    Holden Monaro Pontiac GTO 2004-2006 Service Repair Workshop Manual Pdf

    $16.99
    $16.99
    The Holden Monaro / Pontiac GTO, produced between 2004 and 2006, represents a powerful rear-wheel-drive coupe built on the GM Zeta Platform. This vehicle revived the iconic GTO nameplate for...
    18 people are viewing this right now
    Tipo: Car
    Proveedor:
    Holden
    SKU: 94191
    Etiquetas: 2004 2005 2006 Car Cars Holden Monaro Pontiac GTO
    The Holden Monaro / Pontiac GTO, produced between 2004 and 2006, represents a powerful rear-wheel-drive coupe built on the GM Zeta Platform. This vehicle revived the iconic GTO nameplate for North America, offering a performance-focused experience with its potent V8 engines, including the 5.7L LS1 and the more powerful 6.0L LS2. Known for its muscular styling and driver-centric dynamics, the Monaro/GTO was a significant contender in the performance coupe market, earning a spot on Car and Driver's '10Best' list in 2005. This comprehensive factory service repair workshop manual provides detailed information for the 2004-2006 Holden Monaro and Pontiac GTO models. It covers all essential systems, including the powertrain, chassis, and electrical components, offering in-depth procedures for maintenance, diagnostics, and repair. With over 1000 pages of factory-authorized content, this manual is an indispensable resource for owners, mechanics, and technicians seeking to maintain, troubleshoot, and repair these performance vehicles effectively.
    🏷️ Basic Information
    Identification
    Make:
    Holden / Pontiac
    Model:
    Monaro / GTO
    Model Years Covered:
    2004, 2005, 2006
    Codes
    Platform Code:
    GM Zeta Platform
    Internal Chassis Code:
    V2 (Holden), VY/VZ Series (Holden basis)
    👋 Introduction
    Market Position
    Positioning:
    A powerful, rear-wheel-drive coupe that revived the iconic GTO nameplate for the North American market, while continuing its lineage as the Holden Monaro in Australia. Targets enthusiasts seeking performance and a distinctive muscle car experience.
    Competitive Analysis
    Competitors:
    Ford Mustang, Chevrolet Camaro (prior generations), Dodge Challenger (later generation).
    Key Features
    Performance Focus:
    Emphasis on V8 engine power, rear-wheel-drive dynamics, and a driver-centric experience.
    Manual Value Proposition:
    Provides the essential, factory-authorized information for owners and independent mechanics to maintain, diagnose, and repair this performance coupe effectively.
    📋 Manual Details
    Coverage Areas
    Regions Covered:
    North America (Pontiac GTO), Australia (Holden Monaro)
    Page Count
    Estimated Pages:
    1000+
    Manual Type
    Type:
    Factory Service Repair Workshop Manual
    Language
    Language:
    English
    Format
    Format:
    PDF (Digital Download)
    📖 Manual Coverage
    Systems Covered
    Powertrain:
    Engine (LS1, LS2), Transmission (Manual & Automatic), Drivetrain, Exhaust System
    Chassis:
    Suspension (Front & Rear), Steering System, Brake System (ABS)
    Electrical:
    Wiring Diagrams, Lighting, Instruments, Audio System, Security System, Powertrain Control Module (PCM), Body Control Module (BCM)
    Body:
    Exterior Body Panels, Doors, Hood, Trunk, Interior Trim, HVAC System, Seats, Glass
    Procedures Included
    Maintenance:
    Scheduled Maintenance, Oil Changes, Filter Replacements, Fluid Checks & Changes
    Diagnostics:
    Troubleshooting Guides, Diagnostic Trouble Codes (DTCs), Symptom-Based Diagnosis
    Repair:
    Engine Mechanical Repair, Transmission Overhaul, Suspension Component Replacement, Brake System Overhaul, Electrical Component Repair
    Installation:
    Component Replacement Procedures, Aftermarket Part Installation Guidelines (implied)
    Technical Depth
    Depth:
    Comprehensive; covers basic maintenance to full engine and transmission rebuilds, including detailed electrical schematics and diagnostic procedures.
    📊 Manual Specifications
    File Format
    Compatibility:
    Windows and macOS
    Print Quality
    Printability:
    High-resolution, printable pages
    Binding Type
    Binding:
    N/A (Digital Download)
    Paper Type
    Paper Type:
    N/A (Digital Download)
    Licensing
    Usage Rights:
    Unlimited use on multiple devices, lifetime access
    ⚙️ Engine Specifications
    Primary Engine
    Engine Code 2004:
    LS1
    Engine Displacement 2004:
    5.7L (350 ci)
    Engine Configuration 2004:
    V8, OHV, 2 Valves per Cylinder
    Engine Code 2005 2006:
    LS2
    Engine Displacement 2005 2006:
    6.0L (364 ci)
    Engine Configuration 2005 2006:
    V8, OHV, 2 Valves per Cylinder
    Performance
    Horsepower Ls1:
    325 hp @ 5200 rpm (approx.)
    Torque Ls1:
    330 lb-ft @ 4000 rpm (approx.)
    Horsepower Ls2:
    400 hp @ 6000 rpm (approx.)
    Torque Ls2:
    395 lb-ft @ 4400 rpm (approx.)
    Fuel System
    Injection Type:
    Sequential Fuel Injection (SFI)
    Fuel Type:
    Unleaded Premium Gasoline (91 Octane or higher recommended)
    🔧 Transmission
    Standard
    Transmission Type 2004:
    T-56 6-Speed Manual
    Optional
    Transmission Type 2004 2006:
    4L60-E 4-Speed Automatic
    Features
    Clutch Type:
    Hydraulic Actuated
    Rear Axle Ratio Manual:
    3.46:1 (typical)
    Rear Axle Ratio Auto:
    3.08:1 (typical)
    Fluid Specifications
    Manual Transmission Fluid:
    Dexron III-G or equivalent (check manual for exact spec)
    Automatic Transmission Fluid:
    Dexron III-G or Dexron VI (check manual for exact spec)
    📐 Dimensions
    Exterior
    Wheelbase:
    Approx. 110.2 inches (2800 mm)
    Length:
    Approx. 190.5 inches (4839 mm)
    Width:
    Approx. 74.7 inches (1897 mm)
    Height:
    Approx. 54.6 inches (1387 mm)
    Weights
    Curb Weight Manual:
    Approx. 3700-3800 lbs (1680-1725 kg)
    Curb Weight Auto:
    Approx. 3750-3850 lbs (1700-1745 kg)
    Gross Vehicle Weight Rating:
    Approx. 4600 lbs (2087 kg)
    Cargo
    Trunk Volume:
    Approx. 15.7 cubic feet (445 Liters)
    🛡️ Safety Features
    Ratings
    NHTSA Front Impact:
    5-Star (Driver & Passenger) - 2005 Model Year
    IIHS Front Offset:
    Good
    Active Features
    Brakes:
    4-wheel disc brakes, ABS (Anti-lock Braking System)
    Traction Control:
    Available (TCS)
    Passive Features
    Airbags:
    Frontal airbags (Driver & Passenger), Side-impact airbags (available)
    Seatbelts:
    3-point height-adjustable front seat belts, Pretensioners, Load limiters
    💡 Technology Features
    Infotainment
    Audio System:
    Premium AM/FM/CD player with optional subwoofer and amplifier.
    Instrument Cluster:
    Analog gauges with driver information center.
    Driver Assistance
    Cruise Control:
    Standard
    Parking Sensors:
    Not typically available from factory.
    Connectivity
    Bluetooth:
    Not available from factory; requires aftermarket installation.
    Usb Ports:
    Not available from factory; requires aftermarket installation.
    🔧 Maintenance
    Service Intervals
    Oil Change Interval:
    Every 7,500 miles (12,000 km) or 12 months, whichever comes first (synthetic oil recommended).
    Engine Coolant Flush:
    Every 30,000 miles (48,000 km) or 24 months.
    Transmission Fluid Change:
    Automatic: Every 50,000 miles (80,000 km). Manual: Check fluid level periodically, change as needed or every 100,000 miles (160,000 km).
    Fluid Specifications
    Engine Oil Capacity:
    5.7L: Approx. 5.5 quarts (5.2 L) with filter. 6.0L: Approx. 6.0 quarts (5.7 L) with filter.
    Engine Oil Type:
    SAE 5W-30 (Synthetic recommended for optimal performance and protection).
    Coolant Type:
    Dex-Cool (Orange, long-life coolant, compatible with aluminum engines).
    Known Issues
    Power Steering Pump:
    Leaking seals or noise can be common.
    Window Regulators:
    Can be prone to failure, leading to windows not operating correctly.
    Clutch Wear:
    With spirited driving, clutch wear can be accelerated on manual transmission models.
    Interior Rattles:
    Some owners report minor interior trim rattles over time.
    📚 Vehicle History
    Brand Heritage
    Holden Legacy:
    The Monaro nameplate has a long and celebrated history in Australia, representing Holden's personal luxury coupe line since the 1960s.
    Model Evolution
    Gto Revival:
    The Pontiac GTO was a rebadged version of the Australian Holden Monaro, specifically developed for the North American market to capitalize on the resurgence of muscle car interest.
    Production
    Manufacturing Location:
    Adelaide, South Australia, Australia
    Production Years:
    Holden Monaro (Australia): 2001-2006; Pontiac GTO (North America): 2004-2006
    🏆 Awards & Recognition
    Recognitions
    Car And Driver నించ:
    Named to Car and Driver's '10Best' list in 2005.
    Motor Trend 評價:
    Praised for its V8 power and muscular styling, often compared favorably to its American muscle car rivals.
    Certifications
    Manual Certification:
    Factory Authorized Content
