Target Audience:
DIY enthusiasts, home mechanics, professional technicians, Arctic Cat owners seeking detailed repair and maintenance information.
Comparison:
Provides factory-level detail comparable to manuals used by authorized dealerships, offering a cost-effective alternative for maintenance and repair.
Detail Level:
Highly detailed, comprehensive information for repair, service, restoration, and preventative maintenance.
Usability:
Clear, step-by-step instructions with illustrations make complex procedures accessible for a wide range of skill levels.
Covered Models:
2007 Arctic Cat 400 Automatic/Manual, 2007 Arctic Cat 400 TRV 4x4, 2007 Arctic Cat 500 Automatic/Manual, 2007 Arctic Cat 650 H1 4x4, 2007 Arctic Cat 700 EFI
Estimated Page Count:
Varies (up to 5GB file size mentioned, indicating comprehensive coverage)
Type:
Service Repair Shop Manual
Engine:
Complete engine overhaul, diagnostics, rebuilding, performance tuning
Transmission:
Automatic and Manual transmission service, repair, adjustments, fluid specifications
Drivetrain:
Front and rear differential service, drive shafts, CV joints, lubrication
Suspension:
Front and rear suspension components, shock absorbers, A-arms, bushings, alignment
Brakes:
Brake system diagnostics, caliper service, master cylinder repair, brake fluid specifications, bleeding procedures
Electrical:
Wiring diagrams, starter system, charging system, ignition system, lighting, sensors, diagnostic codes
Fuel System:
Fuel injection system (EFI), fuel pump, injectors, fuel filter replacement, carburetor (if applicable) adjustments
Cooling System:
Radiator, coolant, fan, thermostat service and replacement
Body And Frame:
Body panel removal and installation, frame inspection, seat, handlebars, racks
Tires And Wheels:
Tire inspection, inflation pressures, wheel removal and installation, bolt patterns
Routine Maintenance:
Oil changes, filter replacements, lubrication points, spark plug replacement, air filter service, battery maintenance
Troubleshooting:
Diagnostic procedures for common problems, symptom-based troubleshooting guides
Repair And Rebuild:
Detailed step-by-step instructions for component disassembly, repair, and reassembly
Preventative Maintenance:
Scheduled maintenance tasks to ensure longevity and reliability
Restoration:
Guidance for bringing an older or neglected ATV back to operational status
Depth:
Comprehensive, from basic user maintenance to complete engine and transmission rebuilds, suitable for DIY and professional technicians
Compatibility:
Windows, Linux, Mac (requires PDF reader)
Printable:
Yes, full printing capability
Searchable:
Likely searchable text within PDF, depending on original scan quality
Type:
Digital Download (Not a physical binding)
Type:
Not Applicable (Digital)
Estimated Size:
Up to 5 GB (indicates extensive detail)
Type:
Illustrated with clear step-by-step instructions, zoomable illustrations, exploded views, component breakdowns
Method:
Instant download after purchase
2007 400 Series Engine:
Likely a 375cc-400cc liquid-cooled, SOHC, 4-stroke engine. Specific engine designations may vary by sub-model.
2007 500 Series Engine:
Likely a 493cc liquid-cooled, SOHC, 4-stroke engine. Specific engine designations may vary by sub-model.
2007 650 H1 Engine:
Likely a 641cc liquid-cooled, SOHC, 4-stroke Hemi engine. Known for its robust power delivery.
2007 700 Efi Engine:
Likely a 695cc liquid-cooled, SOHC, 4-stroke engine with Electronic Fuel Injection (EFI). Specific engine designations may vary by sub-model.
Horsepower Torque General:
Specific horsepower and torque figures are model-dependent and detailed within the manual. Expect performance figures typical for their displacement classes in the mid-2000s ATV market.
Injection Type:
EFI on applicable models (e.g., 700 EFI). Carbureted systems are also covered for models designated 'Automatic/Manual'.
Type:
CDI (Capacitor Discharge Ignition) or similar electronic ignition systems, detailed diagnostics and component testing included.
Type:
Automatic transmission with Hi/Lo range and Reverse (CVT - Continuously Variable Transmission) is standard on many models. Manual transmission variants are also covered.
Type:
Manual transmission options may exist for specific 400 and 500 models, as indicated by 'Automatic/Manual' designation.
Cvtvt Service:
Detailed procedures for CVT belt inspection, replacement, sheave maintenance, and roller service.
Transmission Fluid:
Specific Arctic Cat branded or recommended CVT fluid and gearcase oil specifications provided. Typical requirements include SAE 5W-50 Synthetic for CVT or similar specified viscosity for gearcases.
Length Width Height:
Varies by model, but generally around 83-85 inches (L) x 46-48 inches (W) x 48-50 inches (H) for typical 400-700cc ATVs of this era. Specific dimensions are detailed in the manual.
Dry Weight:
Varies significantly by model, generally ranging from 550 lbs to 700+ lbs. Specific dry weight figures are model-dependent and found in the manual.
Towing Capacity:
Typically rated for 1000-1500 lbs towing capacity. Specific figures are model-dependent.
General Safety:
The manual emphasizes safe operating procedures, pre-ride inspections, and proper use of safety equipment. Specific regulatory ratings are not typically detailed in service manuals.
Braking System:
Hydraulic disc brakes (front and rear) with robust lever controls for responsive stopping power. Details on brake component maintenance and bleeding.
Rollover Protection:
Standard ATV design, the manual covers maintenance of frame and body components critical to structural integrity. No integrated ROPS is standard.
Features:
Minimal infotainment features typically found on ATVs of this era. Focus is on functional instrumentation (speedometer, odometer, fuel gauge, 4x4 indicator).
Features:
No advanced driver assistance systems. Focus on electronic fuel injection (EFI) for improved engine management and throttle response on applicable models.
Features:
No modern connectivity features. Vehicle diagnostics may be accessed via specific connectors, detailed in the manual.
Oil Change Interval:
Typically every 100 hours or annually, whichever comes first. Specific intervals for engine oil, transmission oil, and differential fluids are detailed.
Cvtvt Belt Inspection:
Recommended inspection every 50 hours or annually. CVT belt replacement is typically recommended every 2-3 years or based on wear indicators.
Engine Oil:
Arctic Cat proprietary 4-stroke engine oil or equivalent API SG/SH/SJ/SL rated oil with viscosity SAE 5W-50 or 10W-40 (as specified for ambient temperature).
Coolant:
Ethylene glycol based antifreeze with corrosion inhibitors, mixed 50/50 with distilled water. Specific capacity details provided per model.
Brake Fluid:
DOT 3 or DOT 4 hydraulic brake fluid, depending on specific model requirements. Never use DOT 5.
Common Wear Items:
CVT belts, suspension bushings, ball joints, wheel bearings, and brake pads are common wear items that require regular inspection and potential replacement.
Efi System:
Troubleshooting for EFI sensor issues (e.g., TPS, MAP, IAT) and fuel pump performance are covered. The manual provides diagnostic steps for common EFI related problems.
Oil Filter:
Specific part numbers for oil filters (e.g., Arctic Cat part numbers) are included for each engine variant.
Recommended Spark Plugs:
Specific spark plug types and gap specifications (e.g., NGK CR8E or equivalent) are provided for each engine model.
Arctic Cat Atv Development:
Arctic Cat has a long history in powersports, evolving from snowmobiles to a diverse range of ATVs and UTVs, focusing on off-road performance and durability.
2007 Model Lineup:
The 2007 model year saw Arctic Cat refining its ATV lineup, with the Hemi engine (650 H1) and EFI becoming more prevalent, offering enhanced performance and efficiency across their range.
