🏷️ Basic Information

Make:

Yamaha

Model:

Virago XV750

Model Variant:

XV750

Nickname:

Virago

Engine Code Range:

XV750

👋 Introduction

Target Audience:

DIY Mechanics, Professional Technicians, Motorcycle Enthusiasts, Restoration Projects

Segment:

Cruiser Motorcycle

Value Proposition:

Provides professional-level repair and maintenance information, saving costs compared to shop labor.

Convenience:

Instant download, printable pages, accessible on multiple devices.

Content Quality:

Comprehensive, detailed, with diagrams and illustrations.

📋 Manual Details

Applicable Model Years:

1981-1997

Estimated Page Count:

Extensive (specific count not provided, but typical for full service manuals)

Type:

Service Repair Manual

Professional Resource:

Designed for use by professional technicians and dealerships.

Language:

English

Format:

PDF

Downloadable:

Yes (Instant Download)

Operating Systems:

All Versions of Windows & Mac

Software Requirements:

Adobe PDF Reader

📖 Manual Coverage

Engine Systems:

Engine Removal/Installation, Fuel System, Lubrication System, Cooling System, Combustion System, Cylinder Head/Valves, Alternator/Starter Clutch, Crankcase/Piston/Cylinder, Crankshaft/Transmission/Balancer, Fuel Injection System

Drivetrain Systems:

Gearbox & Clutch, Transmission System

Chassis Systems:

Front Wheel and Steering System, Rear Wheel System, Fenders and Exhaust Pipe, Chassis, Suspension, Wheels & Tyres, Frame/Body Panels/Exhaust System

Braking Systems:

Braking System

Electrical Systems:

Electrical System, Battery/Charging System, Ignition System, Electric Starter, Lights/Meters/Switches, Wiring Diagrams

Body And Fixtures:

Body & Fixtures

Maintenance:

Periodic Checks & Adjustments, General Maintenance

Repair And Rebuild:

Complete Engine Rebuild, Transmission Overhaul, Suspension Repair, Brake System Service, Electrical Component Diagnosis and Repair, Bodywork and Fixture Repair

Troubleshooting:

Comprehensive Troubleshooting Guides

Electrical Diagnostics:

Wiring diagram interpretation, component testing (ignition, charging, starting systems).

Chassis Adjustments:

Steering head bearing adjustment, suspension adjustments (if applicable).

Diagnostic Capabilities:

Advanced Diagnostics, Component-Level Troubleshooting

Rebuild Scope:

Full Rebuild Procedures for Major Components

Detail Level:

Step-by-step instructions, diagrams, illustrations, pictures

📊 Manual Specifications

File Type:

PDF

Printability:

All pages are printable

Binding:

N/A (Digital Download)

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Engine Type:

V-Twin, Air-Cooled, 4-Stroke

Displacement:

748 cc (45.6 cu in)

Bore X Stroke:

83.0 mm x 69.2 mm (3.27 in x 2.72 in) (Typical for XV750 models)

Compression Ratio:

9.2:1 (Typical)

Fuel Delivery:

Carbureted or Fuel Injection (depending on specific year/sub-model)

Carburetor Details:

Dual Mikuni CV carburetors (typical for carbureted models)

Fuel Injection Details:

Digital Fuel Injection (DFI) (on later models)

Ignition Type:

Electronic Ignition (CDI)

Valve Configuration:

SOHC, 2 valves per cylinder

Type:

Wet Sump

🔧 Transmission

Type:

5-Speed Constant Mesh

Clutch Type:

Wet, Multiple-Disc

Final Drive:

Shaft Drive

📐 Dimensions

Overall Length:

Variable by year, approximately 2250 mm (88.6 in) (typical)

Dry Weight:

Approximately 184 kg (405 lbs) (typical)

Wet Weight:

Approximately 200 kg (441 lbs) (typical)

🛡️ Safety Features

Frame Construction:

Steel, Double Cradle Frame

💡 Technology Features

Instrumentation:

Analog speedometer, tachometer, fuel gauge, indicator lights.

Braking Assistance:

Disc brakes front and rear (specific configurations vary by year).

Charging System:

Alternator and battery charging system.

🔧 Maintenance

Oil Change Interval:

Refer to manual for specific mileage/time intervals (typically every 3,000-5,000 miles or annually)

Spark Plug Replacement:

Refer to manual for specific intervals (typically every 10,000-15,000 miles)

Engine Oil Type:

Yamaha recommends SAE 20W-40 API SE, SF or SG classification (verify in manual for exact spec)

Engine Oil Capacity:

Approximately 2.4 liters (2.5 US qt) with filter change (verify in manual)

Transmission Oil Type:

Yamalube Gear Oil recommended, or equivalent API GL-4 (verify in manual)

Brake Fluid Type:

DOT 3 or DOT 4 (verify in manual)

Coolant Type:

Not applicable for air-cooled engines.

Common Wear Items:

Clutch plates, brake pads, fork seals, exhaust gaskets, drive shaft splines.

Potential Electrical Issues:

Regulator/rectifier failure, stator issues (common in many vintage Japanese motorcycles).

Fuel System Maintenance:

Carburetor synchronization and cleaning, fuel filter replacement, particularly important for carbureted models.

📚 Vehicle History

Yamaha Motors History:

Yamaha Motor Corporation, founded in 1955, is renowned for its diverse product lines including motorcycles, marine products, and musical instruments.

Virago Lineage:

The Virago line, introduced in the early 1980s, represented Yamaha's foray into the cruiser market, emphasizing style, V-twin power, and shaft drive.

Xv750 Key Features Early:

Long wheelbase, low seat height, V-twin engine, shaft drive, often with classic styling cues.

Manufacturing Origin:

Primarily Japan, with potential assembly in other regions.
