent, check manual for specific LR specification)
System:
Catalytic converters, EGR (Exhaust Gas Recirculation), secondary air injection (on some models).
Type:
R380 5-speed Manual Transmission
Type:
ZF 4HP22-24 4-speed Automatic Transmission
Transfer Case:
LT230SE, 2-speed with lockable center differential
Manual Gearbox Oil:
API GL-4 or GL-5, SAE 75W-90 or 80W-90 (refer to manual for specific R380 recommendation, often specific synthetic oils)
Automatic Gearbox Oil:
ZF TE-ML 14A or equivalent (e.g., Dexron IIE or III)
Transfer Box Oil:
API GL-4 or GL-5, SAE 75W-90 or 80W-90 (check manual for specific LT230SE recommendation)
NHTSA Rating:
Not typically rated by NHTSA in a standardized manner for this era and model's market.
Traction Control:
Optional (TC) on some models.
ABS:
Standard Anti-lock Braking System (ABS).
Airbags:
Driver and front passenger airbags.
Seatbelts:
3-point seatbelts with pretensioners.
Coverage:
Detailed procedures for airbag system diagnostics and repair, seatbelt mechanisms.
System:
Basic AM/FM radio, cassette, CD player (optional) with integrated speakers. 'In Car Entertainment' section will detail wiring and troubleshooting.
Features:
ABS, optional Traction Control (TC).
Features:
Limited by era; focused on basic vehicle electrical systems and diagnostics.
Coverage:
Detailed information on the instrument cluster, warning lights, and their diagnostic procedures.
Coverage:
Information on systems like ABS and potentially TC.
Availability:
Optional, early generation navigation systems may have been available.
Oil Change Interval Miles:
Typically 6,000-12,000 miles or 12 months, whichever comes first (refer to manual for exact schedule).
Air Filter Replacement Miles:
Typically 12,000-24,000 miles or as needed based on driving conditions.
Spark Plug Replacement Miles:
Varies significantly by V8 engine type, could be 30,000-100,000 miles (refer to manual).
Engine Oil Type:
API SJ or SL, SAE 10W-40 or 10W-30 (depending on climate and engine variant, refer to manual for precise specification).
Engine Oil Capacity Quarts:
Approx. 6.5 quarts (with filter) for V8 engines.
Brake Fluid Type:
DOT 3 or DOT 4 (refer to manual).
Power Steering Fluid Type:
ATF Dexron II or III, or specific Land Rover specified fluid.
Common Problems:
Head gasket leaks, ACE (Active Cornering Enhancement) system faults, SLS (Self-Levelling Suspension) issues, engine management sensor failures, rust (especially on chassis and body panels), viscous fan coupling failure.
Troubleshooting Focus:
The manual will be invaluable for diagnosing and repairing these common issues.
Heritage:
Land Rover has a long history of producing rugged, off-road capable vehicles, dating back to the original Land Rover Series in 1948.
Discovery Lineage:
The Discovery 2 (LT) succeeded the original Discovery (often referred to as Discovery 1 or 'Disco 1') and introduced a revised chassis, improved electronics, and updated styling.
Production Years:
The Discovery 2 was produced from 1998 to 2004. The 1996 date in the product name likely refers to a manual that covers models up to or around that period, or a slight mislabeling as Discovery 2 typically starts with the 1998 model year. The manual is explicitly for the 'Discovery 2'.
