Suzuki RM85 2002-2012 Workshop Service Repair Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

15 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 157415

Etiquetas: 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 Motorcycle Motorcycles RM Series RM85 Suzuki

Variantes de producto

Descripción

This manual covers the RM85, an off-road motorcycle designed for motocross racing and recreational riding. Produced from 2002 through 2012, the RM85 is recognized for its lightweight chassis, powerful liquid-cooled two-stroke engine, and adjustable suspension, making it a competitive option in junior motocross. The long heritage in racing is evident in the RM85's engineering, which focuses on performance and rider control, placing it alongside other key models in the competitive entry-level to intermediate motocross segment. This workshop service repair manual provides comprehensive English-language guidance for maintaining and repairing the RM85. It details procedures for engine and transmission overhauls, fuel and ignition system servicing, electrical system diagnostics, and maintenance of the chassis, suspension, brakes, and wheels. The manual is structured to assist mechanical technicians and experienced enthusiasts with everything from routine tune-ups and common wear item replacement to advanced component-level repairs and full rebuilds, ensuring the optimal performance and longevity of the motorcycle.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

Model Years Covered:

2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012

Vehicle Type:

Off-Road Motorcycle (Motocross)

Codes

Chassis Codes:

Specific chassis codes for each year are detailed within the manual.

👋 Introduction

Market Position

Market Segment:

Entry-level to intermediate motocross racing and recreational off-road riding for youth riders.

Competitive Analysis

Competitors:

Kawasaki KX85, Yamaha YZ85, KTM 85 SX.

Key Features

Rm85 Highlights:

Lightweight chassis, powerful two-stroke engine, adjustable suspension, designed for competitive junior motocross racing.

Manual Purpose

Manual Objective:

To provide technicians and owners with accurate and comprehensive information for maintaining and repairing the Suzuki RM85.

Manual Value Proposition

Owner Benefit:

Enables owners to perform maintenance and repairs knowledgeably, saving time and money compared to dealership service.

📋 Manual Details

Coverage Areas

General Coverage:

Comprehensive repair and overhaul of Suzuki RM85 motorcycles from 2002 to 2012.

Page Count

Page Count:

200 pages

Manual Type

Manual Type:

Workshop Service Repair Manual

Language

Language:

English

Format

Format:

📖 Manual Coverage

Systems Covered

Engine:

Complete engine disassembly, assembly, repair, and overhaul.

Transmission:

Detailed procedures for transmission removal, inspection, repair, and installation.

Fuel System:

Carburetor adjustment, cleaning, and rebuilding; fuel tank and line maintenance.

Ignition System:

Ignition timing, spark plug specifications, CDI unit troubleshooting.

Lubrication System:

Two-stroke oil injection system maintenance, oil type specifications.

Exhaust System:

Exhaust pipe and silencer removal, inspection, and reassembly.

Electrical System:

Wiring diagrams, lighting, charging system (if applicable), component testing.

Bodywork:

Fairing removal and installation, seat, handlebars, footpegs.

Suspension:

Front forks (upside-down telescopic) and rear shock absorber (monoshock) maintenance, fluid changes, and adjustments.

Brakes:

Hydraulic disc brake systems (front and rear) inspection, pad replacement, fluid bleeding, caliper and master cylinder service.

Wheels And Tires:

Wheel bearing inspection and replacement, tire pressure recommendations, rim maintenance.

Cooling System:

Radiator, hoses, and coolant maintenance and checks.

Procedures Included

Routine Maintenance:

Tune-ups, oil changes (transmission oil), air filter cleaning/replacement, chain adjustment.

Troubleshooting:

Diagnostic procedures for common issues and component failures.

Repair Procedures:

Step-by-step instructions for component repair and replacement.

Overhaul Procedures:

Detailed instructions for complete engine and component rebuilds.

Assembly Disassembly:

Comprehensive guidance on taking apart and reassembling various motorcycle systems.

Special Tool Usage:

Identification and usage instructions for specialized Suzuki tools.

Engine And Transmission Disassembly:

Extensive coverage of engine and transmission disassembly for in-depth repairs.

Technical Depth

Depth Level:

Advanced diagnostics, complete engine and transmission rebuilds, component-level repair.

Target Audience:

Mechanical technicians and experienced DIY enthusiasts familiar with general automobile/motorcycle practices.

📊 Manual Specifications

File Format

File Format:

Print Quality

Printability:

Yes, printable

Binding Type

Binding Type:

Not Applicable (Digital PDF)

Paper Type

Paper Type:

Not Applicable (Digital PDF)

Content Clarity

Warning Caution Notes:

Manual emphasizes critical information through 'WARNING', 'CAUTION', and 'NOTE' designations.

Accuracy Statement:

Endeavored to ensure accuracy and completeness for all necessary repair instructions.

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, 2-stroke, reed-valve induction

Displacement:

84.7 cc

Bore X Stroke:

48.0 mm x 46.8 mm (Refer to manual for exact year-specific tolerances)

Compression Ratio:

9.9:1 (Approximate, refer to manual for exact specification)

Performance

Horsepower:

Approx. 17.9 HP @ 11,000 RPM (Varies slightly by year, refer to manual)

Torque:

Approx. 7.8 lb-ft @ 10,500 RPM (Varies slightly by year, refer to manual)

Fuel System

Carburetor Model:

Mikuni VM28SS

Fuel Type:

Unleaded gasoline (minimum 91 octane recommended)

Two Stroke Oil Type:

API TC Classification, JASO FD or FD compliant 2-stroke engine oil (refer to manual for specific recommendations and mixing ratios if applicable).

🔧 Transmission

Standard

Transmission Type:

6-speed constant mesh

Features

Clutch Type:

Wet, multi-plate

Transmission Oil Type:

Suzuki Motorcycle Gear Oil (or equivalent SAE 80 API GL-4, refer to manual for specific capacity and type).

📐 Dimensions

Weights

Dry Weight:

Approximately 75 kg (165 lbs) (Varies slightly by year, refer to manual)

Fuel Tank Capacity:

5.0 L (1.3 US gal) (Refer to manual for exact capacity)

Exterior

Overall Length:

Approx. 1835 mm (72.2 in) (Refer to manual for exact year-specific dimensions)

Overall Width:

Approx. 755 mm (29.7 in) (Refer to manual for exact year-specific dimensions)

Overall Height:

Approx. 1100 mm (43.3 in) (Refer to manual for exact year-specific dimensions)

Wheelbase:

Approx. 1240 mm (48.8 in) (Refer to manual for exact year-specific dimensions)

Ground Clearance:

Approx. 315 mm (12.4 in) (Refer to manual for exact year-specific dimensions)

Seat Height:

Approx. 850 mm (33.5 in) (Refer to manual for exact year-specific dimensions)

🛡️ Safety Features

Ratings

Safety Standards:

Designed to meet relevant motocross racing and off-road safety regulations for youth riders. Specific certifications are not typically rated like street vehicles.

Active Features

Braking System:

Powerful hydraulic disc brakes front and rear for effective stopping power.

Passive Features

Chassis Design:

Durable frame designed for off-road abuse and rider control.

💡 Technology Features

Infotainment

Infotainment Systems:

Not Applicable (This is a dedicated motocross racing machine with no infotainment features).

Driver Assistance

Driver Assistance Systems:

Not Applicable (Focus is on rider control and mechanical performance, not electronic driver assistance).

🔧 Maintenance

Service Intervals

General Maintenance Interval:

Refer to manual for specific intervals for engine tune-ups, transmission oil changes, chain lubrication, and air filter cleaning (typically based on operating hours for off-road use).

Fluid Specifications

Transmission Oil Capacity:

Approx. 0.65 L (refer to manual for exact capacity and specific Suzuki recommended oil)

Fork Oil Type And Level:

Specific fork oil viscosity and level are critical for proper suspension performance and are detailed in the manual (e.g., Showa SS-8 or equivalent).

Known Issues

Common Wear Items:

Piston rings, clutch plates, and wheel bearings are common wear items on high-performance two-stroke motocross bikes and require regular inspection and replacement.

Carburetor Performance:

Proper carburetor jetting and cleaning are crucial for optimal engine performance and preventing bogging or fouling, especially with varying altitudes and temperatures.

Suspension Maintenance:

Regular fork seal checks and rear shock service are important to maintain suspension action and prevent leaks.

📚 Vehicle History

Brand Heritage

Suzuki Motorcycle Heritage:

Suzuki has a long and successful history in motorcycle racing, particularly in motocross and Grand Prix events, known for its innovative two-stroke technology.

Model Evolution

Rm85 Lineage:

The RM85 is part of Suzuki's long-standing RM (Racing Machine) series, evolving from earlier 80cc and 85cc motocross models, consistently optimized for junior competition.

Production

Production Period:

The RM85 has been in continuous production, with updates to suspension, engine tuning, and aesthetics, covering the 2002-2012 period as specified.

🏆 Awards & Recognition

Recognitions

Racing Success:

The RM85 platform has historically been a competitive machine in junior motocross championships worldwide.
