2005 Kawasaki KAF400 Mule 600 610 4x4 Service Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

🏷️ Basic Information Identification Make: Kawasaki Model: Mule Model Code: KAF400 Variant: 600 610 4x4 Year: 2005 Generation: First Generation Mule 600/610 Series 📋 Manual Details Document Info Manual Type:...

18 people are viewing this right now

Tipo: Utility Vehicle

Proveedor:

SKU: 4989

Etiquetas: 2005 600 Series Agriculture Case KAF400 Kawasaki Mule 600 Mule 610 Tractors Utility Vehicle

Variantes de producto

Descripción

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

Model Code:

KAF400

Variant:

600 610 4x4

Year:

Generation:

First Generation Mule 600/610 Series

📋 Manual Details

Document Info

Manual Type:

Factory Service Manual

Manual Source:

Language:

English

Page Count:

Format:

Content Overview

Covered Systems:

• General Information

• Periodic Information

• Fuel System

• Engine Top End

• Converter System

• Engine Lubrication

• Engine Removal/Installation

• Engine Bottom End

• Transmission

• Wheels/Tires

• Final Drive

• Brakes

• Suspension

• Steering

• Frame

• Electrical System

• Appendix

⚙️ Engine Specifications

Engine Details

Engine Type:

4-stroke, OHV, V-twin, gasoline

Displacement:

395 cc

Bore X Stroke:

61.0 x 68.0 mm

Compression Ratio:

9.2:1

Carburetor:

Mikuni BNS34

Ignition:

Cooling System:

Forced air-cooled

🔧 Transmission

Drivetrain

Type:

Continuously Variable Transmission (CVT) with Hi/Lo range and Reverse

Drive System:

Shaft driven 4x4

Final Drive:

Bevel gear and pinion, sealed chain

📐 Dimensions

Physical Dimensions

Length:

2765 mm (108.9 in)

Width:

1315 mm (51.8 in)

Height:

1730 mm (68.1 in)

Wheelbase:

1835 mm (72.2 in)

Ground Clearance:

160 mm (6.3 in)

Weight

Curb Weight:

450 kg (992 lbs)

🔧 Maintenance

Fluid Capacities

Engine Oil Capacity:

1.9 L (2.0 US qt)

Engine Oil Type:

SAE 10W-30 API SE, SF or SG

Transmission Oil Capacity:

0.3 L (0.3 US qt)

Transmission Oil Type:

Kawasaki Genuine Gear Oil GL-3 or equivalent

Differential Oil Capacity:

0.35 L (0.37 US qt)

Differential Oil Type:

Kawasaki Genuine Gear Oil GL-4 or equivalent

Service Schedule

Initial Service Interval:

20 hours or 1 month

Regular Service Interval:

100 hours or 6 months

📄 Wheels Tires

Wheel Specifications

Front Tire Size:

23x8.00-12

Rear Tire Size:

23x11.00-10

Front Wheel Offset:

ET-13

Rear Wheel Offset:

ET-17

📄 Brakes

Braking System

Front Brake Type:

Rear Brake Type:

📄 Suspension

Suspension System

Front Suspension Type:

Independent, strut type

Rear Suspension Type:

Independent, strut type

📄 Steering

Steering System

Type:

Rack and pinion
