Target Audience:
Husqvarna TR650 Strada Terra owners, DIY mechanics, professional workshops.
Value Proposition:
Saves significant labor costs ($50-$60 per hour) by enabling owners to perform their own maintenance and repairs. Provides factory-level knowledge.
Manual Source:
Actual Genuine Factory Manuals, not 3rd party reproductions.
Completeness:
COMPLETE official full factory service repair manual. Every detail relating to the vehicle is covered.
Instruction Style:
Step-by-step instructions, numbered instructions, notes, cautions, and warnings.
Visual Aids:
Hundreds of illustrations, diagrams, and photos.
Engine Mechanical:
Top End, Lubrication System, Engine Removal/Installation
Fuel System:
Fuel System Components, Fuel Injection, Fuel Pump, Filters
Cooling System:
Radiator, Coolant, Fan, Thermostat
Drivetrain:
Clutch, Crankshaft, Transmission, Final Drive
Wheels And Tires:
Wheel Specifications, Tire Installation, Balancing
Brakes:
Brake System Components, Hydraulic System, Disc and Pad Service
Suspension:
Front Fork, Rear Shock Absorber, Adjustment Procedures
Steering:
Handlebar, Triple Clamps, Steering Head Bearings
Frame:
Frame Structure, Bodywork Fasteners, Subframe
Electrical System:
Wiring Diagrams, Ignition System, Lighting, Battery, Charging System, ECU
General Information:
Vehicle Identification, Specifications, Torque Values, General Maintenance
Maintenance:
Scheduled Maintenance, Oil Changes, Filter Replacements, Chain Adjustment
Diagnostics:
Troubleshooting Engine Faults, Electrical System Diagnostics, Component Testing
Repair:
Step-by-step repair procedures for all covered systems, including engine rebuilds, transmission overhauls, brake servicing, suspension repairs.
Tuning:
Performance tuning and adjustment guidance
Depth:
Comprehensive factory-level detail, covering everything from basic maintenance to complete engine and component rebuilds. Designed for both DIY owners and professional technicians.
Diagnostic Tools:
Covers diagnostic techniques and interpretation of symptoms.
Wiring Diagrams:
Detailed, traceable wiring diagrams for the entire electrical system.
Troubleshooting Guide:
Advanced troubleshooting guide with 'secret techniques' used by top mechanics.
Component Identification:
Detailed illustrations, drawings, and photos with enlarged insets for precise part identification and examination.
Readability:
Requires Adobe PDF Reader
Compatibility:
Compatible with all PC-based Windows operating systems and Mac.
Resolution:
High Resolution
Print Options:
Print individual pages, chapters, or the entire manual.
Binding:
Digital Download (user printable, can be burned to CD-ROM)
Paper Type:
N/A (Digital Download)
Engine Type:
Single-cylinder, four-stroke
Displacement:
652 cc (39.8 cu in)
Bore X Stroke:
100 mm x 83 mm (3.94 in x 3.27 in)
Engine Management:
Electronic Fuel Injection (EFI)
Horsepower:
Approx. 47 hp (35 kW) @ 7000 rpm (Exact figure may vary slightly by region)
Torque:
Approx. 44 lb-ft (60 Nm) @ 5000 rpm (Exact figure may vary slightly by region)
Fuel Delivery:
Electronic Fuel Injection (EFI) with single throttle body
Fuel Type:
Unleaded Gasoline
Fuel Tank Capacity:
Approx. 12 liters (3.17 US gallons)
Length:
Approx. 2230 mm (87.8 in)
Width:
Approx. 890 mm (35.0 in) (at handlebars)
Height:
Approx. 1370 mm (53.9 in) (at windshield)
Seat Height:
Approx. 860 mm (33.9 in)
Ground Clearance:
Approx. 200 mm (7.9 in)
Dry Weight:
Approx. 160 kg (352.7 lbs)
Wet Weight:
Approx. 180 kg (396.8 lbs) (fully fueled)
Max Load:
Not specified, but typical for this class of motorcycle is around 200 kg including rider and luggage.
Infotainment System:
N/A (Basic motorcycle instrumentation)
Instrumentation:
Analog tachometer, digital speedometer, trip odometer, fuel gauge, gear indicator, warning lights.
ABS:
Optional ABS system, which can be toggled on/off.
Connectivity Features:
N/A
Oil Change Interval:
Typically every 10,000 km or 1 year, whichever comes first (refer to manual for exact specification).
Valve Clearance Check:
Typically every 10,000 km or 20,000 km (refer to manual for exact specification).
Engine Oil Type:
API SG/SH/SJ or higher, JASO MA certified, SAE 10W-50 motorcycle oil (refer to manual for exact specification and capacity).
Coolant Type:
Ethylene glycol based coolant with corrosion inhibitors (refer to manual for specific mixture and capacity).
Brake Fluid Type:
DOT 4 (refer to manual for exact specification).
Common Wear Items:
Chain and sprockets, brake pads, tires, clutch plates (depending on usage).
Potential Issues:
Some owners report occasional electrical gremlins or fuel injection system quirks, though generally considered reliable due to BMW components. Check for recalls.
Brand Origin:
Husqvarna Motorcycles, originally Swedish, established in 1689, with motorcycle production starting in 1903. Now part of the Pierer Mobility Group (KTM).
Development:
The TR650 Strada and Terra models were developed by Husqvarna during its ownership by BMW Motorrad. They share significant components and engineering with BMW's G 650 GS platform, particularly the Sertão variant.
Production Period:
2013-2014
Manufacturing Location:
Made in Italy (under BMW ownership)
