Suzuki GSF1250/GSF1250S/GSF1250A/ GSF1250SA Bandit Service Repair Manual 2007 2008 2009

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

28 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 131051

Etiquetas: 2007 2008 2009 GSF Bandit Series GSF1250 GSF1250A GSF1250S GSF1250SA Motorcycle Motorcycles Suzuki

Variantes de producto

Descripción

Welcome to the comprehensive guide for your GSF1250 Bandit, a versatile motorcycle known for its potent inline-four engine and comfortable riding experience. This model, produced from 2007 to 2009, is available in various configurations, including the GSF1250, GSF1250S (semi-fairing), GSF1250A (ABS), and GSF1250SA (semi-fairing with ABS). The GSF1250 Bandit inherits a legacy of engineering excellence, offering a robust 1255 cc liquid-cooled engine that delivers substantial torque, making it suitable for both spirited riding and long-distance touring. Its design emphasizes practicality and rider comfort, solidifying its reputation as a capable sport-touring machine. This service repair workshop manual provides exhaustive coverage for your GSF1250 Bandit, encompassing all essential maintenance procedures, detailed repair instructions, and diagnostic troubleshooting for every major system. You will find in-depth information on the engine, transmission, brakes, suspension, steering, and electrical systems, complete with step-by-step guidance and detailed diagrams. The manual is designed to empower owners and professional technicians alike, offering the knowledge needed to maintain peak performance, ensure reliability, and address any potential issues, thereby saving time and labor costs.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

GSF1250 Bandit

Model Variants:

GSF1250, GSF1250S (S = Semi-Fairing), GSF1250A (A = ABS), GSF1250SA (SA = Semi-Fairing with ABS)

Generation

Generation Code:

1st Generation (2007-2009)

Codes

Chassis Code:

Common across variants, primarily related to the GSF1250 platform

👋 Introduction

Market Position

Target Audience:

Suzuki GSF1250 Bandit owners and independent repair shops

Value Proposition:

Enables owners to perform repairs and maintenance efficiently, saving money on labor costs.

Competitive Analysis

Comparison To Factory Manuals:

Equivalent to factory shop manuals or CD-ROMs used in professional repair facilities.

Key Features

Instructional Style:

Step-by-step instructions with highly detailed exploded pictures and diagrams.

Ease Of Use:

Designed for easy following, suitable for any skill level.

Diagrams Illustrations:

Tons of pictures and diagrams for clear understanding.

📋 Manual Details

Coverage Areas

Model Years Covered:

2007, 2008, 2009

Geographic Coverage:

Likely global, based on common service manual structure

Page Count

Estimated Pages:

Extensive (based on Table of Contents, likely several hundred pages)

Manual Type

Type:

Service Repair Workshop Manual

Language

Language:

English

Format

Format:

📖 Manual Coverage

Systems Covered

Engine:

Complete engine overhaul, diagnosis, emission control devices, electrical components, mechanical systems, lubrication, cooling, fuel, ignition, starting, charging, exhaust

Suspension:

Front and rear suspension diagnosis, components, wheels, tires

Driveline Axle:

Drive chain, drivetrain, drive shaft maintenance and repair

Brakes:

Brake control system, diagnosis, front and rear brakes, ABS systems

Transmission Transaxle:

Manual transmission, clutch systems

Steering:

Steering diagnosis, handlebar components

Electrical Systems:

Wiring systems, lighting systems, combination meter, fuel meter, horn

Bodywork Accessories:

Exterior parts, body structure

Procedures Included

Maintenance:

Scheduled maintenance, lubrication, fluid changes, filter replacements, adjustments

Repair:

All major and minor repair procedures for covered systems

Troubleshooting:

Diagnostic procedures for various systems, fault finding

Assembly Disassembly:

Detailed steps for component removal and installation

Technical Depth

Depth:

Comprehensive from basic maintenance to complex engine and electrical diagnostics and repairs

📊 Manual Specifications

File Format

Digital Format:

Software Requirements:

Adobe PDF Reader, WinZip (for extraction if compressed)

Print Quality

Printability:

All pages are printable

Zoom Functionality:

YES (zoom in/out functionality)

Binding Type

Binding:

Not applicable (Digital Download)

Paper Type

Paper Type:

Not applicable (Digital Download)

Distribution

Download Availability:

YES (Instant download upon payment)

Compatibility:

All Versions of Windows (XP, ME, 98, NT, 2000, Vista 32/64) & Mac

⚙️ Engine Specifications

Primary Engine

Engine Type:

Inline 4-cylinder, 4-stroke, DOHC, liquid-cooled

Displacement:

1255 cc (1255 cubic centimeters)

Bore X Stroke:

79.0 mm x 64.0 mm

Compression Ratio:

10.5:1

Performance

Horsepower Approx:

Approximately 125 HP (varies slightly by region/tuning)

Torque Approx:

Approximately 110 Nm (varies slightly by region/tuning)

Fuel System

Fuel Delivery:

Fuel Injection (Suzuki's SDTV - Suzuki Dual Throttle Valve system)

Fuel Type:

Unleaded gasoline (91 octane or higher recommended)

Ignition System

Ignition Type:

Digital electronic ignition (CDI)

Cooling System

Cooling Method:

Liquid-cooled

Lubrication System

Oil Type Capacity:

Suzuki recommends specific grades (e.g., SAE 10W-40), capacity approx. 3.5L with filter change (refer to manual for precise details)

🔧 Transmission

Standard

Transmission Type:

6-speed constant mesh

Clutch Type:

Wet, multi-plate, back-torque limiter

Features

Drive System:

Chain drive

Fluid Specifications

Transmission Oil:

SAE 80W API GL-4 or GL-5 gear oil (refer to manual for exact specifications)

📐 Dimensions

Exterior

Length:

Approx. 2,275 mm (GSF1250)

Width:

Approx. 795 mm (GSF1250)

Height:

Approx. 1,235 mm (GSF1250)

Weights

Dry Weight:

Approx. 225 kg (GSF1250)

Wet Weight:

Approx. 247 kg (GSF1250)

Fuel Tank Capacity:

20.0 Liters

🛡️ Safety Features

Ratings

ABS Availability:

Available as GSF1250A and GSF1250SA models

Active Features

Braking System:

Hydraulic dual disc front brakes, Hydraulic single disc rear brake. ABS option provides enhanced braking control.

Passive Features

Lighting:

Halogen headlights, LED taillight (typical for the era)

💡 Technology Features

Infotainment

Instrument Cluster:

Analog tachometer, digital speedometer, gear position indicator, fuel gauge, clock, odometer, trip meters, various warning lights. Detailed diagnostic information is often accessible via the ECU which this manual will cover.

Driver Assistance

Anti-lock Braking System is an optional feature (A/SA models) for enhanced safety.

Connectivity

ECU Diagnosis:

The manual provides diagnostic procedures for the Engine Control Unit (ECU), allowing for fault code retrieval and analysis of sensor data.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 4,000-6,000 km or annually (refer to manual for exact mileage/time)

Spark Plug Replacement:

Around 10,000-12,000 km (refer to manual for specific plug type and interval)

Air Filter Cleaning Replacement:

Check and clean regularly, replace as needed based on operating conditions (refer to manual)

Valve Clearance Check:

Initial check at 1,000 km, subsequent checks typically every 12,000-18,000 km (refer to manual)

Fluid Specifications

Coolant Type:

Suzuki Super Long Life Coolant or equivalent ethylene glycol-based antifreeze with distilled water (50/50 mix) - refer to manual for exact specifications and Suzuki part numbers.

Brake Fluid:

DOT 4

Known Issues

Common Wear Items:

Clutch plates (especially with aggressive riding), chain and sprockets, wheel bearings, front fork seals.

Potential Electrical Issues:

While generally reliable, typical motorcycle electrical issues like corroded connectors or failing regulator/rectifiers can occur with age and mileage. The manual will guide diagnosis.

Engine Performance Quirks:

The inline-four engine is known for its strong mid-range torque. Some riders report minor snatchiness at very low RPM, which can be managed with throttle control or minor tuning.

📚 Vehicle History

Brand Heritage

Suzuki Motorcycle Legacy:

Suzuki has a long history of producing powerful and reliable motorcycles, particularly in the sport-touring and naked bike segments.

Model Evolution

Gsf Bandit Lineage:

The GSF1250 Bandit is an evolution of the Bandit series, inheriting its reputation for torque-rich performance and versatility. It succeeded the air-cooled GSF1200 Bandit, adopting a more modern, liquid-cooled engine.

Production

Manufacturing Location:

Likely Japan (Suzuki's primary motorcycle manufacturing base)

🏆 Awards & Recognition

Recognitions

Market Reputation:

The GSF1250 Bandit is widely regarded as a capable and comfortable sport-touring and commuting motorcycle, praised for its engine performance and value.

Motorcycle Press Reviews:

Often reviewed positively for its torquey engine, comfortable ergonomics for its class, and overall practicality. Specific awards are less common for a model of this type compared to flagship sportbikes, but it consistently received favorable comparisons in its segment.
