1980-1995 Opel Vauxhall Astra & Belmont Workshop Service Repair Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

24 people are viewing this right now

Tipo: Car

Proveedor:

SKU: 149067

Etiquetas: 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 Astra Belmont Car Cars Opel Opel Vauxhall

Variantes de producto

Descripción

This workshop service repair manual covers the Astra and Belmont models produced between 1980 and 1995, encompassing generation codes Mk1 (T85) and Mk2 (T85/F). These compact family cars were renowned for their practical and spacious interiors, front-wheel-drive configuration, and economical operation, offering a comfortable ride and good handling for their class. Available in various body styles including 3-door and 5-door hatchbacks, a 4-door saloon (Belmont), an estate, and a convertible, these vehicles were a popular choice across Europe, particularly in the UK and Germany. Their design philosophy emphasized cost-effectiveness and widespread parts availability, making them a reliable and accessible option for many drivers. This comprehensive manual provides factory-level detail to assist both do-it-yourself enthusiasts and professional mechanics in maintaining and repairing the Astra/Belmont. It covers an extensive range of systems, including powertrain (engine, fuel, ignition, cooling, exhaust), drivetrain (transmissions, clutch, driveshafts), chassis (suspension, steering, brakes), electrical systems (wiring diagrams, components), and body and interior (HVAC, trim). Within its pages, you will find detailed procedures for scheduled maintenance, component removal and installation, overhaul, adjustment, and diagnostics. Technical specifications such as torque values, fluid capacities, and electrical data are also included, ensuring accurate and effective service for all variants of these vehicles.
