KAWASAKI KLR 600 Service Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

29 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 90233

Etiquetas: Kawasaki KLR 600 KLR Series Motorcycle Motorcycles

Variantes de producto

Descripción

The Kawasaki KLR600, produced from 1984 to 1989, is a versatile dual-sport motorcycle renowned for its ruggedness and reliability. Engineered to excel in both on-road commuting and off-road exploration, this model features a robust 564 cc air-cooled, single-cylinder engine with DOHC and four valves, delivering approximately 45 PS. Its design emphasizes durability, with a high-tensile steel semi-double cradle frame, long-travel suspension, and a front disc brake complemented by a rear drum brake. The KLR600's legacy is built on its foundational role in Kawasaki's KLR line, offering riders a capable and enduring machine that has earned recognition for its contribution to the dual-sport segment. This comprehensive service and repair manual provides detailed guidance for the Kawasaki KLR600 models A1 through A6. It covers all essential aspects of maintenance, from routine oil changes and filter replacements to complex engine and transmission overhauls. Included are in-depth procedures for diagnosing and repairing issues across the engine, fuel system, ignition, drivetrain, suspension, brakes, and electrical systems. The manual also features troubleshooting charts, technical specifications, and detailed illustrations, including exploded views and wiring schematics, to assist owners and technicians in maintaining the optimal performance and longevity of their KLR600.
