KTM 530 EXC-R SIX DAYS 2008 Service Repair Manual

$16.99
$16.99
This manual covers the 2008 530 EXC-R SIX DAYS, a high-performance dual-sport motorcycle renowned for its off-road racing heritage and robust LC4 engine platform. As a special SIX DAYS edition,...
27 people are viewing this right now
Tipo: Motorcycle
Proveedor:
Ktm
SKU: 100575
Etiquetas: 2008 530 530 EXC-R SIX DAYS KTM Motorcycle Motorcycles
KTM 530 EXC-R SIX DAYS 2008 Service Repair Manual
This manual covers the 2008 530 EXC-R SIX DAYS, a high-performance dual-sport motorcycle renowned for its off-road racing heritage and robust LC4 engine platform. As a special SIX DAYS edition, this model often includes upgraded components and celebrates international enduro events. Engineered in Austria, the brand is recognized for its focus on performance and reliability in the competitive motorcycle market. The 530 EXC-R SIX DAYS is built for demanding off-road conditions and adventurous riding, combining powerful engine characteristics with durable chassis components. This comprehensive service repair manual provides in-depth factory information for owners and technicians. It details a wide array of procedures, including complete disassembly and reassembly, maintenance, repair, and troubleshooting for all major systems. Key areas covered include the fuel system, cooling system, engine top end, clutch, lubrication system, transmission, wheels and tires, final drive, brakes, suspension, steering, frame, and the electrical system. With hundreds of pages of instructions, supported by numerous photos and illustrations, this manual is an essential resource for ensuring the optimal performance and longevity of your 2008 530 EXC-R SIX DAYS.
