2009 Volvo S80 Service & Repair Manual Software

Regular price: $17.99
Sale price: $17.99
Regular price
Unit price: per

🏷️ Basic Information Identification Make: Volvo Model: S80 Year: 2009 Generation Generation Designation: Second Generation (P3 Platform) Codes Chassis Code: AS/HS 👋 Introduction Market Position Positioning: Premium Executive Sedan, Competes...

21 people are viewing this right now

Type: Car

Vendor:

Sku: 332632

Tags: 2009 Car Cars Featured S80 Volvo

Product variants

Description

🏷️ Basic Information

Identification

Make:

Volvo

Model:

Year:

Generation

Generation Designation:

Second Generation (P3 Platform)

Codes

Chassis Code:

AS/HS

👋 Introduction

Market Position

Positioning:

Premium Executive Sedan, Competes with BMW 5 Series, Mercedes-Benz E-Class, Audi A6

Competitive Analysis

Differentiation:

Volvo's reputation for safety, Scandinavian design, comfort-oriented ride

Key Features

Platform:

P3 Platform, shared with other Volvo models

Design Philosophy:

Scandinavian elegance, minimalism, driver-centric cockpit

Target Audience

User Profile:

DIY enthusiasts, independent repair shops, Volvo owners seeking detailed repair info

📋 Manual Details

Coverage Areas

Primary Coverage:

Service, Repair, Maintenance, Diagnostics

Page Count

Estimated Page Count:

Extensive (Digital Content)

Manual Type

Type:

Service and Repair Manual Software

Language

Language:

English

Format

Format:

Online/Web-based Software

Access

Access Duration:

1 Year (with renewal options)

📖 Manual Coverage

Systems Covered

Powertrain:

Engine, Transmission, Drivetrain

Chassis:

Brakes, Suspension, Steering

Electrical:

Wiring Diagrams, Lighting, Body Electronics, Instrumentation

Body:

Bodywork, Interior Trim, HVAC

Comfort:

Climate Control (HVAC), Seats, Power Accessories

Procedures Included

Maintenance:

Scheduled Maintenance, Fluid Changes, Filter Replacements

Repair:

Component Replacement, System Overhauls

Diagnostics:

Troubleshooting Guides, DTC Interpretation, Electrical Diagnostics

Calibration:

Sensor Calibration, Module Programming (where applicable)

Technical Depth

Depth:

Factory-Level Detail, Comprehensive Procedures, Diagnostic Strategies

📊 Manual Specifications

File Format

File Type:

Proprietary Web-Based Application

Print Quality

Printability:

Printable Sections/Pages (Browser Dependent)

Binding Type

Binding:

N/A (Digital Access)

Paper Type

Paper Quality:

N/A (Digital Access)

Compatibility

Device Compatibility:

PC, Laptop, Smartphone, Tablet

Browser Compatibility:

Modern Web Browsers

Source Data

Data Origin:

Licensed OE (Original Equipment) Materials

⚙️ Engine Specifications

Primary Engine

Engine Code:

B6324S4 (Commonly found)

Engine Type:

3.2L Naturally Aspirated Inline-6

Displacement:

3192 cc (194.8 cu. in.)

Bore X Stroke:

84.0 mm x 96.0 mm (3.31 in. x 3.78 in.)

Compression Ratio:

10.8:1

Horsepower:

235 hp @ 6200 rpm

Torque:

236 lb-ft @ 3200 rpm

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI), Sequential Multi-port

Fuel Type:

Unleaded Gasoline (91 Octane Recommended)

Engine Features

Valve Train:

DOHC, 4 valves per cylinder, Variable Valve Timing (VVT)

Emissions Control:

Catalytic Converter, Secondary Air Injection (if applicable)

🔧 Transmission

Standard

Transmission Type:

6-Speed Geartronic Automatic

Transmission Model:

AW TF-80SC (Aisin Warner)

Optional

Optional Transmission:

None for the 3.2L engine in the US market; AWD was optional

Features

Drive System:

Front-Wheel Drive (FWD) standard, All-Wheel Drive (AWD) optional

Geartronic Functionality:

Manual shifting capability via shifter or steering wheel paddles

Fluid Specifications

Transmission Fluid Type:

JWS 3309 (or Volvo equivalent)

📐 Dimensions

Exterior

Length:

190.9 inches (4850 mm)

Width:

73.4 inches (1864 mm)

Height:

57.7 inches (1466 mm)

Wheelbase:

116.0 inches (2946 mm)

Front Track:

62.5 inches (1587 mm)

Rear Track:

61.7 inches (1567 mm)

Weights

Curb Weight Fw:

Approx. 3,748 lbs (1700 kg)

Curb Weight Aw:

Approx. 3,935 lbs (1785 kg)

Cargo

Trunk Volume:

14.9 cu. ft. (423 L)

🛡️ Safety Features

Ratings

NHTSA Overall:

5-Star (2009 Model Year)

IIHS Front Crash:

IIHS Side Crash:

IIHS Rear Crash:

Active Features

Braking System:

4-wheel Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist

Stability Control:

Electronic Stability Control (ESC), Traction Control System (TCS)

Passive Features

Airbags:

Front, Side, Curtain (Inflatable Curtain - IC), Driver's Side Knee Airbag

Seatbelts:

3-point inertia-reel seatbelts with pretensioners and load limiters

Structure:

Advanced High-Strength Steel Safety Cage

💡 Technology Features

Infotainment

Infotainment System:

Volvo Premium Sound System, optional Dynaudio system, SiriusXM Satellite Radio

Connectivity:

Bluetooth for hands-free calling and audio streaming, USB/Auxiliary input

Navigation:

Optional RTI (Road Traffic Information) Navigation System

Driver Assistance

Cruise Control:

Standard Cruise Control, Optional Adaptive Cruise Control (ACC)

Parking Assistance:

Optional Rear Parking Sensors, Optional Front Parking Sensors

Visibility:

Bi-Xenon Headlights with Active Bending Lights (ABL) on some trims, Rain-sensing wipers

Convenience

Keyless Entry:

Keyless Drive with Personal Car Communicator (PCC) optional

Seats:

Power-adjustable front seats with memory, Heated and Ventilated front seats (optional)

🔧 Maintenance

Service Intervals

Oil Change Interval:

10,000 miles or 12 months, whichever comes first (synthetic oil recommended)

Air Filter Replacement:

Every 30,000 miles or as needed

Cabin Filter Replacement:

Every 15,000 miles or 12 months

Spark Plug Replacement:

60,000 - 100,000 miles (depending on plug type)

Fluid Specifications

Engine Oil Type:

SAE 0W-30 Synthetic (API SM/SN or ILSAC GF-4/GF-5)

Coolant Type:

Volvo Long Life Coolant (or equivalent ethylene glycol-based coolant with corrosion inhibitors)

Brake Fluid Type:

DOT 4

Known Issues

Common Problems:

PCV system issues (oil leaks, rough idle), ABS/SAS module failures, power steering pump leaks, water pump leaks, electrical gremlins (sensor failures, warning lights)

Common Repair Procedures

Pcv System Maintenance:

Regular inspection and potential replacement of PCV diaphragm and hoses

ABS Sas Module Repair:

Diagnosis and potential replacement or repair of ABS/SAS module for brake system faults

📚 Vehicle History

Brand Heritage

Heritage:

Volvo's long-standing commitment to safety and robust engineering

Model Evolution

Second Gen Launch:

Introduced for the 2007 model year, representing a significant update over the first generation

Design Influences:

Designed under the ownership of Ford Motor Company, utilizing the P3 platform

Production

Manufacturing Locations:

Torslanda, Sweden; Ghent, Belgium

🏆 Awards & Recognition

Recognitions

IIHS Top Safety Pick:

Recognized by IIHS for safety performance

Ratings

Consumer Reports Reliability:

Varies by year and specific components; consult specific Consumer Reports data for 2009 S80
