The Ducati Multistrada 620, produced in 2005 and 2006, represents an accessible entry into Ducati's versatile adventure touring segment. This model, specifically the 620 Dark variant, features a distinctive aesthetic...
The Ducati Multistrada 620, produced in 2005 and 2006, represents an accessible entry into Ducati's versatile adventure touring segment. This model, specifically the 620 Dark variant, features a distinctive aesthetic with blacked-out components and is powered by an air-cooled, 618 cc L-Twin engine known for its signature sound and torque delivery. Its unique trellis frame design contributes to its agile handling, making it suitable for both daily commuting and light touring. The Multistrada 620 was positioned to offer Ducati's renowned engineering quality and a blend of sport and touring capabilities to a broader audience, competing with models like the BMW F 650 GS and Suzuki V-Strom DL650.
This comprehensive Parts Catalogue manual serves as an essential resource for owners and technicians maintaining the 2006 Ducati Multistrada 620 Dark. Spanning over 500 pages and available in multiple languages including English, Deutsch, and Italian, it provides detailed component identification and part number referencing across all major systems. The manual covers the engine, transmission, chassis, suspension, braking, fuel, and electrical systems, offering clear assembly and disassembly guidance. Its high-resolution, printable format ensures users can easily access information for accurate part sourcing, facilitating effective repair and upkeep of the motorcycle.
🏷️ Basic Information
Identification
Make:
Ducati
Model:
Multistrada 620
Model Variant:
620 Dark
Year:
2006
Codes
Engine Code:
DS1000 variant
👋 Introduction
Market Position
Segment:
Adventure Touring / Sport Touring Motorcycle
Competitive Analysis
Key Competitors 2006:
• BMW F 650 GS
• Suzuki V-Strom DL650
• Kawasaki KLR650
Key Features
Distinctive Attributes:
• L-Twin engine with signature Ducati sound and torque delivery
Comprehensive component breakdown, enabling accurate part sourcing and identification for repair and maintenance.
📊 Manual Specifications
File Format
Quality:
High-resolution PDF, suitable for printing.
Print Quality
Printability:
Printable, allowing users to generate hard copies of specific sections or the entire manual.
Binding Type
Delivery Format Binding:
Digital Archive (.rar/.zip) for download.
Paper Type
N/A:
N/A (Digital Format)
⚙️ Engine Specifications
Primary Engine
Engine Type:
Air-cooled, L-Twin cylinder, 4-stroke Desmodromic 2 valves per cylinder
Displacement:
618 cc
Performance
Bore X Stroke:
72 mm x 75 mm
Compression Ratio:
10.4:1
Power Output:
55.5 HP (40.8 kW) @ 8750 rpm
Torque Output:
50.8 lb-ft (69 Nm) @ 6750 rpm
Fuel System
Fuel Delivery:
Weber-Marelli electronic fuel injection with 38mm throttle bodies
Fuel Type:
Unleaded gasoline, minimum 95 RON
🔧 Transmission
Standard
Type:
6-speed
Clutch:
Wet, multi-plate, hydraulically operated
Features
Final Drive:
Chain drive, 520 O-ring sealed
📐 Dimensions
Exterior
Length:
2110 mm (83.1 in)
Width:
820 mm (32.3 in)
Height:
1245 mm (49.0 in)
Wheelbase:
1470 mm (57.9 in)
Weights
Dry Weight:
177 kg (390 lbs)
Wet Weight:
194 kg (428 lbs)
Fuel Tank Capacity:
20 liters (5.3 US gal)
🛡️ Safety Features
Ratings
N/A:
Motorcycle safety is primarily dependent on rider skill and adherence to road rules. Specific crash ratings are not applicable in the same way as for automobiles.
Active Features
Braking System:
Dual 320mm discs with 2-piston calipers (front), Single 240mm disc with 2-piston caliper (rear). Optional ABS available on some models.
Passive Features
Lighting:
Halogen headlight, LED tail light
💡 Technology Features
Infotainment
Display Type:
Analog tachometer and speedometer with LCD multi-function display
Features Included:
• Odometer
• Trip meter
• Clock
• Fuel level indicator
Driver Assistance
ABS:
Optional ABS (Anti-lock Braking System) available on some configurations.
Connectivity
N/A:
No integrated Bluetooth or smartphone connectivity.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 12,000 km (7,500 miles) or 12 months
Desmo Service Interval:
Every 24,000 km (15,000 miles) - Includes valve clearance adjustment via Desmodromic system
Fluid Specifications
Engine Oil:
SAE 15W-50, API SJ or higher, JASO MA compatible (e.g., Shell Advance AX7, Motul 5100)
Coolant:
Not applicable (Air-cooled engine)
Brake Fluid:
DOT 4
Clutch Fluid:
DOT 4 (if hydraulic clutch)
Gearbox Oil:
SAE 80W-90 API GL-4 (Specific Ducati gearbox oil recommended)
Known Issues
Common Wear Items:
• Clutch plates (wear dependent on usage)
• Cam belt tensioners and belts (regular replacement crucial)
• Front fork seals (potential leaks)
• Electrical connector corrosion (especially in humid climates)
Specific To Model:
Some owners report an occasionally abrupt throttle response, which can be mitigated with careful tuning and maintenance. Fuel pump reliability has been a minor concern on some Ducati models of this era.
📚 Vehicle History
Brand Heritage
Manufacturer:
Ducati Motor Holding S.p.A.
Model Evolution
Multistrada Lineage:
The Multistrada series, introduced in 2003, aimed to blend sportbike handling with touring comfort and off-road capability. The 620 model was a more accessible and less powerful variant of the original 1000cc model, targeting a wider audience.
Production
Production Years:
2005-2006
Manufacturing Location:
Bologna, Italy
🏆 Awards & Recognition
Recognitions
N/A:
While specific awards for the 620 Dark are not widely documented, the Multistrada line itself has been generally well-received for its unique blend of capabilities. Ducati's heritage in racing and engineering excellence often contributes to the perceived quality and desirability of their models.
