Motorcycle Segment:
Hyper sport / Sport touring, initially the fastest production motorcycle.
Key Competitors 1St Gen:
Kawasaki Ninja ZX-12R, Honda CBR1100XX Super Blackbird.
Aerodynamic Design:
Sleek, wind-tunnel-developed fairing for extreme high-speed stability and rider comfort.
Performance Focus:
Emphasis on straight-line speed, acceleration, and overall power delivery.
Long Distance Comfort:
Despite its performance, designed for greater rider comfort on longer journeys compared to typical sportbikes of the era.
Engine Operation:
Detailed explanation of the 1299cc inline-four engine, including lubrication, cooling, and ignition systems.
Fuel System:
Coverage of the fuel injection system, fuel tank, and fuel pump operation.
Transmission Operation:
Explanation of the 6-speed sequential gearbox, clutch operation, and gear selection.
Chassis And Suspension:
Information on frame construction, front telescopic forks (USD), and rear monoshock suspension.
Braking System:
Details on dual front hydraulic disc brakes and single rear hydraulic disc brake, including lever and pedal operation.
Electrical System:
Overview of lighting, starting, ignition, charging system (stator, regulator/rectifier), and battery.
Controls And Instruments:
Explanation of handlebar controls, dashboard layout, gauges, and warning lights.
Pre Ride Inspection:
Step-by-step guide for daily checks including tires, brakes, fluids, and lights.
Basic Maintenance:
Instructions for oil changes, filter replacement, chain lubrication and adjustment, tire pressure checks.
Storage Procedures:
Guidance on preparing the motorcycle for extended storage.
Troubleshooting Guide:
Basic troubleshooting tips for common operational issues.
Depth Level:
Owner-level maintenance, operation, and basic troubleshooting. Does not include in-depth mechanical repair procedures or diagnostic codes.
Engine Type:
Liquid-cooled, 4-stroke, DOHC, 16-valve, inline-four cylinder
Bore X Stroke:
81 mm x 63 mm
Compression Ratio:
11.0:1
Horsepower Crank:
Approximately 175 PS (172.6 hp) @ 9800 rpm (with RAM air effect)
Torque:
Approximately 140 Nm (103.3 lb-ft) @ 7000 rpm (with RAM air effect)
Top Speed:
Electronically limited to 300 km/h (186 mph) in most markets due to gentleman's agreement.
Fuel Delivery:
Fuel Injection (Suzuki Dual Throttle Valve - SDTV system)
Fuel Type:
Unleaded gasoline, 95-98 octane (RON/MON)
Fuel Tank Capacity:
21 Liters (5.5 US gal)
Transmission Type:
6-speed, constant mesh, sequential
Clutch Type:
Wet, multi-plate, back-torque limiter
Final Drive:
Sealed O-ring type, #530 chain
Overall Length:
Approx. 2,095 mm (82.5 in)
Overall Width:
Approx. 740 mm (29.1 in)
Overall Height:
Approx. 1,155 mm (45.5 in)
Wheelbase:
Approx. 1,485 mm (58.5 in)
Ground Clearance:
Approx. 130 mm (5.1 in)
Seat Height:
Approx. 830 mm (32.7 in)
Dry Weight:
Approx. 215 kg (474 lbs)
Curb Weight:
Approx. 245 kg (540 lbs) (with all fluids)
Safety Certifications:
CE marking and other regional safety compliance where applicable for original sale.
Braking Performance:
Dual 320mm front discs with 6-piston calipers, 260mm rear disc with 2-piston caliper for strong stopping power.
Handling Stability:
Advanced suspension tuning and aerodynamic design contribute to high-speed stability.
Rider Protection:
Full fairing for wind protection, integrated bodywork for rider safety.
Dashboard Features:
Analog tachometer and speedometer, LCD trip meter, clock, fuel gauge, and various indicator lights.
ABS:
Not available on the 1999-2007 model.
Traction Control:
Not available on the 1999-2007 model.
Connectivity Features:
N/A (pre-smartphone era for motorcycles)
Oil Change Interval:
Every 6,000 km (3,700 miles) or 6 months.
Air Filter Cleaning:
Every 6,000 km (3,700 miles) or 6 months; replace as needed.
Spark Plug Replacement:
Every 24,000 km (15,000 miles).
Chain Lubrication:
Every 1,000 km (600 miles) or after riding in rain/wet conditions.
Chain Adjustment Interval:
Every 1,000 km (600 miles).
Major Service Interval:
Refer to manual for specific mileage intervals for valve clearance checks, coolant replacement, etc. (e.g., 24,000 km / 15,000 miles).
Engine Oil Type:
SAE 10W-40 API SG or SH
Engine Oil Capacity:
Approx. 3.4 L (3.6 US qt) without filter, 3.8 L (4.0 US qt) with filter change.
Coolant Type:
Antifreeze coolant (ethylene glycol-based), Suzuki Super Coolant or equivalent.
Fork Oil Type:
SAE 10W (check specific manual for exact type and level)
Transmission Oil Type:
Suzuki Gear Oil (API GL-4, SAE 75W-90) or equivalent.
Common Wear Items:
Clutch plates, brake pads, chain and sprockets due to high performance demands.
Electrical Components:
Occasional issues with regulator/rectifier, though generally reliable.
Fuel Pump Reliability:
Generally robust, but regular use and proper fuel quality are recommended.
Suzuki Legacy:
Suzuki's history of performance-oriented motorcycles, building on its GSX-R lineage.
Hayabusa Genesis:
Introduced as the 'Ultimate Sportbike' to reclaim the title of the world's fastest production motorcycle.
1St Generation Timeline:
1999-2007, characterized by its groundbreaking speed and unique styling.
Impact On Industry:
Led to the 'gentlemen's agreement' among major manufacturers to electronically limit top speeds.
Production Start Year:
1999
Manufacturing Location:
Japan
