2004 Toyota Matrix Service & Repair Manual Software

Regular price: $17.99
Sale price: $17.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Toyota Model: Matrix Year: 2004 Codes Platform: E130 Generation Generation: First Generation (XP10/XP90) 👋 Introduction Market Position Segment: Compact Hatchback / Wagon Target Audience: DIY...

22 people are viewing this right now

Type: Car

Vendor:

Sku: 47336

Tags: 2004 Car Cars Featured Matrix Toyota

Product variants

Description

🏷️ Basic Information

Identification

Make:

Toyota

Model:

Matrix

Year:

Codes

Platform:

Generation

Generation:

First Generation (XP10/XP90)

👋 Introduction

Market Position

Segment:

Compact Hatchback / Wagon

Target Audience:

DIY enthusiasts, independent repair shops, Toyota owners seeking comprehensive repair information.

Competitive Analysis

Competitors:

Honda Civic Hatchback, Ford Focus, Mazda3, Subaru Impreza.

Key Features

Licensing:

Officially licensed, derived from OE (Original Equipment) materials.

Vendor:

RepairSurge

Access Duration:

1-Year access with discounts for extensions.

Accessibility:

Accessible on PC, laptop, smartphone, tablet via web browser.

📋 Manual Details

Coverage Areas

Primary Coverage:

North America

Secondary Coverage:

Global Markets (where applicable)

Page Count

Estimated Pages:

1000+

Manual Type

Type:

Factory-Derived Service and Repair Manual

Language

Language:

English

Format

Format:

Digital Download (PDF)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Complete engine disassembly, assembly, diagnostics, and repair for all variants.

Engine Management:

Fuel injection, ignition system, emissions control, sensors, actuators, diagnostic trouble codes (DTCs).

Transmission:

Manual and automatic transmission overhaul, repair, fluid specifications, and diagnostics.

Drivetrain:

Front-wheel drive (FWD) and all-wheel drive (AWD) systems, CV axles, differentials, propeller shaft (AWD).

Suspension:

Front and rear suspension components, springs, shock absorbers, control arms, alignment specifications.

Steering:

Power steering system, steering rack, tie rods, column, linkage, diagnosis.

Brakes:

Disc brake systems (front and rear), ABS, brake fluid specifications, bleeding procedures, caliper and rotor replacement.

Electrical System:

Battery, charging system, starter, lighting, power windows, mirrors, locks, wipers, horns.

HVAC:

Air conditioning system, heater core, blower motor, climate control, refrigerant specifications.

Body And Frame:

Body panel removal and installation, interior trim, exterior trim, glass replacement, structural repair information.

Diagnostics:

Comprehensive diagnostic procedures for all major systems, including troubleshooting flowcharts and symptom-based diagnosis.

Wiring Diagrams:

Detailed electrical wiring schematics for all vehicle systems.

Procedures Included

Maintenance:

Scheduled maintenance tasks, fluid changes, filter replacements, spark plug replacement, belt inspection/replacement.

Repair:

Step-by-step repair instructions for a vast array of components and systems.

Troubleshooting:

Identification and resolution of common and uncommon vehicle issues.

Disassembly Assembly:

Detailed instructions for removing and reinstalling virtually every component.

Specifications:

Torque specifications, clearances, fluid capacities, pressures, electrical values.

Technical Depth

Depth:

Comprehensive (from basic maintenance to complete engine and transmission rebuilds, advanced diagnostics).

📊 Manual Specifications

File Format

File Type:

Searchability:

Searchable text content for quick information retrieval.

Print Quality:

High-resolution, printable pages.

Binding Type

Binding:

N/A (Digital Download)

Paper Type

Paper:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Code 1:

1ZZ-FE

Engine Type 1:

1.8L DOHC 16-valve inline-4 VVT-i (Variable Valve Timing with intelligence)

Displacement 1:

1794 cc

Bore X Stroke 1:

79.0 mm x 91.5 mm

Compression Ratio 1:

10.0:1

Horsepower 1:

130 hp @ 6000 rpm

Torque 1:

125 lb-ft @ 4200 rpm

Fuel System 1:

Electronic Fuel Injection (EFI)

Fuel Type 1:

Unleaded Gasoline (87 octane recommended)

Optional Engine

Engine Code 2:

2ZZ-GE

Engine Type 2:

1.8L DOHC 16-valve inline-4 VVTL-i (Variable Valve Timing and Lift intelligent)

Displacement 2:

1796 cc

Compression Ratio 2:

11.5:1

Horsepower 2:

180 hp @ 7800 rpm

Torque 2:

135 lb-ft @ 6800 rpm

Fuel System 2:

Electronic Fuel Injection (EFI)

Fuel Type 2:

Unleaded Gasoline (91 octane recommended for optimal performance)

🔧 Transmission

Standard

Transmission Type 1:

5-Speed Manual

Optional

Transmission Type 2:

4-Speed Automatic (with electronically controlled transmission - ECT)

Features

AWD Availability:

Optional All-Wheel Drive (AWD) available on select models (primarily with 1ZZ-FE engine).

📐 Dimensions

Exterior

Length:

Approx. 168.1 inches (4270 mm)

Width:

Approx. 66.7 inches (1695 mm)

Height:

Approx. 59.3 inches (1505 mm)

Wheelbase:

Approx. 102.4 inches (2600 mm)

Weights

Curb Weight Min:

Approx. 2730 lbs (1238 kg)

Curb Weight Max:

Approx. 2930 lbs (1330 kg)

🛡️ Safety Features

Ratings

NHTSA Front Impact Driver:

NHTSA Front Impact Passenger:

NHTSA Side Impact Front Seat:

NHTSA Side Impact Rear Seat:

IIHS Front Offset Crash:

Active Features

Standard Anti-lock Braking System (ABS)

Traction Control:

Available Traction Control System (TRAC) on some models.

Passive Features

Airbags Front:

Dual front SRS (Supplemental Restraint System) airbags.

Airbags Side:

Optional front side-impact airbags and side curtain airbags on some trims.

Seatbelts:

3-point seatbelts with pretensioners and force limiters in all seating positions.

💡 Technology Features

Infotainment

Audio System:

Standard AM/FM/CD player, optional premium audio with cassette, CD changer.

Display:

Basic digital clock and radio display.

Driver Assistance

Cruise Control:

Available cruise control on most models.

Connectivity

Auxiliary Input:

No factory auxiliary input in this model year.

🔧 Maintenance

Service Intervals

Oil Change:

Every 5,000 miles or 6 months, whichever comes first (or 10,000 miles / 12 months with synthetic oil, consult manual for details).

Air Filter Replacement:

Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles if driving in dusty conditions.

Cabin Air Filter Replacement:

Inspect every 15,000 miles, replace as needed. Replace every 30,000 miles or annually.

Spark Plug Replacement 1Zz:

Replace every 100,000 miles with Iridium-tipped spark plugs (e.g., Denso PK20TT or NGK Iridium).

Spark Plug Replacement 2Zz:

Replace every 60,000 miles with Iridium-tipped spark plugs (e.g., Denso PK20PR11 or NGK Iridium).

Fluid Specifications

Engine Oil:

SAE 5W-30, API Certified (ILSAC GF-4 or API SM recommended).

Engine Oil Capacity:

4.4 US quarts (4.2 liters) with filter for 1ZZ-FE; 4.5 US quarts (4.3 liters) with filter for 2ZZ-GE.

Coolant:

Toyota Super Long Life Coolant (SLLC) - Pink, or equivalent pre-mixed 50/50 ethylene glycol coolant.

Coolant Capacity:

Approx. 6.0 US quarts (5.7 liters) for 1ZZ-FE; Approx. 7.0 US quarts (6.6 liters) for 2ZZ-GE (including reservoir).

Transmission Fluid Manual:

API GL-4, SAE 75W-90 Gear Oil (Toyota Genuine Gear Oil or equivalent).

Transmission Fluid Automatic:

Toyota Genuine ATF WS (World Standard) or equivalent Dexron III/VI compatible fluid.

Brake Fluid:

DOT 3 or DOT 4.

Power Steering Fluid:

Toyota Genuine Power Steering Fluid or equivalent Dexron II/III ATF.

Known Issues

Oil Consumption 1Zz:

Some 1ZZ-FE engines are known for oil consumption due to piston ring issues. Regular oil level checks are crucial.

Clutch Wear:

Clutch wear can be accelerated by aggressive driving or frequent stop-and-go traffic.

Evaporative Emission Control System:

Faulty EVAP canister purge valve or vent solenoid can trigger check engine lights.

Rear Wheel Bearings:

Rear wheel bearings can develop noise and require replacement over time, particularly on AWD models.

📚 Vehicle History

Brand Heritage

Manufacturer:

Toyota Motor Corporation

Reputation:

Renowned for reliability, quality, and value.

Model Evolution

Introduction Year:

2000 (globally), 2003 (North America)

Platform Sharing:

Shared platform with the Toyota Corolla (E130).

Design Philosophy:

Compact, versatile hatchback/wagon aimed at younger buyers and those seeking utility.

Production

Manufacturing Location:

Canada (Toyota Motor Manufacturing Canada Inc. - TMMC)

🏆 Awards & Recognition

Recognitions

Consumer Guide:

Often cited by Consumer Guide as a Recommended Buy for its practicality and value.

Kelley Blue Book:

Consistently ranked well by Kelley Blue Book for its segment.
