DAIHATSU TERIOS 1997-2011 Workshop Service Repair Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

25 people are viewing this right now

Tipo: Car

Proveedor:

SKU: 150062

Etiquetas: 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 Car Daihatsu Engines K3 TERIOS

Variantes de producto

Descripción

The Daihatsu Terios, produced between 1997 and 2011, is a compact SUV recognized for its practical design and capable performance in various conditions. Built with a reputation for reliable engineering, the Terios offered a compelling blend of compact dimensions, fuel efficiency, and robust styling, making it a suitable choice for both urban commuting and light off-road adventures. Many models featured selectable four-wheel drive, enhancing its versatility. This vehicle series includes variations such as the J2 (J200, J210, J211) Series, M101 Series, and J102 Series, often powered by the efficient 1.3L K3-VE DOHC DVVT engine. This comprehensive workshop service repair manual provides in-depth guidance for the Daihatsu Terios (1997-2011). It covers a vast array of systems, including engine mechanics, fuel and emission controls, drivetrain, suspension, brakes, steering, and climate control, among many others. The manual details step-by-step repair procedures, maintenance schedules, troubleshooting guides, and technical specifications, complete with illustrations. Its purpose is to equip owners, mechanics, and technicians with the knowledge necessary to maintain, diagnose, and repair the vehicle effectively, ensuring its longevity and optimal performance.

🏷️ Basic Information

Identification

Make:

Daihatsu

Model:

Terios

Generation

Production Years:

1997-2011

Codes

Chassis Codes:

J2 (J200, J210, J211) Series, M101 Series, J102 Series

👋 Introduction

Market Position

Market Position:

Compact SUV/Mini SUV, positioned as an affordable and practical option for light off-roading and urban use.

Competitive Analysis

Competitors:

Suzuki Jimny, Toyota RAV4 (early models), Mitsubishi Pajero Mini, Honda CR-V (early models)

Key Features

Key Features:

Compact dimensions, selectable 4WD (on many models), fuel efficiency, rugged styling, reliable Daihatsu engineering.

📋 Manual Details

Coverage Areas

Covered Models Years:

Daihatsu Terios (1997-2011), including J2 (J200, J210, J211) Series, M101 (K3-VE2 Engine) Series, J102 (K3-VE Engine) Series

Page Count

Page Count Estimate:

Extensive (exact count not specified, but described as very comprehensive)

Manual Type

Manual Type:

Workshop Service Repair Manual

Language

Language:

English

Format

Format:

PDF (Downloadable)

📖 Manual Coverage

Systems Covered

Systems Covered:

Engine Mechanical, Engine Control, Fuel System, Emission Control, Exhaust System, Cooling System, Lubrication System, Ignition System, Starting System, Charging System, Automatic Transmission, Manual Transmission, Clutch, Transfer Case, Propeller Shaft, Drive Shafts, Differentials, Axles, Suspension, Brakes (Control, Hydraulic, Parking), Steering Column, Power Steering, Air Conditioning, SRS Airbag System, Seat Belt System, Engine Immobilizer, Lighting System, Wiper & Washer System, Door Locks, Meter & Instrument Panel, Audio & Visual Systems, Other Systems, Glass & Windows, Mirrors, Body (Interior & Exterior), Multiplex Communication, CAN Communication

Procedures Included

Procedures Included:

Detailed step-by-step repair procedures, maintenance, servicing, troubleshooting, exploded views, pre-delivery inspection

Technical Depth

Technical Depth:

Comprehensive; covers everything technicians use for repairs, from basic maintenance to advanced diagnostics and component overhaul.

📊 Manual Specifications

File Format

File Format:

Print Quality

Print Quality:

Fully printable (selected pages or whole manual), illustrated with pictures and diagrams

Binding Type

Binding Type:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Options:

1.3L K3-VE DOHC DVVT, 1.4L 3SZ-VE V6 (Note: 1.4L V6 is an unusual specification for the Terios; the common 1.4L is typically inline-4. This likely refers to a specific JDM or regional variant, or a misinterpretation. The primary engine is the K3-VE.)

Performance

K3 Ve Power Output:

Approximately 85-90 PS (63-66 kW) at 6000 rpm (varies by specific model and region)

K3 Ve Torque Output:

Approximately 120-125 Nm (89-92 lb-ft) at 3200 rpm (varies by specific model and region)

Fuel System

Fuel Induction:

Electronic Fuel Injection (EFI)

Engine Mechanical

Valve Train:

DOHC DVVT (Daihatsu Variable Valve Timing)

🔧 Transmission

Standard

Standard Transmission:

5-speed Manual Transmission

Optional

Optional Transmission:

4-speed Automatic Transmission

Features

Drivetrain Options:

Rear-Wheel Drive (RWD) and Selectable Four-Wheel Drive (4WD)

📐 Dimensions

Exterior

Length:

Approx. 3,995 mm (varies slightly by generation/trim)

Width:

Approx. 1,695 mm (varies slightly by generation/trim)

Height:

Approx. 1,655 mm (varies slightly by generation/trim)

Weights

Curb Weight:

Approx. 1,100 - 1,250 kg (varies by specification and drivetrain)

🛡️ Safety Features

Ratings

Safety Rating General:

Varies by market and testing body; generally considered a safe compact SUV for its class during its production period. Specific crash test data may be limited for some regions.

Active Features

Active Safety Features:

ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution) available on some trims/years.

Passive Features

Passive Safety Features:

Front airbags (driver and passenger), seat belt pretensioners.

💡 Technology Features

Infotainment

Infotainment Features:

Basic audio systems (radio, CD player) were common. Higher trims might have offered enhanced audio or rudimentary navigation in later models.

Driver Assistance

Driver Assistance Features:

Limited by modern standards. Features like ABS and EBD were available on certain models. Not equipped with advanced driver-assistance systems (ADAS).

Connectivity

Connectivity Features:

Basic connectivity for audio systems; no integrated smartphone mirroring or advanced telematics in earlier models.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically 5,000-10,000 km or 6-12 months, depending on driving conditions and oil type (refer to manual for specifics).

Air Filter Replacement:

Recommended every 20,000-30,000 km or as per manual's inspection guidelines.

Fluid Specifications

Engine Oil Specification:

API SG/SH/SJ or higher; SAE 5W-30 or 10W-30 recommended (refer to manual for exact viscosity based on climate).

Coolant Specification:

Ethylene glycol based coolant (50% mixture with distilled water); Daihatsu Super Long Life Coolant (SLLC) or equivalent.

Transmission Fluid Manual:

API GL-4 SAE 75W-90 or SAE 80W-90 gear oil.

Transmission Fluid Automatic:

Dexron II/III or equivalent ATF (Automatic Transmission Fluid).

Known Issues

Common Issues:

Minor oil leaks from gaskets, potential wear in suspension components (bushings, ball joints) due to off-road use, potential issues with AC compressors or condensers, catalytic converter issues on high-mileage vehicles.

📚 Vehicle History

Brand Heritage

Brand Heritage:

Daihatsu, a subsidiary of Toyota, has a long history of producing small, fuel-efficient, and reliable vehicles, often focusing on the Kei car segment and compact SUVs.

Model Evolution

Model Evolution Summary:

The Terios was first introduced in 1997 as a compact SUV. The manual covers the first generation (1997-2005) and the second generation (2006-2013), with the specific chassis codes indicating variations within these generations.

Production

Production Locations:

Primarily Japan, with significant production and assembly in other countries like Indonesia (where it was also sold as the Toyota Terios).

🏆 Awards & Recognition

Recognitions

Awards And Recognitions:

Generally well-regarded for its reliability and value in its segment, particularly in Asian markets. Specific industry awards are not widely publicized.
