Model Years Covered:
2013, 2014, 2015
Regions Covered:
Global (all markets where Pajero/Shogun/Montero were sold)
Models Covered:
All Pajero, Shogun, and Montero variants
Engine Variants Covered:
All factory-supplied engine options for the specified model years
Trim Levels Covered:
All trim levels and configurations
Transmission Types Covered:
All factory transmission options (e.g., Automatic, Manual)
Estimated Page Count:
Extensive (typically 1500+ pages for complete workshop manuals)
Type:
Complete Workshop Service Repair Manual
Engine Mechanical:
Engine assembly, disassembly, cylinder head, block, pistons, crankshaft, camshafts, lubrication, cooling, timing systems
Engine Management:
Fuel injection, ignition, emission control, sensor diagnostics, ECU troubleshooting
Transmission Automatic:
Automatic transmission overhaul, hydraulic control, torque converter, electronic controls, fluid service
Transmission Manual:
Manual transmission overhaul, clutch system, gearshift mechanism
Drivetrain:
Front and rear axles, differentials, driveshafts, transfer case, Super Select 4WD system
Suspension:
Front and rear suspension systems, shock absorbers, springs, control arms, bushings, alignment specifications
Brakes:
Brake system components (discs, pads, calipers, master cylinder, ABS), hydraulic circuits, parking brake
Steering:
Power steering system, steering gear, steering column, tie rods
Electrical System:
Battery, charging system, starter motor, lighting, power windows, mirrors, seats, locks
HVAC:
Heating, Ventilation, and Air Conditioning system components, refrigerant handling, diagnostics
Body And Chassis:
Frame, body panels, doors, glass, bumpers, interior trim, corrosion protection
Safety Systems:
Airbag system, seatbelt pre-tensioners, SRS module
Exhaust System:
Exhaust manifold, catalytic converter, mufflers, pipes, oxygen sensors
Fuel System:
Fuel tank, fuel pump, fuel lines, fuel filter, injectors
Routine Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, tire rotations
Troubleshooting:
Diagnostic charts, symptom-based troubleshooting, common fault identification
Component Repair:
Step-by-step instructions for disassembling, inspecting, repairing, and reassembling virtually all vehicle components
Diagnostic Procedures:
Engine codes, DTC interpretation, electrical circuit testing, sensor testing
Specifications:
Torque values, clearances, fluid capacities, electrical resistance values
Wiring Diagrams:
Comprehensive electrical schematics for all systems
Assembly Disassembly:
Detailed procedures for removing and installing major components and sub-assemblies
Body Repair:
Procedures for dent repair, panel replacement, and welding (where applicable)
Emissions Control Service:
Service and repair of emission control devices, EVAP system, EGR system
Depth:
Comprehensive from basic maintenance to complete engine and transmission rebuilds, advanced diagnostics
Engine Code Example:
6G74 (3.5L V6), 6B31 (3.0L V6 MIVEC), 4M41 (3.2L Di-D Diesel)
Power Output Example 3.0L V6:
Approximately 220-250 HP (varies by market and specific tune)
Torque Output Example 3.0L V6:
Approximately 260-280 lb-ft (varies by market and specific tune)
Power Output Example 3.2L Di-D:
Approximately 175-200 HP
Torque Output Example 3.2L Di-D:
Approximately 330-350 lb-ft
Type Petrol:
Electronic Fuel Injection (MPI)
Type Diesel:
Common Rail Direct Injection (Di-D)
Oil Change Interval Petrol:
Typically 10,000 km or 6 months, whichever comes first (refer to manual for exact specifications)
Oil Change Interval Diesel:
Typically 15,000 km or 12 months, whichever comes first (refer to manual for exact specifications)
Air Filter Replacement:
Recommended every 20,000-40,000 km or as needed based on driving conditions
Coolant Replacement:
Typically every 40,000-80,000 km or 2-4 years
Transmission Fluid Change Auto:
Recommended every 40,000-80,000 km or as per manual, especially for heavy use
Engine Oil Petrol Example:
API SN/CF, ILSAC GF-5, SAE 0W-20 or 5W-30 (confirm per manual)
Engine Oil Diesel Example:
API CJ-4/CK-4, ACEA E9, SAE 5W-30 or 10W-30 (confirm per manual)
Coolant Type Example:
Mitsubishi DiaQueen Super Long Life Coolant (Green) or equivalent G12/G13 type
Transmission Fluid Auto Example:
DiaQueen ATF SP-III or J2 (confirm per manual for specific transmission)
Common Wear Items:
Bushings, ball joints, suspension components due to off-road use and vehicle weight
Diesel Specific Issues:
Potential for diesel particulate filter (DPF) issues if not driven appropriately (short trips)
Transfer Case Issues:
Rare instances of issues with the 4WD engagement system, requiring proper fluid maintenance
