Polaris Master 1972-1981 Workshop Service Repair Manual 1973 1974 1975 1976 1977 1978 1979 1980 Snowmobile

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

29 people are viewing this right now

Tipo: Snowmobile

Proveedor:

SKU: 88206

Etiquetas: 1972 1973 1974 1975 1976 1977 1978 1979 1980 1981 ATV Master Polaris Powersports Snowmobile

Variantes de producto

Descripción

This workshop service repair manual covers a comprehensive range of snowmobile models manufactured between 1972 and 1981. This extensive collection includes models such as Colt, Charger, Mustang, ATX, Starfire, Cobra, Gemini, Apollo, Galaxy, Cutlass, and many others, reflecting a significant presence and innovation in the snowmobile market during the 1970s. The manual details the engineering and reliability that characterized vehicles of this era, particularly highlighting advancements like the Torque-O-Matic drive system, which offered a more user-friendly automatic transmission. This manual is designed for DIY enthusiasts, owners, and professional technicians seeking to maintain, repair, or restore these classic machines. The purpose of this manual is to provide detailed, step-by-step instructions for all aspects of vehicle maintenance and repair. It covers essential systems including the engine, carburetion, fuel system, drive system, brakes, suspension, and electrical components, offering guidance from routine maintenance and tune-ups to complete component rebuilds. Troubleshooting procedures, detailed part breakdowns, and exploded views are included to aid in diagnosing and resolving issues. With potentially hundreds to over a thousand pages of information, this English-language manual is an invaluable resource for ensuring the longevity and optimal performance of your snowmobile.
