KTM 950 990 Super Duke Workshop Service Repair Manual 2003-2007

$16.99
$16.99
The KTM 950 Super Duke and 990 Super Duke, produced between 2003 and 2007, represent high-performance naked sportbikes powered by a potent V-twin, four-stroke LC8 engine. Known for their aggressive...
21 people are viewing this right now
Tipo: Motorcycle
Proveedor:
Ktm
SKU: 136623
Etiquetas: 2003 2004 2005 2006 2007 950 Super Duke 990 990 Super Duke KTM Motorcycle Motorcycles
KTM 950 990 Super Duke Workshop Service Repair Manual 2003-2007
The KTM 950 Super Duke and 990 Super Duke, produced between 2003 and 2007, represent high-performance naked sportbikes powered by a potent V-twin, four-stroke LC8 engine. Known for their aggressive styling, lightweight chassis, and sophisticated components like WP suspension and Brembo brakes, these models offer a sporty and engaging riding experience. Building on KTM's off-road racing heritage, the Super Duke line delivers exceptional handling and strong torque, positioning them as formidable competitors in their segment. This workshop service repair manual provides comprehensive guidance for the KTM 950 and 990 Super Duke models from 2003-2007. It covers essential maintenance procedures, detailed repair instructions for all major systems including the engine, fuel, ignition, clutch, transmission, suspension, brakes, and electrical systems, as well as troubleshooting guidance. The manual is designed to assist owners, mechanics, and technicians in maintaining the peak performance and longevity of their vehicles through step-by-step instructions, technical specifications, and diagrams.
🏷️ Basic Information
Identification
Make:
KTM
Model:
990 Super Duke
Year:
2003-2007
Engine Type:
V-Twin, Four-Stroke
Engine Subtype:
LC8
👋 Introduction
Market Position
Market Segment:
High-performance naked sportbike
Competitive Analysis
Competitors:
Ducati Monster, Triumph Speed Triple, Aprilia Tuono
Key Features
Engine Type:
V-twin, known for strong torque and character
Chassis Design:
Lightweight, high-quality components (e.g., WP suspension, Brembo brakes)
Rider Ergonomics:
Aggressive, sporty riding position suitable for spirited riding.
📋 Manual Details
Coverage Areas
Covered Models:
KTM 950 Super Duke, KTM 990 Super Duke
Covered Years:
2003, 2004, 2005, 2006, 2007
Page Count
Page Count Estimate:
Comprehensive (Actual page count not specified, but described as 'Extremely detailed')
Manual Type
Manual Type:
Workshop Service Repair Manual
Language
Language:
English (Assumed based on product description and common manual languages)
Format
Format:
PDF
📖 Manual Coverage
Systems Covered
Engine:
Complete engine overhaul, internal components, timing, valve clearance, lubrication
Fuel System:
Fuel injection system, throttle bodies, fuel pump, injectors
Ignition System:
Ignition coils, spark plugs, ECU diagnosis
Clutch:
Clutch assembly, hydraulic system, clutch plates
Transmission:
Gearbox operation, gear ratios, internal components, maintenance
Suspension:
Front forks (WP USD), rear shock absorber, adjustments, servicing
Wheels:
Wheel bearings, rim types, spoke tension (if applicable to specific models)
Braking System:
Front and rear calipers (Brembo), master cylinders, brake lines, bleeding procedures, pad replacement
Electrical System:
Wiring diagrams, lighting, battery, starter, charging system, fuses, relays
Bodywork:
Fairings, tank, seat, panels, removal and installation
Air Temperature Control System:
Likely refers to engine intake air management and associated sensors/components.
Procedures Included
Maintenance:
Oil changes, filter replacements, chain adjustment, spark plug replacement, fluid checks
Repair:
Engine rebuild, gearbox repair, suspension overhaul, brake system repair, electrical diagnostics
Troubleshooting:
Diagnostic procedures for various systems, fault finding based on symptoms
Component Replacement:
Detailed steps for replacing all major and minor components
Special Tools:
Identification and usage of KTM-specific tools
Technical Depth
Depth:
Full workshop level, from basic servicing to complete engine and gearbox rebuilds.
Documentation Type:
Step-by-step instructions, detailed diagrams, exploded views, torque specifications, fluid capacities.
📊 Manual Specifications
File Format
File Format:
PDF
Print Quality
Printability:
All pages are printable
Binding Type
Binding Type:
N/A (Digital PDF)
Paper Type
Paper Type:
N/A (Digital PDF)
Searchability
Search Functionality:
PDF format typically allows for text search (depending on PDF creation)
⚙️ Engine Specifications
Primary Engine
Engine Configuration:
75-degree V-Twin, four-stroke, liquid-cooled
Displacement 950:
942 cc
Displacement 990:
999 cc
Performance
Horsepower 950:
Approx. 98 HP (72 kW) at 9000 rpm
Horsepower 990:
Approx. 110 HP (81 kW) at 9000 rpm
Torque 950:
Approx. 95 Nm (70 lb-ft) at 7000 rpm
Torque 990:
Approx. 98 Nm (72 lb-ft) at 7000 rpm
Fuel System
Fuel Delivery:
Electronic fuel injection (EFI), dual throttle bodies
Fuel Type:
Unleaded gasoline, minimum octane rating typically 91
🔧 Transmission
Standard
Transmission Type:
6-speed, constant mesh
Features
Clutch Type:
Hydraulically operated wet multi-plate clutch
Final Drive:
Chain drive
📐 Dimensions
Exterior
Seat Height Approx:
870 mm (34.3 inches) - Subject to variation
Weights
Dry Weight Approx 950:
189 kg (417 lbs)
Dry Weight Approx 990:
191 kg (421 lbs)
🛡️ Safety Features
Ratings
Safety Ratings:
N/A (Motorcycle safety is typically assessed by specific component performance and design, not standardized crash ratings like cars).
Active Features
Brakes:
High-performance Brembo braking system (dual discs front, single disc rear).
Suspension:
Quality WP suspension components for stable handling.
Passive Features
Frame:
Chromium-molybdenum steel trellis frame for rigidity and impact absorption.
💡 Technology Features
Infotainment
Infotainment System:
Basic digital dashboard with essential readouts (speed, RPM, odometer, trip meters, fuel level, coolant temp).
Driver Assistance
Driver Assistance Features:
No electronic rider aids like ABS or traction control were standard on these early models. Later 990 variants introduced these.
Connectivity
Connectivity Features:
N/A
🔧 Maintenance
Service Intervals
Oil Change Interval:
Typically 7,500 km (4,660 miles) or 12 months, whichever comes first (Refer to manual for exact specification).
Valve Clearance Interval:
Typically every 15,000 km (9,320 miles) (Refer to manual for exact specification).
Spark Plug Replacement Interval:
Typically every 15,000 km (9,320 miles) (Refer to manual for exact specification).
Fluid Specifications
Engine Oil:
KTM recommends specific grades of synthetic motorcycle oil, often SAE 10W-50 or 15W-50 (Consult manual for precise API and JASO specifications).
Coolant:
Ethylene glycol-based antifreeze mixture (typically 50% coolant, 50% distilled water).
Brake Fluid:
DOT 4 or DOT 5.1 brake fluid (Check manual for specific requirement).
Clutch Fluid:
DOT 4 or DOT 5.1 brake fluid (Typically shared with brake system, check manual).
Known Issues
Common Wear Items:
Clutch slave cylinder seals, fuel pump internal components, regulator/rectifier can be prone to failure under high heat/load.
Maintenance Importance:
Adherence to service intervals is crucial for longevity, especially regarding valve clearances and oil changes due to the high-performance nature of the engine.
📚 Vehicle History
Brand Heritage
Brand Focus:
KTM is renowned for its off-road racing heritage and performance-oriented motorcycles.
Model Evolution
Super Duke Lineage:
The Super Duke line represents KTM's entry into the high-performance street naked segment, building on their powerful V-twin engine technology.
Production
Manufacturing Location:
Austria (KTM's primary manufacturing base)
🏆 Awards & Recognition
Recognitions
Industry Reception:
The Super Duke models were generally well-received for their performance, handling, and unique character within the sportbike segment.
Ratings
Performance Ratings:
