Target Audience:
DIY Enthusiasts, Independent Repair Shops, Tundra Owners
Advantage:
Convenient online access, factory-derived licensed information, cost-effective compared to printed manuals or dealership services
Feature 1:
Instant online access
Feature 2:
Comprehensive coverage of all major vehicle systems
Feature 3:
Licensed OE (Original Equipment) materials
Feature 4:
User-friendly interface with search capabilities
Engine:
Comprehensive Engine Mechanical and Electrical Systems, Diagnostics, Repair, and Overhaul
Drivetrain:
Front-Wheel Drive (FWD), Rear-Wheel Drive (RWD), Differential, Driveshafts, Axles
Transmission:
Automatic Transmission (AT) - Maintenance, Diagnostics, and Repair
Suspension:
Front and Rear Suspension Components, Alignment, Shock Absorbers, Springs
Steering:
Power Steering System, Steering Column, Tie Rods, Steering Gearbox
Brakes:
Front and Rear Brakes (Disc/Drum), ABS System, Brake Lines, Master Cylinder, Parking Brake
Electrical:
Full Electrical System Schematics, Wiring Diagrams, Lighting, Charging System, Starting System, Body Electrical Components
HVAC:
Heating, Ventilation, and Air Conditioning (HVAC) System Components, Refrigerant, Operation
Body:
Exterior Body Panels, Doors, Hood, Tailgate, Glass, Interior Trim
Maintenance:
Scheduled Maintenance, Oil Changes, Filter Replacements, Fluid Checks and Top-offs
Troubleshooting:
Diagnostic Flowcharts, Symptom-Based Troubleshooting, Fault Code Interpretation
Repair:
Component Removal, Installation, Adjustment, and Reassembly Procedures
Diagnostics:
OBD-II Diagnostics, Sensor Testing, Actuator Testing
Depth:
Comprehensive, including advanced diagnostics and component-level repairs
Print Readability:
High-resolution, suitable for printing
Binding:
N/A (Digital Download)
Paper Quality:
N/A (Digital Download)
Device Compatibility:
PC, Laptop, Smartphone, Tablet via Web Browser
License Type:
Officially Licensed
Access Duration:
1 Year (with renewal options)
Transmission Type Standard:
5-Speed Automatic (A750E/F)
Transmission Type Optional:
5-Speed Manual (RA02F) - Less common
Transmission Fluid Spec:
Toyota Genuine ATF WS (World Standard)
NHTSA Front Impact:
5-star driver, 4-star passenger (2006 model year data)
NHTSA Side Impact:
5-star driver, 5-star rear passenger (2006 model year data)
ABS:
Standard Anti-lock Braking System (ABS)
Airbags:
Driver and Front Passenger Airbags, Available Side Curtain Airbags (check specific trim)
Oil Change Interval:
Every 5,000 miles (8,000 km) or 6 months, or Every 7,500 miles (12,000 km) with synthetic oil (refer to manual for specifics)
Engine Air Filter Replacement:
Every 30,000 miles (48,000 km) or as needed based on inspection
Cabin Air Filter Replacement:
Every 15,000 miles (24,000 km) or annually
Transmission Fluid Change:
Check at 30,000 miles (48,000 km) and replace as needed, typically around 60,000-100,000 miles (96,000-160,000 km) for severe use.
Engine Oil Type:
SAE 5W-30 (API Certified)
Engine Oil Capacity 2Uz-Fe:
7.9 US quarts (7.5 Liters) with filter change
Coolant Type:
Toyota Super Long Life Coolant (Pink)
Issue 1:
Frame rust (particularly in areas with road salt use)
Issue 2:
Brake wear (front pads and rotors)
Issue 3:
Check for ABS actuator leaks or failures
Issue 4:
EGR valve cleaning/replacement
Brand Reputation:
Toyota is renowned for reliability, durability, and quality manufacturing.
First Generation Introduction:
The Tundra was first introduced for the 2000 model year, replacing the T100.
2006 Model Year Updates:
The 2006 model year represented the final year of the first generation, receiving minor updates and package refinements.
Manufacturing Location:
Princeton, Indiana, USA
