2009-2011 Kawasaki Mule 4000 4010 4x4 UTV Repair Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

🏷️ Basic Information Identification Make: Kawasaki Model: Mule 4000 / 4010 Year: 2009, 2010, 2011 Model Code: KAF620 Vehicle Type: Utility Task Vehicle (UTV) Drivetrain: 4x4 📋 Manual Details Publication...

21 people are viewing this right now

Tipo: Utv

Proveedor:

SKU: 46431

Etiquetas: 2009 2010 2011 Kawasaki Mule Mule 4000 Mule 4010 4x4 Powersports UTV

Variantes de producto

Descripción

🏷️ Basic Information

Identification

Make:

Kawasaki

Model:

Mule 4000 / 4010

Year:

2009, 2010, 2011

Model Code:

KAF620

Vehicle Type:

Utility Task Vehicle (UTV)

Drivetrain:

📋 Manual Details

Publication

Manual Type:

Factory Service / Repair Manual

Format:

PDF Download

Source:

ClassicCirculations.com

Language:

English

Content

Coverage:

Repair, Maintenance, Parts Lookup

Topics Covered:

General Information, Routine Maintenance, Engine, Fuel System, Lubrication, Cooling, Transmission, Steering, Shocks, Body Work, Intake, Exhaust, Electrical System, Troubleshooting

⚙️ Engine Specifications

Engine Configuration

Engine Type:

4-stroke, Liquid-cooled, V-twin, OHV

Displacement:

617 cc (37.6 cu in)

Bore X Stroke:

74.0 x 72.0 mm (2.9 x 2.8 in)

Compression Ratio:

9.8:1

Fuel System

Fuel Delivery:

Carbureted (Mikuni B24-1 x 2)

Ignition

Ignition Type:

🔧 Transmission

Drivetrain

Transmission Type:

Continuously Variable Transmission (CVT) with High/Low range and Reverse

Drive System:

Shaft Drive, Selectable 4WD

📐 Dimensions

Physical

Length:

2790 mm (109.8 in)

Width:

1560 mm (61.4 in)

Height:

1885 mm (74.2 in)

Wheelbase:

1835 mm (72.2 in)

Ground Clearance:

190 mm (7.5 in)

Dry Weight:

645 kg (1422 lbs)

🔧 Maintenance

Fluid Capacities

Engine Oil Capacity:

1.7 L (1.8 US qt) with filter change

Transmission Fluid Type:

API GL-4 SAE 80W-90 Gear Oil

Coolant Capacity:

1.6 L (1.7 US qt)

Service Intervals

Engine Oil Change:

First 20 hours, then every 100 hours or 6 months

Air Filter Cleaning:

Every 50 hours

Spark Plug Replacement:

Every 100 hours or 12 months
