Polaris Sportsman 400 500 Xplorer 1996-2003 Service Repair Workshop Manual 1997 1998 1999 2000 2001 2002

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

This manual covers the Polaris Sportsman 400, Sportsman 500, and Xplorer models produced between 1996 and 2003. A pioneer in the ATV industry, these versatile machines were developed for a...

25 people are viewing this right now

Tipo: Atv

Proveedor:

SKU: 87930

Etiquetas: 1996 1997 1998 1999 2000 2001 2002 2003 ATV Misc Polaris Powersports Sportsman 400 Sportsman 500 Xplorer

Variantes de producto

Descripción

This manual covers the Polaris Sportsman 400, Sportsman 500, and Xplorer models produced between 1996 and 2003. A pioneer in the ATV industry, these versatile machines were developed for a range of uses, from trail riding to utility tasks. Known for their robust engineering and reliable performance, these ATVs feature a 4-stroke engine, automatic PVT transmission with selectable 2WD/AWD, and hydraulic disc brakes. The Sportsman series is celebrated for its comfort and capability, while the Xplorer models often offered enhanced trail performance. This comprehensive service, repair, and workshop manual provides in-depth technical information essential for the maintenance and repair of your ATV. It details procedures for all major systems, including the powertrain, chassis, and electrical components, as well as bodywork. The manual covers scheduled maintenance, troubleshooting common issues, detailed disassembly and assembly instructions, and critical technical specifications such as torque values and fluid capacities. This resource is designed to assist ATV owners, independent repair shops, and DIY mechanics in effectively maintaining and repairing these vehicles, ensuring optimal performance and longevity.

🏷️ Basic Information

Identification

Make:

Polaris

Model:

Sportsman 400 / 500 / Xplorer

Codes

Model Years Covered:

1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003

👋 Introduction

Market Position

Target User:

Polaris ATV owners, independent repair shops, and DIY mechanics.

Competitive Analysis

Value Proposition:

Provides in-depth technical information crucial for maintaining and repairing a wide range of Polaris Sportsman and Xplorer models, saving time and money on repairs.

Key Features

Illustrations:

Detailed, clear step-by-step illustrations and diagrams to aid in understanding complex procedures.

Completeness:

Covers a broad range of model years and specifications, offering a singular resource for these ATVs.

📋 Manual Details

Coverage Areas

Manual Scope:

Comprehensive Service, Repair, and Workshop Manual

Page Count

Estimated Page Count:

Likely over 500 pages (typical for comprehensive ATV service manuals of this era)

Manual Type

Manual Format Type:

Service/Repair/Workshop Manual

Language

Language:

English

Format

File Format:

PDF Download

📖 Manual Coverage

Systems Covered

Powertrain:

Engine, Transmission, Drivetrain (AWD/2WD systems), Final Drive

Chassis:

Suspension (Front and Rear), Steering, Brakes (Hydraulic Disc), Frame

Electrical:

Ignition System, Lighting, Battery, Charging System, Starting System, Wiring Diagrams, EFI (if applicable), Carburetor Systems

Bodywork:

Body Panels, Racks, Seat, Controls

Procedures Included

Maintenance:

Scheduled Maintenance, Oil Changes, Filter Replacements, Lubrication Points, Tire Pressure

Troubleshooting:

Diagnostic Procedures, Symptom-Based Troubleshooting Guides, Common Problems and Solutions

Repair:

Engine Rebuilds, Transmission Overhauls, Suspension Component Replacement, Brake System Servicing, Electrical Component Repair

Disassembly Assembly:

Detailed step-by-step instructions for component removal and installation.

Technical Depth

Diagnostic Capabilities:

Advanced diagnostics including ignition timing, carburetor adjustments, EFI system checks (if applicable).

Rebuild Instructions:

Comprehensive internal engine and transmission component specifications and rebuild procedures.

Specification Data:

Detailed torque specifications, clearances, fluid capacities, and electrical values.

📊 Manual Specifications

File Format

PDF Quality:

High-resolution, searchable text and clear, legible diagrams.

Print Quality

Printable:

Yes, designed for printing specific sections or the entire manual.

Binding Type

Binding:

N/A (Digital PDF Download)

Paper Type

Paper Recommendation:

N/A (Digital PDF Download, recommend durable paper if printing for shop use)

⚙️ Engine Specifications

Primary Engine

Engine Type:

4-stroke, Single Cylinder (likely Liquid or Air-Cooled variations)

Displacement 400:

Approx. 375cc - 400cc (specifics vary by sub-model and year)

Displacement 500:

Approx. 499cc - 500cc (specifics vary by sub-model and year)

Performance

Horsepower Range:

Typically in the 20-30 HP range, depending on engine size and tuning.

Torque Range:

Provides strong low-end torque suitable for trail riding and utility tasks.

Fuel System

Fuel Delivery 400:

Carbureted (e.g., Mikuni VM Series)

Fuel Delivery 500:

Primarily Carbureted, with some later models potentially featuring EFI (Electronic Fuel Injection).

🔧 Transmission

Standard

Transmission Type:

Automatic PVT (Polaris Variable Transmission) with Hi/Lo Range and Reverse

Optional

Gear Ratios:

Manual adjustment of CVT belt engagement and variator ratios for optimal power delivery.

Features

Drivetrain Modes:

Selectable 2WD/AWD operation (On-Demand AWD)

Cooling:

Likely belt-driven cooling fan for CVT, engine cooling varies (air/liquid).

📐 Dimensions

Exterior

Length Typical:

Approximately 80-83 inches

Width Typical:

Approximately 45-46 inches

Height Typical:

Approximately 45-47 inches

Weights

Dry Weight Typical:

Approximately 550-650 lbs

Ground Clearance Typical:

Approximately 9-11 inches

Cargo

Rack Capacity Front:

Typically around 100 lbs

Rack Capacity Rear:

Typically around 200 lbs

🛡️ Safety Features

Ratings

Atv Safety Standards:

Meets applicable ANSI/SVIA standards for ATVs of its era.

Active Features

Braking System:

Hydraulic disc brakes on all wheels, providing strong stopping power.

Lighting:

Halogen headlights and taillight for visibility.

Passive Features

Handlebars:

Ergonomically designed handlebars with integrated thumb throttle and hand grips for control.

Footwells:

Full floorboards with integrated heel guards for rider foot protection.

💡 Technology Features

Infotainment

Infotainment System:

Not applicable for these utility-focused ATVs of this era. Basic instrumentation (speedometer, odometer, neutral/gear indicators).

Driver Assistance

Traction Control:

On-Demand AWD provides intelligent traction control by engaging front wheels when rear wheel slip is detected.

Connectivity

Diagnostic Ports:

Diagnostic capabilities may be limited to on-board fault codes for EFI models, primarily requiring manual troubleshooting for carbureted versions.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 100 hours or annually, whichever comes first (consult manual for exact specification).

Spark Plug Replacement:

Recommended every 250-500 hours or as needed based on inspection.

Air Filter Cleaning:

Recommended every 50 hours or more frequently in dusty conditions.

Fluid Specifications

Engine Oil Type:

Typically SAE 10W-40 or 20W-50 motorcycle-specific or ATV oil, API SG or higher.

Engine Oil Capacity:

Approximately 1.5 - 2.5 quarts (consult manual for exact fill)

Brake Fluid Type:

DOT 3 or DOT 4 hydraulic brake fluid.

Transmission Fluid:

Typically a specific Polaris-branded ATV transmission fluid or equivalent for PVT systems.

Known Issues

Cvt Belt Wear:

Regular inspection and replacement of the CVT belt are critical for proper operation and to prevent damage.

Carburetor Cleaning:

Carburetors may require periodic cleaning and adjustment, especially if the ATV sits for extended periods.

Electrical Connections:

Corrosion or looseness in electrical connections can lead to intermittent issues.

Suspension Bushings:

Wear in suspension bushings can lead to play and reduced handling performance.

📚 Vehicle History

Brand Heritage

Polaris Atv Legacy:

Polaris is a pioneer in the ATV industry, known for developing the first mass-produced ATVs in North America.

Model Evolution

Sportsman Series:

The Sportsman line has long been Polaris's flagship utility ATV, emphasizing comfort, capability, and versatility. These models represent a key period in its development.

Xplorer Series:

The Xplorer models typically focused on enhanced trail riding and sportier performance compared to the base Sportsman, often featuring more suspension travel and sport-oriented styling.

Production

Manufacturing Location:

Primarily manufactured in the USA by Polaris.

🏆 Awards & Recognition

Recognitions

Atv Industry Accolades:

Polaris ATVs, including the Sportsman line, have consistently received positive reviews and industry recognition for performance, durability, and innovation over the years.
