2007 Ducati M695 Parts Manual

Name: 2007 Ducati M695 Parts Manual
Brand: Ducati
SKU: 124274
Price: 16.99 USD
Availability: InStock

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

19 people are viewing this right now

Tipo: Motorcycle

Proveedor:

Ducati

SKU: 124274

Etiquetas: 2007 Ducati M695 Motorcycle Motorcycles Parts Catalogues

Variantes de producto

Descripción

The 2007 M695 Monster represents an accessible entry into the iconic naked sportbike lineage, celebrated for its distinctive Italian design, the characteristic L-twin engine, and a nimble trellis frame. This motorcycle offers a compelling blend of performance and rider engagement, making it a popular choice for those seeking the unique experience. With its air-cooled, 695 cc L-twin engine producing approximately 73 horsepower, the M695 provides spirited acceleration and a rewarding riding dynamic, embodying the heritage of performance and style. This comprehensive parts manual for the 2007 M695 Monster provides detailed exploded diagrams and part number lists essential for accurate identification and ordering of all OEM components. Covering the engine, clutch, gearbox, fuel system, electrical system, frame, suspension, and braking systems, it facilitates efficient maintenance and repair. The manual is designed to assist owners, technicians, and mechanics in precisely identifying parts for tasks ranging from routine servicing, such as oil changes and filter replacements, to more involved component repairs, ensuring the longevity and optimal performance of the motorcycle.

🏷️ Basic Information

Identification

Make:

Ducati

Model:

M695 Monster

Year:

2007

Type:

Motorcycle

Codes

Vin Decoder Notes:

Specific VIN decoding would require access to Ducati's official VIN database, but generally follows a WMI-VDS-VIS structure.

👋 Introduction

Market Position

Market Position:

The 2007 Ducati M695 Monster was positioned as an accessible entry into Ducati's iconic Monster line, offering a blend of performance, style, and the characteristic L-twin engine experience.

Competitive Analysis

Competitive Analysis:

Competed against other naked sportbikes in its class, such as the Triumph Speed Triple, Yamaha FZ6, and Kawasaki Z750, differentiating itself with its Italian design and V-twin character.

Key Features

Key Features:

Distinctive 'Monster' styling, L-twin desmodromic engine, trellis frame, accessible performance, and a focus on rider engagement.

📋 Manual Details

Coverage Areas

Coverage Areas:

Comprehensive coverage of all mechanical and electrical components for the 2007 Ducati M695 Monster.

Page Count

Page Count:

100

Manual Type

Manual Type:

Parts Manual

Language

Language:

English

Format

Format:

PDF

📖 Manual Coverage

Systems Covered

Systems Covered:

Engine (Crankshaft, Cylinders, Pistons, Timing, Filters, Oil Pump, Half Crankcases, Alternator Cover), Clutch, Gearbox, Gearchange, Fuel System (Fuel Tank, Fuel Induction, Fuel Infeed), Intake System (Air Induction, Inlet Dict), Exhaust System, Electrical System (Electric Starter, Ignition, Instrument Panel, Front Head-light), Frame, Front Fork, Front and Rear Wheels, Brakes (Front Brake, Rear Brake), Handlebar and Controls (Clutch Control), Stands, Plate Holder - Rear Light, Swingarm and Chain, Rear Suspension, Battery Box Mount, Marking Plates.

Procedures Included

Procedures Included:

Identification of all OEM Ducati parts, component breakdown for repair and replacement, part number cross-referencing for ordering.

Technical Depth

Technical Depth:

Detailed exploded diagrams and part number lists for precise identification and ordering of components. Primarily focused on part identification for maintenance and repair rather than step-by-step repair procedures.

📊 Manual Specifications

File Format

File Format:

PDF

Print Quality

Print Quality:

Printable PDF, allowing users to print specific pages as needed, ensuring clarity for diagrams and part numbers.

Binding Type

Binding Type:

Not Applicable (Digital Format)

Paper Type

Paper Type:

Not Applicable (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Type:

L-Twin, four-stroke, desmodromic, 2 valves per cylinder

Displacement:

695 cc

Bore X Stroke:

80 mm x 69 mm

Cooling System:

Air-cooled

Compression Ratio:

9.2:1

Performance

Horsepower:

73 hp @ 8750 rpm (approx.)

Torque:

46 lb-ft @ 7000 rpm (approx.)

Fuel System

Fuel Delivery:

Electronic fuel injection, 38mm throttle body

Fuel Type:

Unleaded gasoline, minimum 95 RON (91 AKI)

Filters And Oil Pump

Oil Filter Type:

Cartridge type

Oil Pump Type:

Gear-driven, wet sump lubrication system

🔧 Transmission

Standard

Transmission Type:

6-speed sequential

Clutch Type:

Wet, multi-plate, hydraulically actuated

Features

Gear Ratios:

Specific gear ratios would be detailed in a full service manual, but are designed for a balance of acceleration and top-end performance.

📐 Dimensions

Exterior

Wheelbase:

Approximately 1400-1410 mm (55.1-55.5 in)

Weights

Dry Weight:

Approximately 168 kg (370 lbs)

Wet Weight:

Approximately 180 kg (397 lbs)

Fuel Tank Capacity:

15 liters (3.96 US gal)

🛡️ Safety Features

Active Features

Braking System:

Dual 320mm discs with 4-piston calipers (front), Single 245mm disc with 2-piston caliper (rear). ABS was typically optional or unavailable on the M695.

Passive Features

Frame Construction:

Steel trellis frame for rigidity and handling.

💡 Technology Features

Infotainment

Infotainment System:

Basic instrument panel with analog tachometer, digital speedometer, odometer, trip meter, and essential warning lights. No advanced infotainment features.

Driver Assistance

Driver Assistance Features:

ABS was an optional feature on some models and years, but not standard on the M695. No other significant electronic rider aids.

Ignition

Ignition System:

Electronic ignition system with ignition timing controlled by the ECU.

🔧 Maintenance

Service Intervals

Major Service Interval:

Typically every 12,000 km (7,500 miles) or annually, whichever comes first. This includes desmodromic valve clearance checks.

Oil Change Interval:

Every 6,000 km (3,750 miles) or annually.

Fluid Specifications

Engine Oil Type:

SAE 10W-40, API SG or higher, JASO MA compliant synthetic or semi-synthetic motorcycle oil. Exact specifications can vary; always consult a service manual for precise requirements. Ducati typically recommends their own branded oils.

Clutch Fluid Type:

DOT 4 brake fluid for the hydraulic clutch actuation.

Brake Fluid Type:

DOT 4 brake fluid for the hydraulic braking system.

Coolant Type:

Not applicable, as the M695 is air-cooled.

Known Issues

Known Issues:

Potential for voltage regulator issues (common on Ducatis of this era), occasional clutch slave cylinder leaks, and standard wear and tear on consumables like brake pads and tires. Desmodromic valve adjustments require specialized knowledge and tools.

Routine Tasks Covered By Manual

Routine Tasks Covered By Manual:

Identification of parts for oil changes, filter replacements, spark plug changes, brake pad replacement, chain and sprocket inspection/replacement, and general component checks.

📚 Vehicle History

Brand Heritage

Brand Heritage:

Ducati is renowned for its Italian design, L-twin engines, and a rich racing heritage, particularly in MotoGP and World Superbike.

Model Evolution

Model Evolution:

The Monster line, introduced in 1993, is characterized by its naked styling and Ducati's signature trellis frame. The M695 was a refinement of earlier Monster models, offering a more refined and accessible package.

Production

Production Years:

The M695 was produced for a limited period, with 2007 being a significant model year.
