2009 Toyota Sienna Service & Repair Manual Software

$17.99
$17.99
🏷️ Basic Information Identification Make: Toyota Model: Sienna Year: 2009 Product Type: Service & Repair Manual Software Software Provider: RepairSurge Licensing: Officially Licensed Generation Generation: Second Generation (2004-2010) 👋 Introduction...
23 people are viewing this right now
Type: Car
Vendor:
Toyota
Sku: 47410
Tags: 2009 Car Cars Featured Sienna Toyota
2009 Toyota Sienna Service & Repair Manual Software
🏷️ Basic Information
Identification
Make:
Toyota
Model:
Sienna
Year:
2009
Product Type:
Service & Repair Manual Software
Software Provider:
RepairSurge
Licensing:
Officially Licensed
Generation
Generation:
Second Generation (2004-2010)
👋 Introduction
Market Position
Target Audience:
DIYers, independent repair shops, automotive enthusiasts
Competitive Analysis
Advantage:
Licensed OE data, convenient online access, comprehensive coverage, cost-effective compared to printed manuals
Key Features
Features:
Instant access, accurate information, detailed diagrams, step-by-step instructions, user-friendly interface
📋 Manual Details
Coverage Areas
Content Source:
OE (Original Equipment) Materials
Page Count
Estimated Pages:
Extensive (Specific count not provided, but described as comprehensive for all service and repair information)
Manual Type
Type:
Service and Repair Manual
Language
Language:
English
Format
Digital Format:
PDF Download (Web-based access)
Access Duration
Subscription Period:
1 Year (with discounts for additional years)
📖 Manual Coverage
Systems Covered
Powertrain:
Engine (including diagnostics, repair, maintenance), Drivetrain (e.g., AWD system, axles, differential)
Chassis:
Suspension (front and rear), Steering System, Brake System (including ABS and hydraulic components)
Body And Electrical:
Body Repair, Electrical System (wiring diagrams, component testing), HVAC (Heat, Air Conditioning)
Procedures Included
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, tire rotation
Component Repair:
Detailed step-by-step repair procedures for major components and systems
Diagnostics And Troubleshooting:
Troubleshooting charts, diagnostic codes (DTCs), symptom-based diagnostics
Technical Depth
Depth:
Comprehensive (Covers everything from basic maintenance to complete rebuilds and advanced diagnostics)
📊 Manual Specifications
File Format
Format:
Web-based PDF
Print Quality
Quality:
High-resolution, factory-derived data
Binding Type
Binding:
N/A (Digital Access)
Paper Type
Paper:
N/A (Digital Access)
Compatibility
Device Compatibility:
PC, Laptop, Smartphone, Tablet
Access Requirements
Requirements:
Internet connection, Web browser
⚙️ Engine Specifications
Primary Engine
Engine Type:
3.5L V6 DOHC 24-Valve VVT-i
Engine Code:
2GR-FE
Performance
Horsepower:
Approx. 266 hp @ 6200 rpm
Torque:
Approx. 245 lb-ft @ 4700 rpm
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline (87 Octane Recommended)
Cooling System
Coolant Type:
Toyota Super Long Life Coolant (SLLC) Pink
Lubrication
Oil Type:
SAE 0W-20
Oil Capacity:
Approx. 6.4 US quarts (6.1 Liters) with filter
🔧 Transmission
Standard
Type:
6-Speed Automatic (ECT-i)
Optional
Drive Type:
All-Wheel Drive (AWD) - Optional on most trims
Features
Transmission Fluid Type:
Toyota Genuine ATF WS (World Standard)
📐 Dimensions
Exterior
Length:
Approx. 200.0 inches
Width:
Approx. 77.4 inches
Height:
Approx. 68.5 inches
Wheelbase:
Approx. 119.3 inches
Weights
Curb Weight FWD:
Approx. 4,430 lbs
Curb Weight AWD:
Approx. 4,580 lbs
Cargo
Cargo Volume Behind 3Rd Row:
Approx. 19.0 cu ft
Cargo Volume Behind 2Nd Row:
Approx. 42.5 cu ft
Cargo Volume Behind 1St Row:
Approx. 98.2 cu ft
🛡️ Safety Features
Ratings
NHTSA Front Impact Driver:
5 Stars
NHTSA Front Impact Passenger:
5 Stars
NHTSA Side Impact Front Seat:
5 Stars
NHTSA Side Impact Rear Seat:
5 Stars
NHTSA Rollover:
4 Stars
Active Features
Active Safety:
Vehicle Stability Control (VSC), Traction Control (TRAC), Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA)
Passive Features
Passive Safety:
Driver and front passenger airbags, front and second-row side curtain airbags, front seat-mounted side airbags, active headrests
💡 Technology Features
Infotainment
Infotainment System:
Optional touchscreen DVD navigation system with JBL premium audio, Bluetooth connectivity (availability varies by trim and options).
Driver Assistance
Driver Assistance Features:
Backup camera (available on higher trims), cruise control.
Connectivity
Connectivity Options:
Auxiliary audio input jack, optional Bluetooth hands-free phone system.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 5,000 miles or 6 months (under normal driving conditions, check manual for severe conditions)
Tire Rotation Interval:
Every 5,000 miles
Engine Air Filter:
Inspect every 15,000 miles, replace as needed (typically around 30,000 miles)
Cabin Air Filter:
Replace every 15,000 miles or annually
Spark Plugs:
Iridium-tipped: 100,000-120,000 miles
Transmission Fluid Change:
Check condition regularly, typically around 60,000-100,000 miles based on driving conditions (consult manual for specific guidance)
Fluid Specifications
Engine Coolant:
Toyota Super Long Life Coolant (SLLC) - Pink (50/50 mix with distilled water)
Brake Fluid:
DOT 3
Power Steering Fluid:
Toyota Genuine Power Steering Fluid
Known Issues
Common Problems:
Premature wear of strut mounts, catalytic converter issues (less common on this year), potential for interior trim rattles, oil consumption (less prevalent than earlier generations).
Common Fixes:
Strut mount replacement, regular oil checks and top-offs, addressing interior rattles.
📚 Vehicle History
Brand Heritage
Brand Focus:
Toyota is renowned for reliability, quality, and long-term value.
Model Evolution
Model Lineage:
The Sienna has been Toyota's primary minivan offering in North America since its introduction in 1998, known for its car-like driving dynamics and practicality.
Production
Manufacturing Location:
Princeton, Indiana, USA
🏆 Awards & Recognition
Recognitions
Recalls:
NHTSA campaign number 10V-042 (potentially related to floor mat interference with accelerator pedal, check specific VIN for applicability).
Ratings
Kbb Consumer Ratings:
Consistently high consumer ratings for reliability and practicality.
