🏷️ Basic Information

Make:

Toyota

Model:

Prius

Model Code:

ZVW52

Model Year:

2017

Production Start Date:

01/2017

Manual Part Number:

EM32E0E

👋 Introduction

Market Segment:

Compact/Mid-size Hybrid Sedan - positioned as a leading eco-friendly and technologically advanced vehicle.

Competitors:

Hyundai Ioniq, Chevrolet Volt, Honda Insight (depending on specific market focus).

Hybrid Powertrain:

Toyota's renowned Hybrid Synergy Drive system, offering exceptional fuel efficiency and smooth operation.

Aerodynamics:

Distinctive aerodynamic design contributing to fuel economy and stability.

Safety Technology:

Advanced driver-assistance systems (ADAS) and robust passive safety features.

📋 Manual Details

Coverage Scope:

Electrical Wiring Diagrams (EWD)

Language:

English

Manual Type:

Electrical Troubleshooting Manual

Format:

Digital (likely PDF)

📖 Manual Coverage

Electrical Systems:

Comprehensive coverage of all electrical systems including power distribution, lighting, infotainment, safety systems, hybrid system controls, engine management, HVAC, and body electronics.

Troubleshooting:

Detailed diagnostic procedures, symptom-based troubleshooting charts, and fault code interpretation for electrical faults.

Component Testing:

Guidelines for testing various electrical components, including sensors, actuators, relays, and modules, with expected values and testing methods.

Depth:

Advanced diagnostic and repair level, suitable for professional technicians and advanced DIY enthusiasts. Includes detailed circuit diagrams, connector pinouts, and wire harness routing.

📊 Manual Specifications

File Format:

PDF (Portable Document Format) - optimized for readability and searchability. Likely contains high-resolution schematics.

Print Quality:

Designed for high-quality printing of diagrams and text, ensuring clarity of fine details in wiring schematics.

Binding Type:

N/A (Digital Format)

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Type:

Inline 4-Cylinder, DOHC, 16-Valve, Atkinson Cycle with VVT-i

Engine Displacement:

1.8 Liters (1798 cc)

Engine Code:

2ZR-FXE

Combined System Horsepower:

121 hp (90 kW)

Gasoline Engine Horsepower:

98 hp (73 kW) @ 5200 rpm

Gasoline Engine Torque:

105 lb-ft (142 Nm) @ 3600 rpm

Electric Motor Type:

Permanent Magnet Synchronous Motor

Electric Motor Power:

72 hp (53 kW)

Fuel Type:

Unleaded Gasoline

Fuel Injection:

Electronic Fuel Injection (EFI) with Sequential Port Injection

Fuel Tank Capacity:

11.3 gallons (42.7 liters)

🔧 Transmission

Transmission Type:

Electronically Controlled Continuously Variable Transmission (ECVT) with Power Split Device

Drive Modes:

EV Mode, Power Mode, Eco Mode, Normal Mode

Hybrid Control:

Sophisticated computer control managing power flow between gasoline engine, electric motor(s), and battery.

📐 Dimensions

Length:

182.7 inches (4640 mm)

Width:

69.3 inches (1760 mm)

Height:

57.9 inches (1470 mm)

Wheelbase:

106.3 inches (2700 mm)

Curb Weight:

Approximately 3120 lbs (1415 kg)

🛡️ Safety Features

NHTSA Overall Rating:

5-Star (typically for this generation)

IIHS Top Safety Pick:

Likely received a Top Safety Pick or Top Safety Pick+ rating.

ABS:

Anti-lock Braking System

Traction Control:

Traction Control System (TRAC)

Vsc:

Vehicle Stability Control (VSC)

Adas Suite:

Toyota Safety Sense P (TSS-P) - likely included Pre-Collision System with Pedestrian Detection, Lane Departure Alert with Steering Assist, Automatic High Beams, and Dynamic Radar Cruise Control.

Airbags:

Driver and front passenger airbags, front side airbags, curtain shield airbags, driver's knee airbag.

Seatbelts:

Three-point seatbelts with pretensioners and force limiters.

Body Structure:

High-strength steel construction for enhanced crashworthiness.

💡 Technology Features

Display Screen:

7-inch touchscreen infotainment system with navigation (optional or standard depending on trim).

Connectivity:

Bluetooth, USB ports, Auxiliary audio input, voice recognition.

Audio System:

Premium JBL audio system may be available on higher trims.

Adas Features:

See Safety section for Toyota Safety Sense P (TSS-P) details.

Parking Assist:

Backup camera standard; parking sonar and parking assist brake (PKSB) available on some trims.

Smartphone Integration:

May offer basic smartphone integration like Pandora or iHeartRadio app compatibility, but typically not full Apple CarPlay or Android Auto on this generation.

🔧 Maintenance

Oil Change Interval:

Typically every 10,000 miles or 12 months, whichever comes first, using synthetic oil.

Hybrid Battery Warranty:

Typically 10 years or 150,000 miles, whichever comes first (check specific market warranty for exact details).

Inspect Hybrid System:

Regular inspections of the hybrid system components, including cooling systems and high-voltage cables, are recommended.

Engine Oil Type:

SAE 0W-20 API SN or SN Plus, ILSAC GF-5 or GF-6

Engine Oil Capacity:

4.4 US quarts (4.2 liters) with filter change

Coolant Type:

Toyota Super Long Life Coolant (Pink) or equivalent Asian vehicle specific coolant

Transmission Fluid Type:

Toyota Genuine ATF WS (for ECVT gear component)

Hybrid Battery Degradation:

While generally very reliable, long-term degradation of hybrid battery cells can occur, leading to reduced electric range and efficiency. This is a normal wear item.

Water Pump:

Occasional reports of water pump failures on the 2ZR-FXE engine.

Inverter Cooling Pump:

Potential issues with the inverter cooling pump, which can lead to overheating and system shutdown.

📚 Vehicle History

Brand Legacy:

Toyota is renowned for reliability, fuel efficiency, and pioneering hybrid technology with the original Prius.

Fourth Generation:

The ZVW52 represents the fourth generation of the Toyota Prius, introduced for the 2016 model year. This generation introduced a new platform (Toyota New Global Architecture - TNGA) and significant styling and powertrain enhancements.

Manufacturing Location:

Primarily Japan (e.g., Toyota City, Aichi Prefecture)

Sales Figures:

The Prius is one of the world's best-selling hybrid vehicles, with cumulative sales in the millions.

🏆 Awards & Recognition

Fuel Economy Awards:

Consistently recognized by EPA and other bodies for exceptional fuel economy.

Consumer Reports Reliability:

Generally scores well in reliability ratings from publications like Consumer Reports.

Emission Standards:

Meets or exceeds stringent emissions standards due to its hybrid powertrain.
