Yamaha Road Star Warrior XV1700 2006-2010 Full Service & Repair Manual

$17.99
$17.99
🏷️ Basic Information Identification Make: Yamaha Model: Road Star Warrior Model Code: XV1700 Year: 2006-2010 👋 Introduction Market Position Vehicle Segment: Cruiser Motorcycle Target Audience: Performance-oriented cruiser enthusiasts, DIY mechanics,...
15 people are viewing this right now
Type: Motorcycle
Vendor:
Yamaha
Sku: 422743
Tags: 2006 2007 2008 2009 2010 Featured Motorcycle Motorcycles Road Star Warrior XV1700 Warrior Yamaha
Yamaha Road Star Warrior XV1700 2006-2010 Full Service & Repair Manual
🏷️ Basic Information
Identification
Make:
Yamaha
Model:
Road Star Warrior
Model Code:
XV1700
Year:
2006-2010
👋 Introduction
Market Position
Vehicle Segment:
Cruiser Motorcycle
Target Audience:
Performance-oriented cruiser enthusiasts, DIY mechanics, Yamaha owners
Competitive Analysis
Key Competitors:
Harley-Davidson V-Rod, Honda VTX1300, Kawasaki Vulcan 2000
Key Features
Manual Advantage:
Provides professional-grade diagnostic and repair information identical to dealership technicians.
Content Quality:
Detailed photos, exploded diagrams, and step-by-step instructions ensure accuracy.
📋 Manual Details
Coverage Areas
Covered Years:
2006, 2007, 2008, 2009, 2010
Primary Region:
Global
Page Count
Estimated Page Count:
Hundreds (specific count not provided, but described as extensive)
Manual Type
Type:
Factory Service and Repair Workshop Manual
Language
Language:
English (assumed based on product description)
Format
File Format:
PDF (Digital Download)
📖 Manual Coverage
Systems Covered
Mechanical Systems:
Engine, Transmission, Drivetrain, Suspension, Brakes, Chassis, Fuel System, Cooling System, Lubrication System, Exhaust System
Electrical Systems:
Ignition System, Lighting System, Starting System, Charging System, Instrumentation, Wiring Diagrams, EFI System Components
Procedures Included
Maintenance:
Scheduled maintenance, Oil changes, Filter replacements, Chain adjustment, Brake fluid flush, Coolant flush, Spark plug replacement, Air filter service
Troubleshooting:
Diagnostic procedures for common and uncommon faults, fault code interpretation (if applicable to model), step-by-step diagnostic trees
Repair:
Engine rebuild, Transmission overhaul, Clutch service, Fork seal replacement, Brake caliper rebuild, Electrical component diagnosis and replacement, Bodywork repair
Technical Depth
Depth:
Comprehensive Factory Level (covers everything from basic checks to full engine and transmission rebuilds)
📊 Manual Specifications
File Format
Digital Format:
PDF
Print Quality
Printability:
High-quality, printable pages (single or full manual)
Binding Type
Binding Type:
Not Applicable (Digital Download)
Paper Type
Paper Type:
Not Applicable (Digital Download)
Licensing
Usage License:
Lifetime Usage, Unlimited Devices, No Expiry
⚙️ Engine Specifications
Primary Engine
Engine Type:
V-Twin, 4-stroke, Air-cooled
Displacement:
1670cc (102 cubic inches)
Bore X Stroke:
97.0 mm x 113.0 mm
Compression Ratio:
8.5:1
Performance
Horsepower:
Approx. 90-100 HP (at crankshaft, depending on specific year/tuning)
Torque:
Approx. 100-110 lb-ft (at crankshaft, depending on specific year/tuning)
Fuel System
Fuel Delivery:
Electronic Fuel Injection (EFI)
Fuel Type:
Unleaded Gasoline, 90 Octane or higher recommended
Lubrication
Oil Type:
Yamalube 4 (or equivalent SAE 20W-40 API SG or higher)
Cooling
Cooling System:
Air-cooled
🔧 Transmission
Standard
Transmission Type:
5-speed, Constant Mesh
Features
Clutch Type:
Wet, Multiple Disc
Final Drive:
Belt Drive
📐 Dimensions
Exterior
Length:
Approx. 2340 mm (92.1 in)
Width:
Approx. 875 mm (34.4 in)
Height:
Approx. 1165 mm (45.9 in)
Weights
Dry Weight:
Approx. 256 kg (564 lbs)
Wet Weight:
Approx. 275 kg (606 lbs)
Wheels Tires
Front Tire Size:
120/70ZR18M/C (59W)
Rear Tire Size:
190/50ZR17M/C (75W)
Wheelbase:
Approx. 1685 mm (66.3 in)
🛡️ Safety Features
Ratings
Safety Ratings:
N/A (Motorcycle safety is typically assessed through handling dynamics and braking performance, not standardized crash ratings like cars)
Active Features
Braking System:
Hydraulic Dual Disc Front, Hydraulic Single Disc Rear
Suspension Front:
Telescopic Fork, 43 mm
Suspension Rear:
Swingarm, Adjustable Monoshock
💡 Technology Features
Infotainment
Instrumentation:
Analog speedometer and tachometer, digital odometer, trip meters, clock, fuel gauge, indicator lights.
Driver Assistance
ABS:
Not standard on all models; check specific year/trim.
Connectivity
Charging Port:
Optional or accessory available; not standard.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 3,000 miles or 6 months (refer to manual for precise Yamaha recommendations)
Spark Plug Replacement:
Refer to manual (typically around 10,000-15,000 miles for iridium plugs)
Belt Tension Check:
Every 3,000 miles or 6 months
Fluid Specifications
Brake Fluid Type:
DOT 4
Coolant Type:
Yamaha Motorcycles Genuine Coolant or Equivalent (Blue color, Ethylene Glycol based, 50/50 mix with distilled water)
Transmission Oil:
Refer to manual (often shares engine oil or has specific gear oil recommendations)
Known Issues
Common Wear Items:
Clutch wear, Belt wear (due to high torque), Fork seals, Battery issues, Regulator/Rectifier failure (on some models)
Common Issues
Efi Diagnostics:
Potential for sensor failures (throttle position, crank angle) or fuel pump issues, requiring thorough diagnosis covered in the manual.
📚 Vehicle History
Brand Heritage
Yamaha Motorcycle Legacy:
Yamaha has a long and distinguished history in motorcycle manufacturing, known for performance, innovation, and reliability across various categories including sportbikes, cruisers, and off-road vehicles.
Model Evolution
Road Star Lineage:
The Road Star line was Yamaha's answer to the American cruiser market, emphasizing torque-rich engines and classic styling. The Warrior model introduced a sportier, more performance-oriented edge to the cruiser segment.
Production
Production Period:
2002-2010 (XV1700 Warrior specifically from 2005 onwards with EFI upgrades)
🏆 Awards & Recognition
Recognitions
Motorcycle Press Reviews:
The Road Star Warrior was generally praised by motorcycle press for its strong performance, unique styling, and capable handling for a large cruiser.
