About this manual

This is the Troy-Bilt Technical Service and Repair Manual for Horse Model Tiller Transmissions (includes supplements). It covers both types of Four Speed and Two Speed transmissions used on Troy Bilt Horse Roto Tillers 1962 and up . Two Speed, sn.314150 and Below (1962 - 1978), Four Speed, sn.314151- (1978 - up). 165-Pages 6-Sections (revision 2 June-1984) Original printing was 1979 Section Index: Supplement Information General Information Things To Do, Know, And Watch Out For Transmission Disassembly and…

Useful for

• ✓ Service and maintenance procedures
• ✓ Troubleshooting and diagnostics
• ✓ Component removal and installation
• ✓ Repair workshop reference

Delivery: This is a digital repair manual. Open it on your computer, tablet or phone and print only the pages needed for the job.

Digital source file is retained from the original catalog record for fulfillment matching.
