Vehicle Segment:
Compact Crossover SUV
Target Audience:
DIY enthusiasts, independent repair shops, vehicle owners seeking detailed repair and maintenance information.
Competitors:
Honda CR-V, Toyota RAV4, Ford Escape, Mazda CX-5, Chevrolet Equinox.
Manual Advantage:
Licensed OE (Original Equipment) derived information from RepairSurge, offering accuracy and comprehensiveness beyond generic repair guides.
Convenience:
Instant online access across multiple devices, eliminating the need for physical manuals and their associated storage/accessibility issues.
Primary Scope:
Service, Repair, Diagnostics, Maintenance
Geographic Coverage:
North America (assumed based on licensing and typical distribution)
Estimated Pages:
Extensive (Software-based, no fixed page count; equivalent to thousands of printed pages)
Type:
Official Service and Repair Manual Software
Format:
Online Software/Web-based Access
Access Duration:
1 Year (with renewal discounts available)
Accessibility:
PC, Laptop, Smartphone, Tablet via Web Browser
Powertrain:
Engine mechanical, Engine control systems (ECM), Fuel system, Lubrication system, Cooling system, Ignition system, Emission control systems, Exhaust system, Transmission (CVT/Automatic), Drivetrain (AWD/FWD)
Chassis:
Suspension (front & rear), Steering system, Brake system (hydraulic, ABS, EBD), Wheels and tires
Electrical:
Body control modules (BCM), Powertrain control modules (PCM), Instrument cluster, Lighting systems (interior & exterior), Audio and entertainment systems, HVAC controls, Power windows, locks, mirrors, Wiper and washer systems, SRS (Supplemental Restraint System/Airbags)
Body And Trim:
Exterior body panels, Interior trim, Doors, Hood, Liftgate, Bumpers, Glass and seals
Maintenance:
Scheduled maintenance intervals, fluid changes, filter replacements, lubrication
Diagnostics:
Troubleshooting charts, diagnostic trouble codes (DTCs), component testing procedures, wiring diagrams
Repair:
Component removal and installation, overhaul procedures, adjustments, specifications for torque, alignment, etc.
Wiring:
Complete electrical schematics, component location, connector diagrams, troubleshooting guides for electrical faults
Depth:
Factory-level technical information, covering basic maintenance to advanced diagnostics and component overhaul.
โ๏ธ Engine Specifications
Engine Type:
2.5L DOHC 16-valve Inline 4-cylinder
Horsepower:
170 hp @ 6000 rpm (approx.)
Torque:
175 lb-ft @ 4400 rpm (approx.)
Fuel Delivery:
Electronic Fuel Injection (EFI) with sequential multi-port fuel injection
Fuel Type:
Unleaded Regular (87 octane recommended)
Coolant Type:
Nissan Genuine Super Long Life Coolant (Blue) or equivalent silicate-free, ethylene glycol-based coolant
Oil Type:
SAE 5W-30 API SN (or newer) synthetic motor oil
Oil Capacity:
Approximately 5.1 US quarts (4.8 liters) with filter change
Timing Mechanism:
Dual Continuously Variable Valve Timing Control (CVTCS) on intake and exhaust camshafts; Timing Chain
Transmission Type:
Xtronic Continuously Variable Transmission (CVT)
Transmission Options:
All-Wheel Drive (AWD) or Front-Wheel Drive (FWD) with CVT
Cvt Features:
Electronically controlled, adaptive shift logic, manual shift mode (likely available on some trims)
Cvt Fluid Type:
Nissan Genuine NS-2 CVT Fluid (or specified alternative for extreme temperatures, consult manual)
Cvt Fluid Capacity:
Approximately 4.5 US quarts (4.3 liters) for dry fill (check manual for exact capacity and procedure)
Length:
179.0 inches (4547 mm)
Width:
70.9 inches (1801 mm)
Height:
65.1 inches (1653 mm)
Wheelbase:
105.3 inches (2675 mm)
Curb Weight FWD:
Approximately 3366 lbs (1527 kg)
Curb Weight AWD:
Approximately 3516 lbs (1595 kg)
Gross Vehicle Weight Rating:
Varies by trim and drivetrain, refer to vehicle's certification label.
Cargo Volume Behind 2Nd Row:
25.1 cubic feet (711 liters)
Cargo Volume Max Behind 1St Row:
54.4 cubic feet (1540 liters)
NHTSA Front Impact Driver:
5 Stars (2009 Model Year)
NHTSA Front Impact Passenger:
5 Stars (2009 Model Year)
NHTSA Side Impact Front Seat:
5 Stars (2009 Model Year)
NHTSA Side Impact Rear Seat:
5 Stars (2009 Model Year)
NHTSA Rollover Resistance:
4 Stars (2009 Model Year)
ABS:
Standard Anti-lock Braking System (ABS)
Ebd:
Standard Electronic Brake-force Distribution (EBD)
Traction Control:
Standard Traction Control System (TCS)
Stability Control:
Standard Electronic Stability Control (ESC) / Vehicle Dynamic Control (VDC)
Airbags:
Front airbags, front side-impact airbags, roof-mounted curtain airbags for front and rear occupants
Seat Belts:
3-point seat belts with pretensioners and load limiters for all seating positions
Child Anchors:
LATCH (Lower Anchors and Tethers for Children) system
Audio System:
Standard AM/FM/CD audio system with auxiliary input jack. Optional Boseยฎ premium audio system available on higher trims.
Navigation:
Optional DVD-based navigation system available on select trims.
Rearview Camera:
Available on some higher trim levels.
Bluetooth:
Optional Bluetooth hands-free phone system available on select trims.
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, whichever comes first. Use of synthetic oil may allow extended intervals as per manual.
Tire Rotation Interval:
Every 5,000 miles (8,000 km)
Cvt Fluid Change Interval:
Typically around 60,000 miles (96,000 km) for severe use, or as specified by Nissan; consult manual for exact recommendation.
Air Filter Replacement:
Every 15,000 miles (24,000 km) or as needed based on driving conditions.
Power Steering Fluid Type:
Nissan Genuine Power Steering Fluid or equivalent Dexron III ATF (check manual for specific PN)
Engine Coolant Capacity:
Approximately 6.5 US quarts (6.2 liters) - consult manual for exact capacity and fill procedure.
Cvt Reliability:
Early generation CVTs can be sensitive to fluid maintenance and driving style. Overheating or lack of proper fluid can lead to premature failure. The manual will detail proper fluid checks and replacement procedures.
Vibration Issues:
Some owners have reported engine or drivetrain vibrations, which can be related to engine mounts, drive shafts, or CVT component wear. The manual will provide diagnostic steps.
Oil Consumption:
While not widespread, some engines can exhibit minor oil consumption. Regular checks and using the correct oil are crucial. The manual will cover oil consumption testing.
Nissan Crossover History:
Nissan has a strong history in the crossover segment, building on platforms like the X-Trail and Qashqai, which influenced models like the Rogue.
First Generation Introduction:
The first generation Nissan Rogue (S35) was introduced for the 2008 model year in North America, replacing the X-Trail in that market.
2009 Model Year Significance:
The 2009 model year represents the second year of the first generation, incorporating minor refinements from the initial launch.
Manufacturing Location:
Smryna, Tennessee, USA
