Yamaha Grizzly 350 IRS 2007-2011 Service Repair Workshop Manual Download PDF

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

This manual covers the Grizzly 350 IRS All-Terrain Vehicle (ATV) produced between 2007 and 2011. Known for its reliability and capability, the Grizzly 350 IRS is a mid-range utility ATV...

19 people are viewing this right now

Tipo: Atv

Proveedor:

SKU: 84731

Etiquetas: 2007 2008 2009 2010 2011 ATV Grizzly 350 IRS Grizzly Models Powersports Yamaha

Variantes de producto

Descripción

This manual covers the Grizzly 350 IRS All-Terrain Vehicle (ATV) produced between 2007 and 2011. Known for its reliability and capability, the Grizzly 350 IRS is a mid-range utility ATV designed for various terrain conditions. Key features include a comfortable ride enhanced by its Independent Rear Suspension (IRS), a durable air-cooled engine, selectable 2WD/4WD, and a robust design suitable for work and recreation. Yamaha has a long-standing reputation for producing dependable ATVs, and the Grizzly 350 IRS builds on this legacy, offering a capable and user-friendly experience for a wide range of riders. This comprehensive Service Repair Workshop Manual provides complete factory procedures for maintaining and repairing your Grizzly 350 IRS. It details all aspects of the vehicle, including engine, drivetrain, suspension, steering, brakes, and electrical systems. The manual covers routine maintenance, troubleshooting, diagnostic procedures, and complete repair and rebuild instructions for all major components. With over 400 pages of high-resolution text and clear diagrams, this English-language manual is an essential resource for owners, mechanics, and technicians seeking to ensure the optimal performance and longevity of their ATV.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

Grizzly 350 IRS

Model Variant:

Independent Rear Suspension (IRS)

Year Range:

2007-2011

Vehicle Type:

ATV (All-Terrain Vehicle)

👋 Introduction

Market Position

Category:

Mid-range utility ATV, known for its reliability and capability in various terrain conditions.

Competitive Analysis

Competitors:

Honda Foreman/Rancher, Suzuki KingQuad, Polaris Sportsman.

Key Features

Features Overview:

Comfortable ride with IRS, durable engine, ample towing capacity, selectable 2WD/4WD, rugged design.

📋 Manual Details

Coverage Areas

Coverage Scope:

Complete factory service, repair, and workshop procedures

Page Count

Estimated Pages:

Manual Type

Type:

Service Repair Workshop Manual

Language

Language:

English

Format

Format:

Downloadable PDF

📖 Manual Coverage

Systems Covered

Engine:

Internal combustion engine, cooling system, lubrication system, fuel system, ignition system, starting system, exhaust system.

Drivetrain:

Transmission (automatic), clutch, drive shafts, differentials (front and rear), final drive, CV joints, bearings.

Suspension And Steering:

Front and rear independent suspension (IRS), shock absorbers, springs, control arms, steering system, tie rods, steering column, wheel alignment.

Brakes:

Hydraulic brake system, front and rear calipers, brake discs, brake lines, master cylinder, brake fluid specifications.

Electrical:

Wiring diagrams, battery, charging system (alternator/stator), lighting system, starter motor, ignition coil, ECU (Electronic Control Unit), sensors, fuses, relays.

Chassis And Body:

Frame inspection, body panels, fenders, racks, seat, handlebars, footwells, plastics, trim components.

Procedures Included

Maintenance:

Routine inspections, oil changes, filter replacements (air, oil, fuel), spark plug replacement, lubrication points, valve clearance adjustments, coolant flush.

Troubleshooting:

Diagnostic procedures for engine performance, electrical faults, braking issues, starting problems, transmission operation.

Repair And Rebuild:

Detailed disassembly, inspection, repair, and reassembly of all major components, including engine, transmission, suspension, and brakes.

Diagnostics:

Step-by-step diagnostic flowcharts, error code interpretation (if applicable), testing of electrical components and sensors.

Technical Depth

Depth:

Comprehensive, suitable for professional technicians and experienced DIY mechanics. Covers everything from basic maintenance to full engine and transmission rebuilds.

📊 Manual Specifications

File Format

Compatibility:

PDF reader software (Adobe Acrobat, Foxit Reader, etc.)

Print Quality

Quality:

High-resolution, crisp text and clear diagrams for easy reading and printing.

Binding Type

Type:

N/A (Digital Download)

Paper Type

Type:

N/A (Digital Download)

Searchability

Feature:

Searchable text for quick information retrieval.

Access

Availability:

Instant download with no expiry dates or extra fees.

⚙️ Engine Specifications

Primary Engine

Engine Type:

Four-stroke, SOHC, air-cooled

Displacement:

348 cc

Bore X Stroke:

83 mm x 64.5 mm

Compression Ratio:

9.2:1

Fuel Delivery:

Mikuni BSR33 carburetor

Performance

Horsepower:

Approximately 21-23 HP (estimated, actual varies by tuning and market)

Torque:

Approximately 28 Nm (estimated, actual varies by tuning and market)

Fuel System

Fuel Type:

Unleaded gasoline (minimum 87 octane recommended)

Cooling System

Type:

Air-cooled with fan assist

Lubrication System

Oil Type:

Yamalube 4 (or equivalent) SAE 10W-40 API SG or higher

Ignition System

Type:

CDI (Capacitor Discharge Ignition)

Starting System

Type:

Electric starter with automatic decompressor

🔧 Transmission

Standard

Transmission Type:

Automatic (Yamaha Constant-Velocity Transmission - Y.C.V.T.)

Gear Selection:

High, Low, Neutral, Reverse, Park

Drive System:

Shaft drive, selectable 2WD/4WD with Ultramatic® system

Features

Clutch Type:

Wet, centrifugal type

Fluid Specifications

Cvt Fluid:

Yamalube Gear Oil (or equivalent) SAE 80 API GL-4

📐 Dimensions

Exterior

Length:

2065 mm (81.3 in)

Width:

1120 mm (44.1 in)

Height:

1140 mm (44.9 in)

Wheelbase:

1290 mm (50.8 in)

Ground Clearance:

200 mm (7.9 in)

Weights

Dry Weight:

267 kg (589 lbs)

Curb Weight:

281 kg (619 lbs)

Towing Capacity:

500 kg (1102 lbs)

Front Rack Capacity:

45 kg (99 lbs)

Rear Rack Capacity:

85 kg (187 lbs)

🛡️ Safety Features

Ratings

Crash Safety:

N/A (ATVs typically do not have standardized crash ratings like passenger vehicles.)

Active Features

Braking System:

Front and rear hydraulic disc brakes, parking brake.

Passive Features

Ergonomics:

Designed for stability and control with comfortable seating position and intuitive controls.

Lighting:

Dual 30W Krypton headlights, 8W LED taillight.

💡 Technology Features

Infotainment

Features:

N/A (Focus is on utility and off-road performance, not infotainment.)

Driver Assistance

Features:

N/A (No electronic driver assistance systems typical of modern cars.)

Connectivity

Features:

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 1,000 km or 6 months, whichever comes first.

Air Filter Cleaning:

Inspect every 100 hours, clean as needed; replace every 1,000 hours or 12 months.

Spark Plug Replacement:

Replace every 6,000 km or 36 months.

Valve Clearance Check:

Check every 6,000 km or 36 months.

Fluid Specifications

Engine Oil Capacity:

1.8 L (1.9 US qt) with oil filter change

Coolant Type:

Yamaha Two-Stroke Snowmobile/ATV Antifreeze or equivalent (50/50 mixture)

Brake Fluid Type:

DOT 3 or DOT 4 hydraulic brake fluid

Known Issues

Common Wear Items:

CV boots, front-end bushings, wheel bearings, starter motor brushes, rear shock absorber seals (common for high-usage ATVs).

Common Issues

Carburetor Tuning:

Occasional need for carburetor cleaning or adjustment due to fuel variations or environmental conditions.

Electrical Connections:

Corrosion on electrical connectors, especially in wet environments, can lead to intermittent issues.

📚 Vehicle History

Brand Heritage

Yamaha Atv:

Yamaha has a long-standing reputation for producing reliable and durable ATVs, pioneers in the industry with models like the Tri-Zinger and then the YFM series.

Model Evolution

Grizzly Lineage:

The Grizzly 350 IRS builds upon the success of the 350 platform, introducing independent rear suspension for enhanced comfort and handling compared to solid rear axles found on some earlier models or base versions.

Production

Manufacturing:

Typically manufactured in Japan and/or North America by Yamaha Motor Corporation.

🏆 Awards & Recognition

Recognitions

Industry Awards:

N/A (ATVs are generally not subjected to consumer automotive awards in the same manner.)

Ratings

Consumer Reviews:

Consistently rated as a reliable and capable mid-size utility ATV by riders.

Certifications

Emissions:

EPA compliant for its respective model years.
