BMW R1150RT Technical Workshop Manual All ModelS COVERED

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

20 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 125728

Etiquetas: BMW Motorcycle Motorcycles R Series R1150RT

Variantes de producto

Descripción

This manual covers the R1150RT, a luxury sport touring motorcycle produced between 1995 and 2004. Renowned for its comfort and long-distance capability, the R1150RT features a horizontally opposed twin-cylinder Boxer engine, shaft drive, and the Integral ABS II braking system. Its design prioritizes rider ergonomics with an adjustable windscreen and protective fairings, making it a capable machine for touring. The R1150RT has been praised for its robust build quality and reliability, solidifying its reputation as a dependable touring companion. This workshop service repair manual provides comprehensive guidance for maintaining and repairing all models of the R1150RT. It details essential procedures for engine mechanical and electrical systems, transmission and drivetrain, chassis and suspension, brakes including ABS, and the overall electrical system. The manual also covers bodywork and fairings, offering detailed troubleshooting guides and diagnostics for common issues. With in-depth technical information, system schematics, and high-quality diagrams, this manual is an indispensable resource for owners, mechanics, and technicians aiming to ensure the optimal performance and longevity of the R1150RT.

🏷️ Basic Information

Identification

Make:

Model:

R1150RT

Model Variants Covered:

All models

👋 Introduction

Market Position

Vehicle Segment:

Luxury Sport Touring Motorcycle

Target Audience:

Touring riders seeking comfort, performance, and long-distance capability

Competitive Analysis

Key Competitors:

Honda ST1300, Kawasaki GTR1400, Yamaha FJR1300

Key Features

Engine Configuration:

Horizontally opposed twin-cylinder (Boxer)

Drive System:

Shaft drive

Braking Technology:

Integral ABS (Anti-lock Braking System)

Ergonomics:

Adjustable windscreen, comfortable seating position, fairings for weather protection

📋 Manual Details

Coverage Areas

Engine Mechanical:

Comprehensive

Engine Electrical:

Comprehensive

Transmission Drivetrain:

Comprehensive

Chassis Suspension:

Comprehensive

Brakes ABS:

Comprehensive

Electrical System:

Comprehensive

Bodywork Fairings:

Comprehensive

Diagnostics Troubleshooting:

Comprehensive

Page Count

Estimated Pages:

Likely 800+ (based on typical BMW workshop manuals of this era)

Manual Type

Type:

Workshop Service Repair Manual

Language

Language:

English (presumed based on product description)

Format

Format:

📖 Manual Coverage

Systems Covered

Engine Management:

Fuel injection (BMS-K), ignition system, emissions control

Transmission Type:

6-speed manual gearbox, shaft drive

Suspension System:

Telelever front suspension, Monolever rear suspension, adjustable shocks

Braking System:

Integral ABS II (power assisted), dual front discs, single rear disc

Electrical Components:

Wiring diagrams, lighting, starter, alternator, battery, instrumentation

Fuel System:

Fuel tank, fuel pump, injectors, fuel filter

Cooling System:

Oil cooling system (engine oil cooler)

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, spark plug service, valve clearance adjustment

Major Repairs:

Engine rebuilds, gearbox overhauls, suspension component replacement

Electrical Diagnostics:

Fault finding for starting, charging, lighting, and ABS systems

Brake System Service:

Pad replacement, fluid bleeding, caliper service, ABS unit diagnostics

Bodywork Adjustments:

Fairing removal and installation, seat adjustment, mirror replacement

Troubleshooting Guides:

Step-by-step fault diagnosis for common issues

Technical Depth

Depth:

Comprehensive, covering everything from basic maintenance to complete engine and transmission rebuilds.

Diagnostic Capability:

Detailed troubleshooting trees, symptom-based diagnosis, and component testing procedures.

Diagram Quality:

High-quality exploded views, wiring diagrams, and system schematics.

📊 Manual Specifications

File Format

Compatibility:

PC & Mac Compatible (Windows 95, 98, 2000, NT, XP, Vista, Windows 7, etc.)

Accessibility:

Instant Download

Print Quality

Printability:

Printable PDF pages

Binding Type

Binding:

N/A (Digital PDF Download)

Paper Type

Paper Type:

N/A (Digital PDF Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Air-cooled, four-stroke, horizontally opposed twin-cylinder (Boxer)

Displacement:

1130 cc (69.0 cubic inches)

Bore X Stroke:

95 mm x 79.5 mm (3.74 in x 3.13 in)

Compression Ratio:

10.0:1

Valve Train:

2 valves per cylinder, OHC, pushrod operated (via tappets and pushrods)

Performance

Horsepower Claimed:

95 hp (71 kW) at 7250 rpm

Torque Claimed:

70 lb-ft (95 Nm) at 5500 rpm

Fuel System

Fuel Delivery:

Electronic fuel injection (BMS-K)

Fuel Type:

Unleaded premium gasoline, 91 octane (R+M)/2 or higher

Cooling System

Cooling Method:

Air and oil cooled

🔧 Transmission

Standard

Transmission Type:

6-speed manual, constant mesh

Optional

Transmission Options:

N/A (standard 6-speed manual)

Features

Final Drive:

Shaft drive via single-sided swingarm (Paralever)

Clutch:

Single dry plate, hydraulically operated diaphragm spring clutch

📐 Dimensions

Exterior

Length:

Approximately 2230 mm (87.8 in)

Width Over Fairing:

Approximately 950 mm (37.4 in)

Height Over Fairing:

Approximately 1430 mm (56.3 in)

Weights

Dry Weight:

Approximately 250 kg (551 lbs)

Gross Vehicle Weight Rating:

Approximately 490 kg (1080 lbs)

Fuel Tank Capacity:

25 liters (6.6 US gal), including approx. 4 liters reserve

🛡️ Safety Features

Ratings

ABS System:

Integral ABS II (BMW Motorrad)

Active Features

Braking Performance:

Power-assisted, anti-lock system on both wheels

Passive Features

Lighting System:

Halogen headlight, LED taillight, integrated turn signals

💡 Technology Features

Infotainment

Audio System:

Optional integrated radio/cassette or CD player (model dependent).

Driver Assistance

ABS System Integration:

Integral ABS II, which can be power-assisted for improved braking feel and control.

Connectivity

Diagnostic Port:

On-board diagnostics (OBD) port for fault code retrieval and analysis.

Ergonomic Features

Adjustable Windscreen:

Electrically or manually adjustable windscreen for optimal rider comfort and wind protection.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 10,000 km (6,200 miles) or annually.

Valve Clearance Check:

Typically every 20,000 km (12,400 miles) or as specified.

Brake Fluid Change:

Typically every 2 years.

Fluid Specifications

Engine Oil Type:

SAE 20W-50 or SAE 15W-40 motorcycle-specific oil meeting BMW specifications (e.g., API SG or higher).

Gearbox Oil Type:

SAE 75W-90 synthetic gear oil meeting GL-4 or GL-5 specifications.

Final Drive Oil Type:

SAE 80W-90 gear oil meeting GL-5 specifications.

Brake Fluid Type:

DOT 4 or DOT 5.1 (check manual for specific ABS requirements).

Known Issues

Common Wear Items:

Clutch slave cylinder seal, fuel pump O-ring, alternator brushes, ABS modulator issues.

Electrical Concerns:

Wiring harness chafing, loose connections, Hall sensor issues.

📚 Vehicle History

Brand Heritage

Manufacturer:

Bayerische Motoren Werke AG (BMW)

Model Evolution

Predecessor:

BMW R1100RT

Successor:

BMW R1200RT

Production

Production Years:

1995-2004 (This manual covers models within this range)

🏆 Awards & Recognition

Recognitions

Motorcycle Reviews:

Consistently praised for touring comfort, robust build quality, and shaft-drive reliability by automotive journalists.

Ratings

Reliability Reputation:

Generally considered a reliable and durable motorcycle, especially for long-distance touring.
