🏷️ Basic Information

Make:

Subaru

Model:

BRZ

Model Years Covered:

2012, 2013, 2014

Chassis Code:

ZC6 (First Generation)

👋 Introduction

Vehicle Segment:

Compact Sports Car / Rear-Wheel Drive Coupe

Key Competitors:

Mazda MX-5 Miata, Toyota GT86/Scion FR-S (shared platform), Nissan 370Z (higher tier), Ford Mustang (higher tier)

Vehicle Philosophy:

Lightweight, rear-wheel-drive, driver-focused performance with balanced handling and accessible pricing

Value:

Provides professional-level diagnostic and repair information, empowering owners and independent technicians to maintain and repair the vehicle accurately.

📋 Manual Details

Primary Coverage:

All aspects of service, repair, and troubleshooting

Secondary Coverage:

Maintenance, diagnostics, component replacement, specifications

Estimated Pages:

Hundreds of pages (exact count not specified, but indicated as comprehensive)

Type:

Factory Service Manual / Workshop Manual / Repair Manual

Language:

English

Format:

Digital (PDF)

📖 Manual Coverage

Powertrain:

Engine, transmission, drivetrain, exhaust system

Chassis:

Suspension, steering, brakes, wheels, tires

Electrical:

Wiring diagrams, lighting, starting and charging system, body electrical, instrumentation, HVAC controls

Body:

Body construction, exterior trim, interior trim, safety systems (airbags, seatbelts)

Maintenance:

Routine inspections, fluid changes, filter replacements, lubrication

Repair:

Component removal, installation, and overhaul for all systems

Troubleshooting:

Diagnostic procedures, symptom-based troubleshooting charts, fault code interpretation

Depth:

Comprehensive: Covers basic to advanced repairs, including detailed engine rebuilds and complex electrical diagnostics

📊 Manual Specifications

Format:

PDF

Printable:

Yes, individual pages or entire manual can be printed

Binding:

Not Applicable (Digital Download)

Paper Type:

Not Applicable (Digital Download)

Usage License:

Unlimited use on multiple devices, no expiry dates, no renewal fees

Operating Systems:

Fully compatible with Windows and macOS

⚙️ Engine Specifications

Engine Code:

FA20

Engine Type:

Naturally Aspirated Boxer-4 (Horizontally-Opposed)

Displacement:

2.0 Liters (1998 cc)

Horsepower:

200 hp @ 7000 rpm (approx.)

Torque:

151 lb-ft @ 6400 rpm (approx.)

Injection Type:

Direct Injection (D4-S)

Configuration:

DOHC, 16 Valves

Ratio:

12.5:1

Type:

Liquid-cooled

🔧 Transmission

Type:

6-Speed Manual Transmission

Type:

6-Speed Automatic Transmission (with Paddle Shifters on some trims)

Limited Slip Differential:

Standard (Torsen LSD)

Fluid Spec:

GL-4, SAE 75W-90 (refer to manual for specific Subaru specification)

Fluid Spec:

ATF-WS (World Standard) (refer to manual for specific Subaru specification)

📐 Dimensions

Length:

164.2 inches (4170 mm)

Width:

69.1 inches (1755 mm)

Height:

50.6 inches (1285 mm)

Wheelbase:

101.2 inches (2570 mm)

Curb Weight:

Approx. 2700-2800 lbs (1225-1270 kg), depending on transmission

🛡️ Safety Features

NHTSA Overall:

5-Star (typically for models of this era, verify specific year/trim)

Traction Control:

Standard (VSC and TRC)

Stability Control:

Standard (Vehicle Stability Control)

Airbags:

Front, side-impact, curtain airbags

Front Brake Type:

Ventilated Disc

Rear Brake Type:

Solid Disc

Wheel Size Standard:

17-inch alloy

Tire Size Standard:

215/45R17

💡 Technology Features

Head Unit:

Factory-installed audio system with touch screen (details vary by trim level), Bluetooth connectivity, USB input.

Cruise Control:

Standard

Auxiliary Input:

Available (depending on trim)

Diagnostic Tools Covered:

The manual provides information on using OBD-II scanners, interpreting diagnostic trouble codes (DTCs), and using specific Subaru diagnostic software/procedures.

🔧 Maintenance

Oil Change Interval:

Every 5,000-7,500 miles or 6-12 months, whichever comes first (refer to manual for exact schedule based on driving conditions)

Engine Air Filter:

Inspect every 15,000 miles, replace as needed (typically every 30,000 miles)

Cabin Air Filter:

Replace every 15,000 miles or annually

Spark Plugs:

Replace at 60,000 miles (refer to manual for specific plug type, likely iridium)

Engine Oil Spec:

0W-20 Synthetic (refer to manual for exact Subaru specification and capacity)

Coolant Spec:

Subaru Super Coolant (Blue) or equivalent silicate-free, long-life coolant (refer to manual for capacity)

Brake Fluid Spec:

DOT 3 or DOT 4 (refer to manual for specific recommendation and capacity)

Common Complaints:

Oil consumption (especially in early models), clutch wear (depending on driving style), potential for valve spring issues (though less common in early NA motors compared to turbocharged variants, requires specific checks).

Manual Diagnostic Utility:

The manual details common failure points and diagnostic procedures for these potential issues, aiding in early detection and resolution.

📚 Vehicle History

Performance Focus:

Subaru has a long history of motorsport involvement and performance-oriented vehicles, notably with the Impreza WRX/STI and legacy performance sedans.

First Generation Launch:

The first generation (2012-2021) was jointly developed with Toyota (as the GT86/Scion FR-S), marking Subaru's return to the rear-wheel-drive sports car segment after a hiatus.

Manufacturing Location:

Gunma Plant, Japan

🏆 Awards & Recognition

Car And Driver 10Best:

The Subaru BRZ (and its Toyota sibling) was often cited in '10Best' lists for its driving dynamics and value by publications like Car and Driver and MotorTrend, though specific awards can vary by year.
