🏷️ Basic Information

Make:

Mitsubishi

Model:

Triton

Alternate Model Names:

L200, Strada, Warrior, Sportero, Hunter (Israel)

Generation Code:

Fourth Generation (KB/KC)

Chassis Codes:

KB4T (4x4), KB9T (4x4 Heavy Duty)

👋 Introduction

Vehicle Segment:

Mid-size pickup truck

Competitors:

Toyota Hilux, Ford Ranger, Isuzu D-Max, Nissan Navara, Holden Colorado

Vehicle Attributes:

Robust construction, reliable diesel powertrains, strong off-road capability, versatile utility.

Diy Benefit:

Enables DIY owners and enthusiasts to perform maintenance, diagnostics, and repairs, saving on professional labor costs.

📋 Manual Details

Applicability:

2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013

Estimated Page Count:

Varies significantly by specific engine and drivetrain, often exceeding 2000 pages for a complete workshop manual.

Type:

Workshop Service Repair Manual

Language:

English

Format:

Digital Download (PDF, potentially ZIP/RAR)

📖 Manual Coverage

Powertrain:

Engine (2.5L Diesel, 3.2L Diesel, 3.5L Petrol), Fuel System, Lubrication System, Cooling System, Exhaust System, Intake System

Drivetrain:

Transmission (Manual and Automatic), Clutch, Driveshafts, Differentials, Transfer Case, Axles

Chassis:

Suspension (Front and Rear), Steering System, Brake System (Front and Rear), Wheels, Tires

Electrical:

Ignition System, Charging System (Alternator, Battery), Starting System (Starter Motor), Lighting System, Instrumentation, ECUs (Engine Control Unit, Transmission Control Unit, etc.), Wiring Diagrams, Wire/Cable/Hose Routing

Bodywork:

Body Panel Repair, Interior Trim, Doors, Windows, Seats, Chassis Assembly

Climate Control:

Air conditioning system (refrigerant type, servicing procedures, troubleshooting), heater core, HVAC controls.

Body Electrical:

Interior and exterior lighting, power windows, power mirrors, central locking, wiper system, horn, horn circuit.

Maintenance:

Scheduled maintenance, Oil changes, Filter replacements, Fluid level checks and top-offs, Spark plug replacement (petrol), Glow plug inspection (diesel), Brake fluid flush, Coolant flush, Air filter replacement

Repair:

Engine disassembly and reassembly, Transmission overhaul, Clutch replacement, Brake caliper/rotor replacement, Suspension component replacement, Steering rack repair, Fuel injector testing/replacement, Cooling system component replacement, Electrical component diagnostics and replacement

Troubleshooting:

Diagnostic procedures for common drivability issues, Electrical fault finding, Brake system malfunctions, Suspension noises, Drivetrain issues

Restoration:

Detailed instructions for component rebuilds and restoration of various systems.

Wheel Alignment:

Specifications and procedures for checking and adjusting wheel alignment angles (camber, caster, toe).

Brake Servicing:

Detailed procedures for front and rear brake pad replacement, rotor resurfacing/replacement, brake caliper service, bleeding the brake system.

Suspension Service:

Replacement of shock absorbers, springs, ball joints, control arm bushings, sway bar links, and steering linkage components.

Engine Diagnostics:

Step-by-step guides for diagnosing engine performance issues, misfires, and abnormal noises using diagnostic codes and measurement tools.

Diagnostics:

Advanced diagnostic procedures, use of diagnostic tools, interpretation of trouble codes.

Specifications:

Detailed torque specifications for all fasteners, service data, fluid capacities, and specifications for all major components.

Illustrations:

Abundant illustrations, exploded views, and diagrams to aid in understanding procedures and identifying parts.

Torque Specifications:

Comprehensive torque values for critical engine, chassis, and driveline fasteners are provided, essential for correct assembly and to prevent damage.

📊 Manual Specifications

Format Details:

PDF (Portable Document Format), potentially requiring decompression utilities like WinZip or WinRAR for access.

Compression Requirement:

Some manuals may be delivered in a compressed format (ZIP or RAR), requiring a decompression utility (e.g., WinZip, WinRAR) to access the PDF files.

Printability:

Printable on any standard printer; no restrictions mentioned on printing or burning to disc.

Binding:

N/A (Digital download only, not a physical product)

Paper Quality:

N/A (Digital download only)

⚙️ Engine Specifications

Engine Options:

4D56 2.5L I4 Turbo Diesel, 6G74 3.5L V6 MIVEC MPI Petrol, 4M41 3.2L DI-D I4 Turbo Diesel (depending on market and trim)

Power Output 2 5 Diesel:

Approx. 134-176 hp (100-131 kW) depending on tune and turbocharger specification.

Torque Output 2 5 Diesel:

Approx. 231-280 lb-ft (313-380 Nm) depending on tune and turbocharger specification.

Power Output 3 2 Diesel:

Approx. 163-175 hp (121-130 kW).

Torque Output 3 2 Diesel:

Approx. 260-280 lb-ft (353-380 Nm).

Power Output 3 5 V6 Petrol:

Approx. 200-220 hp (149-164 kW).

Torque Output 3 5 V6 Petrol:

Approx. 245-255 lb-ft (332-346 Nm).

Diesel Injection:

Common Rail Direct Injection (CRDi) for 4D56 and 4M41 engines.

Petrol Injection:

Multi-Point Fuel Injection (MPI) for 6G74 engine.

🔧 Transmission

Manual Transmission:

5-speed and 6-speed manual transmissions available depending on engine and market.

Automatic Transmission:

4-speed and 5-speed automatic transmissions available depending on engine and market.

Drivetrain Options:

2WD (Rear-Wheel Drive) and 4WD (Four-Wheel Drive) with available Super Select 4WD system.

📐 Dimensions

Body Styles:

Single Cab, Club Cab (Extended Cab), Double Cab

Wheelbase Approx:

Approx. 3000 mm (varies slightly by body style).

Curb Weight Approx:

Approx. 1800 kg - 2100 kg (varies by configuration).

🛡️ Safety Features

Ancap Rating:

Varies by market and year, often 4-star or 5-star ANCAP rating for Double Cab models.

Active Safety:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA), Active Stability Control (ASC), Traction Control (TCL) - availability dependent on trim level.

Passive Safety:

Front airbags for driver and passenger, side airbags and curtain airbags (on higher trims and Double Cab models), front seatbelt pretensioners, impact-absorbing steering column.

💡 Technology Features

Audio System:

Factory-fitted audio systems typically include AM/FM radio, CD player, and MP3 playback. Higher trims may feature a multi-information display and enhanced speaker systems. Auxiliary input jack is common.

Driver Aids:

Availability of features like cruise control, parking sensors (rear), and a reversing camera varies by trim level and market. ABS, EBD, ASC, and TCL are key electronic driver aids.

Connectivity Options:

Bluetooth hands-free calling and audio streaming became more common in later years of this generation, often integrated with the audio system.

🔧 Maintenance

Oil Change Interval Diesel:

Typically every 7,500 miles or 6 months (whichever comes first), though consult specific manual for exact recommendation.

Oil Change Interval Petrol:

Typically every 7,500 miles or 6 months (whichever comes first), though consult specific manual for exact recommendation.

Timing Belt Replacement:

For 6G74 V6 petrol engine: Check manual, typically around 60,000-90,000 miles. Diesel engines usually feature timing chains, requiring less frequent maintenance but eventual inspection.

Engine Oil Diesel:

API CI-4 or CJ-4 specification, SAE 15W-40 or 5W-40 depending on climate. Check manual for exact OEM recommendation (e.g., Mitsubishi Dia Queen).

Engine Oil Petrol:

API SN/SM/SL specification, SAE 5W-30 or 10W-30 depending on climate. Check manual for exact OEM recommendation.

Transmission Fluid Manual:

API GL-4 or GL-5, SAE 75W-90 or 80W-90 gear oil. Check manual for specific viscosity and type.

Transmission Fluid Automatic:

Mitsubishi Dia Queen ATF SP III or equivalent. Always use the specified automatic transmission fluid.

Coolant Type:

Ethylene Glycol based coolant with anti-corrosion inhibitors. Typically a 50/50 mix with deionized water. Use genuine Mitsubishi Super Long Life Coolant (SLLC) or equivalent.

Common Problems:

Early models of the 4D56 diesel engine may experience turbocharger issues or injector problems under certain conditions. Differential and transfer case issues can occur with aggressive off-road use. Some owners report minor electrical gremlins and interior trim wear over time.

Turbocharger Diesel:

Potential for variable geometry turbocharger (VGT) actuator issues or clogging due to carbon buildup, particularly with short-distance driving. Proper maintenance and occasional Italian tune-ups can help.

Drivetrain Wear:

U-joint and CV joint wear can occur, especially in vehicles used frequently for towing or off-roading. Regular lubrication and inspection are recommended.

📚 Vehicle History

Mitsubishi Truck Lineage:

Part of Mitsubishi's long-standing tradition of producing robust and capable utility vehicles, building on the legacy of the Mitsubishi L200.

Fourth Generation Introduction:

The fourth generation (KB/KC) was introduced globally in 2005, with the 2006 model year representing an early part of this generation's lifecycle. This generation saw significant updates in styling, interior comfort, and powertrain refinement.

Production Plants:

Primarily manufactured at Mitsubishi's facilities in Thailand (Laem Chabang).

🏆 Awards & Recognition

Industry Awards:

While specific awards for the 2006-2013 models vary by market, the Triton/L200 lineage has consistently been recognized for its durability, reliability, and value proposition in the pickup truck segment by automotive publications and consumer surveys in various regions.
