🏷️ Basic Information

Make:

Toyota

Model:

Corolla

Year:

2006

Generation Code:

E130

Chassis Code:

E130

👋 Introduction

Segment:

Compact Sedan/Hatchback

Competitors:

Honda Civic, Mazda3, Ford Focus, Nissan Sentra, Chevrolet Cobalt.

Reputation:

Known for reliability, fuel efficiency, and affordability. A perennial best-seller in its class.

Target Audience:

Budget-conscious buyers, families, daily commuters seeking dependable transportation.

Convenience:

Instant online access provides immediate support for repairs and maintenance, unlike traditional printed manuals.

Licensing:

Officially licensed content derived from OE (Original Equipment) materials ensures accuracy and completeness.

Cost Effectiveness:

Offers significant savings compared to dealership labor costs and potentially expensive printed manuals.

📋 Manual Details

Primary Coverage:

North America

Estimated Pages:

Varies by specific module, but comprehensive coverage typically spans over 2000 pages in OE factory format.

Type:

Service and Repair Manual Software

Language:

English

Format:

PDF Download (Online Access)

📖 Manual Coverage

Engine Mechanical:

Engine assembly, cylinder head, block, crankshaft, pistons, connecting rods, lubrication system, cooling system, fuel system (injection), exhaust system, timing system.

Engine Management:

Ignition system, emission control systems (EVAP, EGR), engine control unit (ECU) diagnostics and functions, sensor operations (MAF, O2, TPS, knock sensor), fuel trim control.

Transmission Manual:

Clutch operation, transmission internal components, gear selection, shift linkage, manual transmission fluid specifications and replacement.

Transmission Automatic:

Automatic transmission assembly, torque converter, valve body, hydraulic control systems, shift solenoids, automatic transmission fluid (ATF) specifications and replacement, electronic transmission control.

Drivetrain:

Front-wheel drive axle shafts, CV joints, differential operation, transaxle assembly.

Suspension:

Front suspension (struts, control arms, ball joints, stabilizer bar), rear suspension (torsion beam or independent, depending on specific model variant), shock absorbers, springs, bushings.

Steering:

Power steering system (hydraulic or electric), steering rack, tie rods, steering column, steering wheel, wheel alignment specifications.

Brakes:

Front and rear disc brake systems, brake calipers, pads, rotors, brake lines, master cylinder, ABS (Anti-lock Braking System) components and diagnostics, parking brake system.

Electrical System:

Battery, charging system (alternator, voltage regulator), starting system (starter motor), fuses, relays, lighting systems (headlights, taillights, interior lights), power windows, door locks, mirrors.

HVAC:

Heating, ventilation, and air conditioning (HVAC) system components (compressor, condenser, evaporator, blower motor, HVAC control module), refrigerant handling, cabin air filter replacement.

Body And Trim:

Exterior body panels, interior trim components, door mechanisms, hood, trunk lid, bumpers, glass replacement, weatherstripping.

Restraint Systems:

Airbag system components, seat belts, SRS warning light diagnostics.

Diagnostics:

OBD-II (On-Board Diagnostics) system, trouble codes (DTCs), diagnostic scan tool procedures, component testing procedures.

Maintenance:

Oil and filter changes, air filter replacement, cabin air filter replacement, spark plug replacement, fluid level checks and top-offs (coolant, brake fluid, power steering fluid, transmission fluid), tire rotation, brake inspection.

Troubleshooting:

Step-by-step diagnostic charts for common drivability issues, starting problems, electrical faults, HVAC malfunctions, brake complaints, and suspension noise.

Repair:

Detailed step-by-step instructions for component removal, installation, and adjustment for all major systems, including engine rebuild procedures, transmission overhauls, brake caliper replacement, suspension component replacement, and electrical component diagnosis and replacement.

Wiring Diagrams:

Comprehensive electrical wiring diagrams for all vehicle systems, including power distribution, ground points, and connector pinouts.

Specifications And Tolerances:

Precise torque specifications for all fasteners, measurement specifications for critical engine and suspension components, fluid capacities, and diagnostic parameter ranges.

Special Tools:

Identification and usage instructions for specialized tools required for specific repair procedures.

Depth:

Comprehensive, factory-level technical information suitable for professional technicians and advanced DIY enthusiasts. Covers everything from basic maintenance to complex system diagnostics and complete component overhauls.

📊 Manual Specifications

File Type:

PDF

Readability:

High resolution, clear text and diagrams. Optimized for digital viewing and printing.

Access Method:

Online access with download capability. No physical binding.

Digital Format:

Digital document, accessible via web browser on various devices.

⚙️ Engine Specifications

Engine Code And Type:

1ZZ-FE (1.8L DOHC 16-valve VVT-i Inline 4-cylinder)

Horsepower:

132 hp @ 6000 rpm

Torque:

123 lb-ft @ 4200 rpm

Injection Type:

Electronic Fuel Injection (EFI) with Sequential Port Injection

Fuel Requirement:

87 Octane Unleaded Gasoline

Coolant Capacity And Type:

Approx. 5.4 quarts (5.1 liters) of Toyota Super Long Life Coolant (Pink) or equivalent.

Oil Capacity And Type:

Approx. 4.4 quarts (4.2 liters) with filter change, using SAE 5W-30 API certified synthetic or conventional oil.

Spark Plugs:

Denso FXE20HR11 (Iridium Long Life) or equivalent.

🔧 Transmission

Transmission Type:

5-speed Manual Transmission

Transmission Type:

4-speed Automatic Transmission (ECT-i)

Automatic Features:

Electronically Controlled Transmission with intelligence (ECT-i) for optimized shift points and fuel economy.

Automatic Transmission Fluid Type:

Toyota ATF WS (World Standard) or equivalent.

Automatic Transmission Fluid Capacity:

Approx. 3.2 quarts (3.0 liters) for a drain and fill.

📐 Dimensions

Length:

177.0 in (4495 mm)

Width:

66.7 in (1695 mm)

Height:

57.7 in (1465 mm)

Wheelbase:

102.4 in (2600 mm)

Curb Weight Min:

Approx. 2756 lbs (1250 kg) for manual transmission models.

Curb Weight Max:

Approx. 2844 lbs (1290 kg) for automatic transmission models.

Gross Vehicle Weight Rating Gvwr:

Approx. 3880 lbs (1760 kg).

🛡️ Safety Features

NHTSA Frontal Impact Driver:

5 Stars

NHTSA Frontal Impact Passenger:

5 Stars

NHTSA Side Impact Front Driver:

5 Stars

NHTSA Side Impact Front Passenger:

5 Stars

NHTSA Side Impact Rear Passenger:

4 Stars

IIHS Frontal Offset:

Good

IIHS Side Impact:

Good

ABS:

Standard Anti-lock Braking System (ABS) with Electronic Brake-force Distribution (EBD).

Airbags:

Driver and front passenger airbags, front side airbags (optional on some trims), side curtain airbags (optional on some trims).

Seatbelts:

Front seat pretensioners and force limiters, all-position three-point seatbelts.

💡 Technology Features

Audio System:

Factory AM/FM/CD player with 4 or 6 speakers. Auxiliary input jack may be present on some higher trims.

Cruise Control:

Available on most trim levels.

Bluetooth:

Not commonly available on factory systems for this model year. Aftermarket integration is typical.

🔧 Maintenance

Oil And Filter Change:

Every 5,000 miles (8,000 km) or 6 months, whichever comes first, under normal driving conditions. Consult manual for severe driving conditions.

Engine Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on driving environment.

Cabin Air Filter Replacement:

Every 15,000 miles (24,000 km) or annually.

Spark Plug Replacement:

Every 100,000 miles (160,000 km) for iridium-tipped plugs.

Automatic Transmission Fluid Change:

Every 60,000 miles (96,000 km) is a common recommendation, but check manual for specific intervals and conditions.

Brake Fluid Type:

DOT 3 or DOT 4 brake fluid.

Power Steering Fluid Type:

Toyota Genuine Power Steering Fluid or equivalent Dexron II/III ATF.

Common Wear Items:

Typical wear items include brake pads and rotors, suspension bushings, wheel bearings, and exhaust components due to age and mileage.

Engine Specifics:

The 1ZZ-FE engine is generally robust, but oil consumption can increase with high mileage. Regular oil changes are crucial.

Transmission Specifics:

Automatic transmissions are generally reliable; maintaining proper fluid levels and condition is key. Occasional issues with solenoids or torque converters can occur.

📚 Vehicle History

Toyota Reputation:

Toyota is globally recognized for its commitment to quality, durability, and reliability (QDR).

Ninth Generation:

The 2006 model year falls within the ninth generation (E130) of the Toyota Corolla, introduced for the 2003 model year, featuring a significant redesign with a longer wheelbase and more refined styling.

Manufacturing Location:

Primarily manufactured in North America (USA and Canada) and Japan for the global market.

🏆 Awards & Recognition

Reliability Rankings:

Consistently ranked among the most reliable vehicles in its class by organizations like Consumer Reports and J.D. Power.
