2017 Chevrolet Malibu Service and Repair Manual

Vin Decoder Prefix:

1GC

Generation Identifier:

Malibu (9th Generation - V08)

Generation Years:

2016-2023

👋 Introduction

Vehicle Segment:

Mid-size Sedan

Target Audience:

Families, commuters, fleet vehicles

Primary Competitors:

Toyota Camry, Honda Accord, Ford Fusion, Nissan Altima, Hyundai Sonata

Platform:

Epsilon II Platform (shared with Cadillac XTS, Buick LaCrosse)

Design Philosophy:

Sportier styling, improved aerodynamics, enhanced fuel efficiency

Technology Integration:

Advanced infotainment and driver-assistance systems

📋 Manual Details

Comprehensive Coverage:

True

Engine Coverage:

2.0L Turbocharged L3X, 1.5L Turbocharged LYX

Transmission Coverage:

9T50 (9-Speed Automatic)

Body And Chassis Coverage:

Exterior, Interior, Frame, Suspension, Steering, Brakes, Wheels, Tires

Electrical System Coverage:

Charging System, Starting System, Ignition System, Lighting, Instrumentation, Body Control Modules, Powertrain Control Modules, Infotainment System

HVAC Coverage:

Heating, Ventilation, Air Conditioning, Refrigerant System

Safety And Restraint Coverage:

Airbag Systems, Seatbelts, Advanced Driver Assistance Systems (ADAS)

Diagnostic Coverage:

Troubleshooting, DTC (Diagnostic Trouble Codes) Explanations and Procedures

Estimated Page Count:

2000+

Manual Category:

Factory Service Manual (FSM) / Repair Manual

Language:

English

Format Type:

Digital (PDF)

📖 Manual Coverage

Powertrain Systems:

Engine mechanical, engine performance, fuel injection, exhaust, cooling, lubrication, emissions control

Drivetrain Systems:

Transmission (automatic), transaxle, drive shafts, axles, differential

Chassis Systems:

Suspension (front and rear), steering (electric power assist), braking system (ABS, EBD, ESC), wheel bearings, tires

Electrical Systems:

Battery, charging system, starter motor, ignition system, lighting (headlamps, taillamps, interior), gauges, instrument cluster, body control module (BCM), power windows, power locks, mirrors, sensors (oxygen, knock, temperature, pressure), ECUs (Engine Control Unit), TCU (Transmission Control Unit)

Comfort And Convenience Systems:

HVAC, climate control, power seats, keyless entry, remote start, audio system, navigation system, infotainment interface

Safety Systems:

Airbags, seat belts, pre-tensioners, advanced driver assistance systems (forward collision alert, lane keep assist, parking assist)

Scheduled Maintenance:

Oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt inspections and replacement

Engine Repair And Rebuild:

Engine disassembly and reassembly, cylinder head service, piston and connecting rod service, crankshaft service, timing system service

Transmission Service:

Transmission fluid and filter change, transmission removal and installation, internal transmission component diagnosis and repair

Brake System Repair:

Brake pad and rotor replacement, brake caliper service, brake line and hose replacement, bleeding brake system, ABS system diagnosis and repair

Suspension And Steering Repair:

Strut and shock absorber replacement, control arm replacement, ball joint replacement, tie rod end replacement, power steering system service

Electrical Diagnostics:

Circuit testing, component testing, wiring diagram interpretation, module programming and relearning

HVAC Service:

Refrigerant system charging and evacuation, component replacement (compressor, condenser, evaporator), blower motor service

Body And Trim Repair:

Panel replacement, door hardware service, glass replacement, interior trim panel removal and installation

Diagnostic Troubleshooting:

Step-by-step diagnostic procedures for various symptoms and DTCs

Depth Of Information:

Expert-level technical detail, suitable for professional technicians and advanced DIYers

Diagnostic Flowcharts:

Included for systematic troubleshooting

Torque Specifications:

Comprehensive list for all critical fasteners

Wiring Diagrams:

Detailed electrical schematics for all systems

Special Tools:

Identification and usage of required special tools for specific repairs

Rebuild Procedures:

Detailed steps for engine and transmission rebuilds

Component Replacement:

Detailed instructions for replacing major and minor components

📊 Manual Specifications

Digital Format:

PDF

Searchability:

Text-searchable for quick information retrieval

Printability:

Printable pages for in-shop use

Image Resolution:

High-resolution diagrams and illustrations

Binding:

N/A (Digital)

Paper Quality:

N/A (Digital)

⚙️ Engine Specifications

Engine 1 Displacement Liters:

1.5

Engine 1 Code:

LYX

Engine 1 Configuration:

Inline-4, turbocharged, direct injection

Engine 1 Horsepower Hp:

160

Engine 1 Torque Lb Ft:

184

Engine 1 Fuel Type:

Regular Unleaded Gasoline

Engine 2 Displacement Liters:

2.0

Engine 2 Code:

L3X

Engine 2 Configuration:

Inline-4, turbocharged, direct injection

Engine 2 Horsepower Hp:

250

Engine 2 Torque Lb Ft:

260

Engine 2 Fuel Type:

Premium Unleaded Gasoline Recommended

Fuel Delivery:

Direct Injection

Emission Controls:

Catalytic Converter, On-Board Diagnostics (OBD-II)

🔧 Transmission

Transmission Type Standard:

9-Speed Automatic (9T50)

Transmission Fluid Type Standard:

Dexron-VI (or equivalent)

Transmission Features:

Manual mode, paddle shifters (on certain trims)

📐 Dimensions

Length Inches:

193.8

Width Inches:

73.1

Height Inches:

57.4

Wheelbase Inches:

111.4

Passenger Volume Cu Ft:

105.1

Front Headroom Inches:

39.1

Rear Headroom Inches:

37.5

Front Legroom Inches:

42.1

Rear Legroom Inches:

38.1

Cargo Volume Cu Ft Rear Seats Up:

15.8

Cargo Volume Cu Ft Rear Seats Down:

48.5

Curb Weight Lbs Min:

3335

Curb Weight Lbs Max:

3500

Gross Vehicle Weight Rating Gvwr Lbs:

4586

Towing Capacity Lbs:

1000

🛡️ Safety Features

NHTSA Overall Rating:

5-Star Overall Safety Rating

IIHS Top Safety Pick:

Yes (when equipped with specific optional safety features)

ABS:

Standard (4-wheel antilock disc brakes)

Traction Control:

Standard (StabiliTrak Electronic Stability Control System)

Electronic Brakeforce Distribution:

Standard

Brake Assist:

Standard

Forward Collision Alert:

Optional

Lane Keep Assist:

Optional

Lane Departure Warning:

Optional

Rear Park Assist:

Optional

Airbags:

Standard: Frontal, Knee, Side-Impact (front and rear), Curtain

Seat Belts:

3-point, all seating positions; front seatbelt pretensioners

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for Children) system

💡 Technology Features

Infotainment System Name:

Chevrolet MyLink

Screen Sizes:

7-inch or 8-inch diagonal touchscreen

Apple Carplay Android Auto:

Available/Standard on higher trims

Navigation System:

Optional

Adaptive Cruise Control:

Optional

Automatic Emergency Braking:

Optional

Blind Spot Monitoring:

Optional

Rear Cross Traffic Alert:

Optional

Bluetooth Connectivity:

Standard

Usb Ports:

Available

Wi Fi Hotspot:

Optional (OnStar 4G LTE)

🔧 Maintenance

Oil Change Interval Miles Or Months:

7,500 miles or 12 months (whichever comes first), depending on driving conditions

Tire Rotation Interval Miles:

7,500

Engine Air Filter Replacement Miles:

24,000-45,000 (under normal conditions)

Cabin Air Filter Replacement Miles:

15,000-30,000

Spark Plug Replacement Miles Lyx:

60,000 (iridium)

Spark Plug Replacement Miles L3X:

60,000 (iridium)

Transmission Fluid Change Interval Miles:

90,000-100,000 (under normal driving conditions)

Engine Oil Type:

SAE 0W-20 Full Synthetic (API SN or newer)

Engine Oil Capacity Quarts Lyx:

4.9

Engine Oil Capacity Quarts L3X:

5.2

Coolant Type:

GM DEX-COOL (Orange)

Brake Fluid Type:

DOT 3 (or DOT 4 if specified)

Power Steering Fluid Type:

GM Power Steering Fluid (or DEXRON-VI Automatic Transmission Fluid)

Common Maintenance Items:

Turbocharger diagnostics and maintenance, water pump seals, exhaust manifold leaks, AC system performance, catalytic converter issues

Diagnostic Challenges:

Intermittent electrical faults, CAN bus communication errors, turbocharger boost pressure issues

Software Updates:

PCM/TCM updates for transmission shift quality and engine performance

📚 Vehicle History

Chevrolet Founding:

1911

Chevrolet Tagline:

Find New Roads

Malibu Introduction Year:

1964

Malibu Previous Generation Design:

More upright, less aerodynamic styling

Malibu 9Th Gen Redesign Focus:

Lighter weight due to increased use of high-strength steel, improved fuel economy, more dynamic styling

Manufacturing Locations 2017:

Fairfax Assembly, Kansas City, Kansas; Oshawa Assembly, Ontario, Canada

🏆 Awards & Recognition

Ward S 10 Best Engines:

2.0L Turbocharged L3X engine recognized in past years (though not specifically for 2017 model year, the powertrain technology is advanced)

Family Sedan Awards:
