The Polaris Scrambler XP 850 HO EPS is a high-performance All-Terrain Vehicle (ATV) designed for enthusiasts seeking exceptional capability in aggressive trail riding and demanding terrain. Produced for the model years 2013, 2014, and 2015, this model variant features a High Output (HO) 850cc ProStar engine and Electronic Power Steering (EPS) for enhanced handling and reduced rider fatigue. A pioneer in the ATV market since the 1980s, the Scrambler line was engineered to emphasize sport and aggressive trail performance, making it a strong competitor in its segment. Its robust build, coupled with features like On-Demand True All-Wheel Drive and a 1,500 lb towing capacity, positions it as a reliable and versatile machine for recreational and utility use.
This comprehensive Factory Service Repair Workshop Manual provides detailed information for the complete service, repair, and troubleshooting of the Polaris Scrambler XP 850 HO EPS. Covering a vast range of systems including the powertrain, chassis, suspension, and electrical components, the manual offers step-by-step instructions, diagnostic procedures, and wiring diagrams. It is designed to empower owners, mechanics, and technicians by detailing scheduled maintenance, component replacement, and technical adjustments with clarity. With hundreds of pages of in-depth content, including detailed photos and exploded diagrams, this English-language manual ensures that users can maintain and repair their ATV with confidence and precision, ensuring its optimal performance and longevity.
Model:
Scrambler XP 850 HO EPS
Model Variant:
High Output (HO), Electronic Power Steering (EPS)
Years Covered:
2013, 2014, 2015
Vehicle Type:
All-Terrain Vehicle (ATV)
Segment:
High-performance sport/utility ATV
Target Audience:
Enthusiasts seeking capability for aggressive trail riding, recreational use, and demanding terrain.
Competitors:
Can-Am Outlander, Yamaha Grizzly, Arctic Cat TRV
Performance Focus:
Emphasis on the 850cc High Output engine and the benefits of Electronic Power Steering (EPS) for enhanced handling and reduced rider fatigue.
Value Statement:
Provides professional-level repair and maintenance information, empowering owners and independent technicians to service their ATV with confidence and precision.
Primary Coverage:
Complete Service, Repair, and Troubleshooting
Secondary Coverage:
Maintenance, Diagnostics, Component Replacement, Wiring Diagrams
Estimated Page Count:
Hundreds (specific number not provided, but described as 'very detailed' with 'hundreds of pages')
Type:
Factory Service Repair Workshop Manual
Powertrain:
Engine (850cc ProStar engine), Transmission, Drivetrain (AWD/2WD systems)
Chassis And Suspension:
Frame, Suspension (Front & Rear), Steering, Brakes
Electrical System:
Ignition, Charging System, Lighting, Instrumentation, ECU, Sensors, EPS System
Body And Accessories:
Body Panels, Racks, Seats, Controls
Maintenance:
Scheduled Maintenance, Oil Changes, Filter Replacements, Lubrication
Repair:
Engine Overhaul, Transmission Repair, Suspension Rebuild, Brake Service, Electrical Component Replacement
Troubleshooting:
Diagnostic procedures for common and uncommon issues, DTC (Diagnostic Trouble Code) interpretation
Technical Adjustments:
Valve adjustments, carburetor/throttle body synchronization (if applicable), EPS calibration
Depth:
Comprehensive (from basic maintenance to full engine and transmission rebuilds, including electrical system diagnostics and wiring diagrams)
Visual Aids:
Detailed photos, exploded diagrams, step-by-step instructions
Format Details:
PDF, universally compatible with Windows and MAC operating systems.
Print Capability:
Printable - single pages or the entire manual can be printed.
Binding:
Digital Download (PDF)
Paper Type For Printing:
Standard printer paper (user's discretion)
Licensing Terms:
Lifetime use, no expiry dates, usable on multiple devices/computers.
