Kawasaki KVF 360 Prairie KVF360 Complete Workshop Service Repair Manual 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

The KVF360 Prairie, also known by its model designation KVF360, represents a capable mid-size utility All-Terrain Vehicle (ATV) produced from 2003 through 2013. Built upon a legacy of durable and...

28 people are viewing this right now

Tipo: Atv

Proveedor:

SKU: 75774

Etiquetas: 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 ATV Kawasaki KVF 360 Prairie KVF360 Powersports Prairie Models

Variantes de producto

Descripción

The KVF360 Prairie, also known by its model designation KVF360, represents a capable mid-size utility All-Terrain Vehicle (ATV) produced from 2003 through 2013. Built upon a legacy of durable and reliable off-road machines, the KVF360 offers a robust platform designed for both demanding work and recreational trail riding. Key features include a liquid-cooled 362 cc engine, automatic continuously variable transmission (CVT) with high/low range gearing, selectable 2WD/4WD capability, and a limited-slip front differential, all contributing to its dependable performance in various terrains. Its strong value proposition lies in delivering solid utility and reliable operation at a competitive price point, making it an accessible choice for a wide range of users. This comprehensive workshop service repair manual provides detailed information for the KVF360 Prairie covering model years 2003 to 2013. It serves as an essential resource for owners, mechanics, and technicians, offering in-depth coverage of all major vehicle systems, including engine overhaul, fuel and ignition systems, transmission, drivetrain, suspension, braking, and electrical systems. The manual includes detailed maintenance procedures, step-by-step repair instructions, troubleshooting guides, and precise technical specifications and tolerances. Its high-resolution format ensures clarity for all procedures, from routine maintenance such as oil changes and filter replacements to complex repairs like engine rebuilds and electrical diagnostics, enabling effective upkeep and repair of the vehicle.

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

KVF360 Prairie

Model Designation:

KVF360

Generation

Generation Name:

First Generation Prairie 360

Codes

Chassis Code:

Likely KVF360

👋 Introduction

Market Position

Market Segment:

Mid-size utility ATV (All-Terrain Vehicle).

Competitive Analysis

Key Competitors:

Honda FourTrax 350/400, Yamaha Kodiak 400/450, Polaris Sportsman 400/500, Suzuki TwinPeaks 700 (though slightly higher displacement).

Key Features

Value Proposition:

Offers robust utility and reliable performance at a competitive price point, making it an accessible option for serious off-road work and recreation.

📋 Manual Details

Coverage Areas

Covered Years:

2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013

Page Count

Estimated Page Count:

Likely 300-500 pages (typical for complete workshop manuals)

Manual Type

Manual Type:

Complete Workshop Service Repair Manual

Language

Language:

English

Format

Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine Systems:

Engine overhaul, lubrication system, cooling system, fuel system (carburetor/injection depending on sub-model), ignition system, exhaust system, emissions control, engine diagnostics.

Transmission Systems:

Automatic transmission (CVT) operation, maintenance, repair, belt inspection/replacement, torque converter.

Drivetrain Systems:

Four-wheel drive (4WD) system, limited-slip front differential, rear differential, drive shafts, CV joints, U-joints, wheel bearings.

Suspension Systems:

Front independent suspension (MacPherson strut or A-arm), rear solid axle or independent suspension (depending on sub-model), shock absorbers, springs, bushings, control arms, alignment procedures.

Braking Systems:

Hydraulic brake system, front and rear disc brakes, brake calipers, brake pads, brake lines, master cylinder, bleeding procedures.

Electrical Systems:

Battery, charging system (stator, regulator/rectifier), starting system (starter motor, solenoid), lighting system (headlights, taillights, indicators), ignition switch, wiring diagrams, fuse box, relays, electrical component testing.

Fuel And Exhaust:

Fuel tank, fuel pump, fuel lines, carburetor or fuel injection system, muffler, exhaust pipes, catalytic converter (if applicable).

Chassis And Body:

Frame inspection and repair, body panels, fenders, seat, handlebars, racks, skid plates, lighting components, body trim.

Procedures Included

Maintenance Procedures:

Scheduled maintenance intervals, oil changes, filter replacements (oil, air), spark plug replacement, valve clearance adjustment, brake fluid changes, coolant flushes, lubrication points.

Repair Procedures:

Engine rebuilds, transmission overhaul, suspension component replacement, brake system repairs, electrical troubleshooting and repair, steering system repairs, drive axle repairs.

Troubleshooting Guides:

Step-by-step diagnostic procedures for common problems, fault code interpretation (if applicable), symptom-based troubleshooting.

Specifications And Tolerances:

Detailed technical specifications for all major components, torque values, clearances, measurements, and material specifications.

Technical Depth

Technical Depth:

Comprehensive from basic user maintenance to complete engine and transmission rebuilds. Includes detailed diagnostic procedures and component-level repair.

📊 Manual Specifications

File Format

File Format:

PDF (Portable Document Format)

Print Quality

Print Quality:

High-resolution, suitable for printing individual pages or the entire manual.

Binding Type

Binding Type:

N/A (Digital Download - User Printable)

Paper Type

Paper Type:

N/A (Digital Download - User Printable)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Four-stroke, SOHC, V-twin (for some earlier Prairie models, but KVF360 is typically single-cylinder)

Displacement:

362 cc (Cubic Centimeters)

Bore X Stroke:

Approx. 85.0 mm x 63.0 mm (typical for KVF360)

Compression Ratio:

Approx. 9.0:1

Performance

Horsepower:

Approx. 18-20 HP (Horsepower) at 6000 RPM (estimated, model dependent)

Torque:

Approx. 21-23 lb-ft (Pound-feet) at 4500 RPM (estimated, model dependent)

Fuel System

Fuel Delivery:

Carburetor (Mikuni BSR42) or potentially early fuel injection on some specific sub-models, though carburetor is most common for KVF360.

Cooling System

Cooling Method:

Liquid-cooled

Ignition System

Ignition Type:

CDI (Capacitor Discharge Ignition)

🔧 Transmission

Standard

Transmission Type:

Automatic (Kawasaki Automatic Revolution - K.A.R.V. CVT)

Optional

Gear Reduction:

Yes (High/Low range gearing)

Features

Drive Modes:

2WD / 4WD selection

Differential Lock:

Front differential lock (variable electronic control or manual engagement depending on sub-model)

Fluid Type

Cvt Fluid:

Kawasaki Genuine Transmission Oil or equivalent (specific viscosity and API rating detailed in manual).

📐 Dimensions

Exterior

Overall Length:

Approx. 80.1 inches (2035 mm)

Overall Width:

Approx. 44.7 inches (1135 mm)

Overall Height:

Approx. 46.5 inches (1180 mm)

Wheelbase:

Approx. 48.2 inches (1225 mm)

Weights

Dry Weight:

Approx. 553 lbs (251 kg)

Curb Weight:

Approx. 593 lbs (269 kg)

Cargo

Front Rack Capacity:

Approx. 100 lbs (45 kg)

Rear Rack Capacity:

Approx. 187 lbs (85 kg)

Towing Capacity:

Approx. 1,250 lbs (567 kg)

Wheels Tires

Front Tire Size:

AT25x8-12

Rear Tire Size:

AT25x10-12

Wheel Bolt Pattern:

Likely 4x110mm

🛡️ Safety Features

Ratings

Atv Safety Considerations:

Adherence to ATV safety guidelines, proper protective gear (helmet, eyewear, gloves, boots), responsible riding practices.

Active Features

Braking System Type:

Hydraulic disc brakes front and rear for effective stopping power.

Engine Braking:

CVT provides a degree of engine braking effect, especially in lower gears.

Passive Features

Frame Construction:

Robust steel frame designed for durability and load-bearing capacity.

Ergonomics:

Comfortable seating position, intuitively placed controls, and effective handlebar ergonomics for rider control.

💡 Technology Features

Infotainment

Infotainment System:

N/A (Utility ATV, typically no integrated infotainment system beyond basic controls).

Driver Assistance

Driver Assistance Features:

Selectable 2WD/4WD, limited-slip front differential, electronic fuel gauge, neutral and reverse indicator lights.

Connectivity

Connectivity Options:

N/A (No specific connectivity features beyond basic vehicle operation).

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 600 miles or 6 months, whichever comes first (refer to manual for specific interval for break-in period).

Air Filter Cleaning Or Replacement:

Check every 600 miles; clean or replace as needed. More frequently in dusty conditions.

Spark Plug Replacement:

Every 3,600 miles or 24 months.

Cv Belt Inspection:

Inspect every 1,200 miles or 12 months for wear and proper tension.

Fluid Specifications

Engine Oil Type:

SAE 10W-40 API SG or higher, JASO MA certified (specific recommendations in manual).

Engine Oil Capacity:

Approx. 1.9 US qt (1.8 L) with filter change.

Coolant Type:

Permanent type ethylene glycol based coolant (50/50 mix with distilled water).

Brake Fluid Type:

DOT 3 or DOT 4 brake fluid.

Known Issues

Common Wear Items:

CVT belt wear, suspension bushings, wheel bearings, and brake pads are common wear items requiring periodic inspection and replacement.

Potential Carburetor Issues:

Carburetor can be prone to clogging with fuel varnish if the ATV is stored with fuel for extended periods without treatment.

📚 Vehicle History

Brand Heritage

Kawasaki Atv Legacy:

Kawasaki has a long-standing reputation for building durable and capable ATVs, with the Prairie line being a significant contributor to their utility ATV segment.

Model Evolution

Kvf Series Development:

The KVF360 Prairie succeeded earlier Prairie models, offering refinements and a robust platform for utility and recreational riding.

Production

Manufacturing Location:

Typically manufactured by Kawasaki Heavy Industries in Japan or its manufacturing facilities in North America.

🏆 Awards & Recognition

Recognitions

Industry Recognition:

While specific awards are not highlighted, the KVF360 Prairie was generally well-regarded for its robust utility and reliability in its class.
