Vehicle Segment:
Sport/GT Scooter (Grand Turismo Scooter)
Competitors:
Piaggio X8, Yamaha XMAX, Suzuki Burgman, Kymco People GT series
Handling:
Known for agile handling and sporty ride characteristics.
Comfort:
Designed for both urban commuting and longer-distance touring with comfortable seating and good weather protection.
Storage:
Generous under-seat storage compartment suitable for helmets and other items.
Engine Overhaul:
Complete disassembly, inspection, repair, and reassembly of engine components.
Fuel System:
Carburetor/Fuel Injection systems, fuel pump, fuel lines, fuel tank maintenance.
Cooling System:
Radiator, coolant flow, thermostat, fan operation, coolant specifications.
Ignition System:
Spark plugs, ignition coils, CDI unit, timing.
Transmission Drivetrain:
Automatic transmission (CVT), clutch operation, drive belt, variator, torque converter.
Suspension System:
Front fork (telescopic), rear shock absorber, linkage, tuning.
Braking System:
Front and rear disc brakes, hydraulic lines, calipers, master cylinders, brake fluid specifications and bleeding procedures.
Electrical System:
Battery, charging system (stator, regulator/rectifier), starter motor, lighting (headlight, taillight, turn signals), wiring diagrams, fuses, ECU functions.
Body Panels Trim:
Removal and installation of fairings, seat, storage compartments, bodywork components.
Wheels Tires:
Wheel bearing maintenance, tire pressure recommendations, wheel removal/installation.
Routine Maintenance:
Oil changes, filter replacements, spark plug checks, drive belt inspection/replacement, brake pad checks.
Troubleshooting:
Diagnostic flowcharts for common problems, symptom analysis, error code interpretation (if applicable).
Disassembly Assembly:
Step-by-step instructions for component removal and reinstallation.
Cleaning Reinstallation:
Specific instructions for cleaning components during overhaul.
Torque Specifications:
Critical torque values for fasteners across all systems.
Depth:
Comprehensive, suitable for professional technicians and advanced DIY mechanics.
Target Audience:
Professional technicians and do-it-yourself mechanics with basic electrical and mechanical knowledge.
Engine Type 125:
Four-stroke, single-cylinder, liquid-cooled
Displacement 125:
124cc (Approximate, exact spec depends on specific engine code)
Bore X Stroke 125:
Specific to engine variant, detailed in manual
Compression Ratio 125:
Specific to engine variant, detailed in manual
Engine Type 200:
Four-stroke, single-cylinder, liquid-cooled
Displacement 200:
183cc (Approximate, exact spec depends on specific engine code)
Bore X Stroke 200:
Specific to engine variant, detailed in manual
Compression Ratio 200:
Specific to engine variant, detailed in manual
Horsepower 125:
Typically around 15-17 HP at specified RPM (exact figure depends on market and tuning)
Torque 125:
Specific to engine variant, detailed in manual
Horsepower 200:
Typically around 18-20 HP at specified RPM (exact figure depends on market and tuning)
Torque 200:
Specific to engine variant, detailed in manual
Fuel Delivery:
Likely a carburetor for 125cc and possibly fuel injection for the 200cc variant, or both carb variants depending on market. Manual will specify.
Fuel Type:
Unleaded Gasoline
Fuel Tank Capacity:
Approx. 9-10 Liters (specific capacity detailed in manual)
Length:
Approx. 2000 mm (specific dimensions detailed in manual)
Width:
Approx. 740 mm (specific dimensions detailed in manual)
Height:
Approx. 1370 mm (specific dimensions detailed in manual)
Dry Weight 125:
Approx. 140-150 kg (specific weight detailed in manual)
Wet Weight 125:
Approx. 150-160 kg (specific weight detailed in manual)
Dry Weight 200:
Approx. 145-155 kg (specific weight detailed in manual)
Wet Weight 200:
Approx. 155-165 kg (specific weight detailed in manual)
Max Load Capacity:
Specific capacity detailed in manual
Instrument Cluster:
Digital and analog display including speedometer, tachometer, fuel gauge, odometer, clock, and indicator lights.
ABS Option:
ABS was an optional feature on some models; manual will cover its operation and diagnostics.
Engine Oil Change:
Typically every 3,000 - 5,000 km or annually, as specified in the manual.
Air Filter Cleaning Replacement:
Check every 3,000 km, replace as needed based on condition.
Spark Plug Check Replacement:
Check at 6,000 km intervals, replace per manual recommendations.
Drive Belt Inspection Replacement:
Inspect at 6,000 km, replace typically around 12,000 - 18,000 km or as per wear indicators.
Brake Fluid Flush:
Recommended every 2 years or as per manual.
Engine Oil Type:
SAE 10W-40 or 15W-50 API SG or higher (refer to manual for precise specification).
Engine Oil Capacity:
Approx. 1.0 - 1.2 Liters (refer to manual for exact capacity).
Coolant Type:
Ethylene glycol based coolant, mix of 50% coolant and 50% distilled water.
Brake Fluid Type:
DOT 4 hydraulic brake fluid.
Electrical Connections:
Corrosion or loose connections in wiring harness can cause intermittent electrical issues. Manual provides diagnostic steps.
Water Pump Seal:
Leaking water pump seal is a potential issue that requires replacement. Manual covers seal replacement procedure.
Fuel Injector Clogging:
On fuel-injected models, injector clogging can lead to poor running. Manual details cleaning procedures.
