Target Audience:
Suzuki QuadRunner owners, DIY mechanics, service technicians
Manual Comparison:
Offers a digital, instantly accessible alternative to potentially costly and hard-to-find paper manuals, with enhanced portability for on-site repairs.
Digital Advantage:
Instant download, no shipping, print-specific pages, mobile device compatibility for trailside repairs.
Content Scope:
Covers all aspects of repair, maintenance, and troubleshooting for the specified models.
Applicable Years:
1987, 1988, 1989
Covered Versions:
All versions of LT300E and LT-F300 QuadRunner ATVs
Estimated Page Count:
Varies by specific edition, typically 200-400 pages for comprehensive service manuals
Manual Type:
Comprehensive Service and Repair Manual, Owners Manual content included
Format:
Digital Download (PDF)
Engine:
Complete overhaul, troubleshooting, tuning, internal components, lubrication, cooling
Fuel System:
Carburetor disassembly, adjustment, cleaning, fuel pump, fuel tank, lines
Transmission Drive:
Transmission internal components, gear ratios, final drive, chain and sprockets, lubrication
Steering Suspension:
Steering system components, tie rods, steering shaft, wheel bearings, shock absorbers, suspension linkages
Electrical System:
Ignition system, lighting, battery, charging system (stator, regulator/rectifier), starter motor, wiring diagrams, troubleshooting
Bodywork Frame:
Frame inspection, body panel removal and installation, fenders, seats, racks
Brakes:
Hydraulic brake system, brake pads, rotors, calipers, brake lines, master cylinder
Intake Exhaust:
Air filter system, intake manifold, exhaust system, muffler
Maintenance:
Routine checks, fluid changes, filter replacements, lubrication, valve adjustments
Troubleshooting:
Diagnostic procedures for common and advanced issues across all systems
Repair Overhaul:
Detailed step-by-step instructions for engine, transmission, suspension, and electrical component rebuilds
Installation:
Engine removal/installation, component replacement procedures
Depth Of Information:
Comprehensive, covering basic maintenance to advanced engine and electrical diagnostics and repairs
File Format:
PDF (Portable Document Format)
Print Quality:
High-resolution scans, designed for clear printing of text and diagrams
Binding Type:
N/A (Digital Download)
Paper Type:
N/A (Digital Download)
Text Searchability:
Searchable text within PDF for quick information retrieval
Loss Damage Policy:
Lifetime Protection Policy for replacement if lost or damaged
Engine Type:
4-stroke, SOHC, Air-Cooled
Engine Displacement:
290 cc (approx. 17.7 cubic inches)
Bore X Stroke:
74.0 mm x 64.5 mm (approx. 2.91 x 2.54 inches)
Horsepower Rating:
Approximately 20-23 HP at 6500-7000 RPM (estimated based on similar models)
Torque Rating:
Approximately 17-19 lb-ft at 5000-5500 RPM (estimated based on similar models)
Carburetor Model:
Mikuni VM32SS (typical for this era, specific part number may vary)
Fuel Type:
Unleaded gasoline, minimum 87 octane
Oil Type:
SAE 10W-40 API SE, SF, or SG classification
Oil Capacity:
Approximately 1.5-1.8 liters (1.6-1.9 US qt) with filter change (refer to manual for exact capacity)
Cooling Method:
Air-Cooled
Overall Length:
Approximately 1950 mm (76.8 inches)
Overall Width:
Approximately 840 mm (33.1 inches)
Overall Height:
Approximately 1080 mm (42.5 inches)
Dry Weight:
Approximately 200-210 kg (440-463 lbs)
Fuel Tank Capacity:
Approximately 10.0 liters (2.6 US gallons)
Atv Safety Standards:
Meets relevant safety standards for ATVs of its era; specific ratings not typically issued for ATVs in the same manner as passenger cars.
Lighting:
Halogen headlight, taillight/brake light
Braking System:
Hydraulic disc brakes front and rear
Tires:
All-terrain tires for optimal grip and stability
Oil Change Interval:
Every 100 hours or annually (refer to manual for specific recommendations)
Air Filter Cleaning:
Every 50 hours or as needed based on operating conditions
Spark Plug Replacement:
Every 100 hours or annually (NGK DR8EA or equivalent)
Engine Oil Spec:
SAE 10W-40 API SE/SF/SG
Transmission Gear Oil Spec:
SAE 80W-90 API GL-4/GL-5
Brake Fluid Spec:
DOT 3 or DOT 4 (check reservoir cap, verify with manual)
Carburetor Issues:
Can be prone to clogging with debris, requiring regular cleaning and rebuilding. Diaphragm failure.
Electrical Issues:
Stator failures, regulator/rectifier issues, and aging wiring can lead to charging problems or intermittent ignition.
Suspension Wear:
Worn bushings and shock absorbers can degrade ride quality and handling over time.
Drive Shaft U Joints:
Can wear out, leading to clunking or vibration under load.
Suzuki Atv Legacy:
Suzuki has a long history in powersports, with the QuadRunner line being foundational in the development of modern ATVs.
Quadrunner Introduction:
The QuadRunner line debuted in the early 1980s, establishing Suzuki as a major player in the burgeoning ATV market. The LT300E/LT-F300 represented a step up in displacement and capability for their lineup.
Manufacturing Period:
Produced from the mid-1980s through the early 1990s, with the 300cc models specifically from 1987-1989 in this context.
