1980 Husqvarna 125 240 250 and 390 CR parts Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

The 1980 CR series, encompassing the CR 125, CR 240, CR 250, and CR 390 models, represents a significant era in off-road motorcycle engineering. These machines were celebrated for their...

17 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 119990

Etiquetas: 125 CR 1980 240 CR 250 CR 390 390 CR Chainsaws Home and Garden Husqvarna Motorcycle Power Equipment

Variantes de producto

Descripción

The 1980 CR series, encompassing the CR 125, CR 240, CR 250, and CR 390 models, represents a significant era in off-road motorcycle engineering. These machines were celebrated for their potent two-stroke engines, robust construction, and advanced suspension systems, establishing the brand as a formidable competitor in motocross and enduro racing. Renowned for their Swedish heritage of quality and performance, these models offered riders a distinct advantage with their powerful drivetrains and agile handling, making them highly sought after by enthusiasts and professionals alike. This Parts Manual provides comprehensive coverage for all components and assemblies of the 1980 CR models. Its purpose is to facilitate accurate part identification, cross-referencing, and ordering, essential for maintaining, restoring, or repairing these classic motorcycles. The manual features detailed exploded views, part numbers, and descriptions for the engine, transmission, chassis, suspension, brakes, and electrical systems, serving as an indispensable resource for owners, mechanics, and restoration specialists.
