Segment:
Sport touring motorcycle
Brand Heritage:
Moto Guzzi is known for its distinctive transverse V-twin engine configuration and Italian craftsmanship.
Competitors:
BMW R 1200 RT, Yamaha FJR1300, Honda ST1300.
Engine Layout:
Transverse 90-degree V-twin, air-cooled.
Design Philosophy:
Comfortable for long-distance touring with performance capabilities.
Value Proposition:
Empowers owners and technicians with comprehensive knowledge for maintaining and repairing the Norge 1200.
General Coverage:
Repair, Maintenance, Rebuild, Refurbish, Restoration
Estimated Pages:
Hundreds (as stated in description, typical for this level of detail)
Type:
Service and Repair Manual
Language:
English (standard for most commercial manuals)
Engine Mechanical:
Disassembly, inspection, assembly, troubleshooting of the 1151cc V-twin engine.
Engine Management:
Fuel injection system (EFI), ignition system, emission control systems.
Transmission:
6-speed gearbox, clutch assembly, shaft drive maintenance.
Chassis And Suspension:
Frame, front forks (including adjustment), rear shock absorber (including adjustment), swingarm, wheel bearings.
Brakes:
Front and rear brake systems, ABS (if equipped), brake fluid specifications and bleeding procedures.
Electrical System:
Wiring diagrams, battery, charging system, lighting, starting system, fuses, relays, ECU, instrument panel.
Fuel System:
Fuel tank, fuel pump, fuel lines, fuel filter replacement.
Exhaust System:
Mufflers, catalytic converter, exhaust gaskets.
Bodywork And Trim:
Fairings, seat removal, body panel repair and replacement, windshield adjustment/replacement.
Wheels And Tires:
Tire pressure, tire replacement, wheel balancing, wheel specifications.
Routine Maintenance:
Oil changes, filter replacements, spark plug replacement, chain adjustment (if applicable, though shaft drive), valve clearance checks.
Troubleshooting:
Diagnostic procedures for common issues, fault code interpretation (if applicable).
Rebuilding:
Complete engine and gearbox rebuild procedures with detailed steps and torque specifications.
Component Replacement:
Step-by-step guides for replacing major components like the clutch, brake calipers, suspension units.
Diagnostics:
Electrical system diagnostics, fuel system testing, ignition timing checks.
Calibration:
Throttle body synchronization, idle speed adjustment.
Depth:
Comprehensive, covering everything from basic maintenance to full engine and gearbox rebuilds, including detailed torque specifications.
Engine Type:
Four-stroke, air-cooled, 90° V-twin
Displacement:
1151 cc (1.15 liters)
Bore X Stroke:
95 mm x 81.2 mm (typical for this engine family)
Valve Train:
Overhead valves, pushrod actuated (characteristic of Guzzi).
Horsepower:
Approx. 107 HP @ 7500 rpm (typical for this model/year)
Torque:
Approx. 110 Nm (81 lb-ft) @ 6000 rpm (typical for this model/year)
Fuel Delivery:
Electronic Fuel Injection (EFI), Marelli IAW 5AM (common)
Fuel Type:
Unleaded gasoline, minimum 95 RON
Length:
Approx. 2,250 mm (typical)
Width:
Approx. 880 mm (typical, including mirrors)
Height:
Approx. 1,400 mm (typical, including windscreen)
Dry Weight:
Approx. 243 kg (typical)
Wet Weight:
Approx. 270 kg (typical, with fluids and fuel)
Fuel Capacity:
23 liters (including reserve)
ABS:
Available (Bosch ABS system likely)
Brakes Front:
Dual 320mm discs, 4-piston calipers (Brembo)
Brakes Rear:
Single 282mm disc, 2-piston caliper (Brembo)
Lighting:
Halogen headlights, LED taillight (typical)
Instrument Panel:
Analog tachometer and speedometer, LCD display for odometer, trip meters, fuel level, clock, gear indicator (depending on exact trim).
ABS:
Anti-lock Braking System (ABS) available on certain models/options.
ECU Diagnostics:
On-board diagnostics capabilities via diagnostic port (if equipped).
Oil Change Interval:
Every 10,000 km or annually (refer to manual for exact specification).
Valve Clearance Check:
Every 20,000 km (typical for this engine).
Spark Plug Replacement:
Every 20,000 km (typical, depending on plug type).
Engine Oil Type:
SAE 10W-40 Synthetic motorcycle oil, API SG or higher (refer to manual for precise specification).
Engine Oil Capacity:
Approximately 3.5 liters (with filter change) (refer to manual).
Gearbox Oil Type:
SAE 75W-90 Synthetic GL-5 (refer to manual).
Brake Fluid Type:
DOT 4 (refer to manual).
Final Drive Oil Type:
SAE 75W-90 GL-5 (refer to manual).
Common Wear Items:
Clutch wear, driveshaft splines, fuel pump reliability (early models).
Electrical Gremlins:
Can sometimes occur with wiring harnesses or sensor connections, especially if not properly maintained.
Founding:
Founded in Mandello del Lario, Italy, in 1921.
Specialty:
Renowned for its longitudinally mounted V-twin engines and shaft drive.
Predecessor:
The Norge concept evolved from earlier large-displacement Guzzi touring bikes, with a focus on aerodynamics and comfort.
Development:
Introduced as a more modern and comfortable alternative to the Norge 1200 8V, later models integrated ABS and improved electronics.
Manufacturing Location:
Mandello del Lario, Italy
Owner Satisfaction:
While specific awards are not readily documented for this model year, Moto Guzzi generally enjoys strong loyalty from its owner base for its unique character and build quality.
Review Scores:
Contemporary reviews often praised its comfortable ergonomics, powerful torque, and classic Guzzi feel, while noting its weight and potential for vibrations compared to inline-four competitors.
