2007-2009 Suzuki GSF1250 Bandit Workshop Service Repair Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

The Suzuki GSF1250 Bandit, produced for the 2007, 2008, and 2009 model years, represents the third generation of a motorcycle line celebrated for its blend of power, comfort, and value....

17 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 145147

Etiquetas: 2007 2008 2009 GSF Bandit Series GSF1250 Bandit Motorcycle Motorcycles Suzuki

Variantes de producto

Descripción

The Suzuki GSF1250 Bandit, produced for the 2007, 2008, and 2009 model years, represents the third generation of a motorcycle line celebrated for its blend of power, comfort, and value. Featuring a robust liquid-cooled, DOHC, inline-four-cylinder engine with a displacement of 1257 cc, the Bandit is known for its strong mid-range torque and linear power delivery, making it an excellent choice for riders seeking a versatile machine for commuting, sport touring, or general riding. Its durable steel frame and comfortable ergonomics, combined with capable suspension, contribute to its reputation as a reliable and adaptable motorcycle within its segment. This workshop service repair manual provides comprehensive information for the Suzuki GSF1250 Bandit (chassis code WVC7) from 2007-2009. It covers all essential aspects of maintenance, diagnosis, and repair, including detailed procedures for the engine, fuel system, ignition, cooling, transmission, drivetrain, suspension, brakes, wheels, tires, and electrical systems. The manual also includes routine maintenance tasks, troubleshooting guides, disassembly and assembly instructions, wiring schematics, and technical specifications such as torque values and fluid capacities. This resource is designed to assist both DIY enthusiasts and professional mechanics in keeping the vehicle in optimal condition.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

GSF1250 Bandit

Model Years Covered:

2007, 2008, 2009

Generation

Generation:

Third Generation (2007-2016)

Codes

Chassis Codes:

👋 Introduction

Market Position

Motorcycle Segment:

Naked/Standard Motorcycle, Sport Touring (depending on configuration).

Target Audience:

Riders seeking a powerful, versatile, and reliable large-displacement motorcycle for commuting, touring, and general riding.

Competitive Analysis

Key Competitors:

Yamaha FZ1, Kawasaki Z1000, Honda CB1000R (early models), BMW R1200R.

Key Features

Engine Type:

Liquid-cooled, DOHC, inline-four-cylinder engine.

Power Delivery:

Known for strong mid-range torque and linear power delivery, making it ideal for relaxed touring and spirited riding.

Chassis Design:

Durable steel frame, comfortable ergonomics, and capable suspension for its class.

Versatility:

Adaptable for various riding styles with the addition of accessories for touring or sportier configurations.

📋 Manual Details

Coverage Areas

Coverage Overview:

Complete service and repair information for the 2007-2009 Suzuki GSF1250 Bandit.

Page Count

Estimated Page Count:

Comprehensive (exact count not provided, but described as 'complete').

Manual Type

Manual Type:

Workshop Service Repair Manual

Language

Language:

English

Format

File Format:

Delivery Method:

Instant Download

Specifications

Printability:

Fully Printable

Zoom Capability:

Yes (Zoom IN/OUT)

Requirements

Software Requirements:

Adobe PDF Reader, WinZip

Operating System Compatibility:

All Versions of Windows & Mac

📖 Manual Coverage

Systems Covered

Engine:

Complete engine overhaul, disassembly, assembly, tuning, diagnostics.

Fuel System:

Fuel injection system, fuel pump, injectors, throttle body, fuel tank, lines, and controls.

Ignition System:

Ignition coils, spark plugs, ECU control, wiring.

Cooling System:

Radiator, hoses, thermostat, water pump, fan operation.

Transmission:

Gearbox inspection, disassembly, assembly, clutch operation, and maintenance.

Drivetrain:

Final drive assembly, chain and sprockets, bearing maintenance.

Suspension:

Front fork service, rear shock absorber maintenance, linkage lubrication.

Brakes:

Front and rear brake system inspection, servicing, hydraulic components, rotor and pad replacement.

Wheels And Tires:

Wheel bearing maintenance, tire pressure, mounting, and balancing.

Electrical System:

Wiring diagrams, battery, charging system, starter motor, lighting, instrumentation.

Emissions Control:

Components related to emissions standards (if applicable for the model year).

Frame And Bodywork:

Frame inspection, fairing removal and installation, seat, fuel tank, and body panel repairs.

Procedures Included

Routine Maintenance:

Oil changes, filter replacements, chain lubrication, brake adjustments, fluid level checks.

Troubleshooting:

Diagnostic procedures for common and uncommon issues, symptom-based troubleshooting guides.

Repair Procedures:

Step-by-step instructions for component removal, overhaul, and reinstallation.

Disassembly Assembly:

Detailed breakdown and reassembly of major motorcycle components.

Wiring Schematics:

Comprehensive electrical system diagrams for accurate diagnosis and repair.

Specifications:

Torque values, clearances, fluid capacities, electrical data, and performance metrics.

Technical Depth

Depth Of Coverage:

Highly detailed, covering everything from basic maintenance to complex engine and electrical repairs.

User Base:

Suitable for both DIY enthusiasts and experienced professional mechanics.

📊 Manual Specifications

File Format

File Type:

PDF (Portable Document Format)

Print Quality

Print Resolution:

High resolution, suitable for clear printing of diagrams and text.

Binding Type

Binding Type:

Not Applicable (Digital Format)

Paper Type

Paper Type:

Not Applicable (Digital Format)

⚙️ Engine Specifications

Primary Engine

Engine Code:

G506 (based on GSX-R1000 architecture)

Displacement:

1257 cc (76.7 cubic inches)

Bore X Stroke:

81.0 mm x 63.0 mm

Compression Ratio:

12.5:1

Valve Train:

DOHC, 4 valves per cylinder

Performance

Horsepower:

Approx. 118-123 hp @ 8,800 rpm (claimed, rear wheel power may vary).

Torque:

Approx. 110-115 Nm (81-85 lb-ft) @ 6,500 rpm (claimed).

Fuel System

Fuel Delivery:

Electronic Fuel Injection (EFI) with dual injectors per cylinder.

Fuel Tank Capacity:

19 Liters (5.0 US gal)

Fuel Type:

Unleaded gasoline, 95 RON (or equivalent Octane rating).

Cooling System

Cooling Medium:

Water-cooled

🔧 Transmission

Standard

Transmission Type:

6-speed constant mesh

Clutch Type:

Wet, multi-plate

Features

Final Drive:

O-ring sealed chain

Transmission Fluid Type:

API GL-4, SAE 80W-90 hypoid gear oil (for final drive).

📐 Dimensions

Exterior

Overall Length:

2,130 mm (83.9 in)

Overall Width:

760 mm (30.0 in)

Overall Height:

1,075 mm (42.3 in)

Wheelbase:

1,515 mm (59.6 in)

Weights

Dry Weight:

Approx. 215 kg (474 lbs)

Curb Weight:

Approx. 225-230 kg (496-507 lbs) (depending on ABS/fairing options).

Seat Height:

800 mm (31.5 in)

🛡️ Safety Features

Ratings

Safety Certification:

Compliant with relevant national and international motorcycle safety standards for its production era.

Active Features

Braking System:

Optional ABS (Anti-lock Braking System) available on some models. Powerful dual disc front brakes, single disc rear.

Passive Features

Lighting:

Halogen headlight, LED taillight.

💡 Technology Features

Infotainment

Instrument Cluster:

Digital speedometer, analog tachometer, gear position indicator, fuel gauge, clock, trip meters, warning lights.

Driver Assistance

ABS Availability:

Optional on select models for the 2007-2009 GSF1250 Bandit.

Connectivity

Charging Port:

No factory-integrated USB or 12V power outlet; typically an aftermarket addition.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Recommended every 6,000 km (3,700 miles) or annually, whichever comes first.

Major Service Interval:

Initial inspection at 1,000 km (600 miles), followed by major services typically every 12,000 km (7,500 miles) for valve clearance checks and detailed inspections.

Fluid Specifications

Engine Oil Type:

Suzuki recommends SAE 10W-40 API SG or SH, JASO MA certified oil.

Engine Oil Capacity:

3.4 Liters (3.6 US qt) without filter change; 3.6 Liters (3.8 US qt) with filter change.

Coolant Type:

Suzuki Super Long Life Coolant or equivalent ethylene glycol-based antifreeze with demineralized water (50:50 mix).

Known Issues

Common Wear Items:

Clutch plates (depending on riding style), chain and sprockets, brake pads, fork seals.

Potential Concerns:

Some owners report minor electrical connector issues over time; regular inspection is advised. Stator and regulator/rectifier can be potential failure points on some older bikes, though not specific to this model year exclusively.

Maintenance Schedule Data

Spark Plug Replacement:

NGK CR9E or equivalent, typically replaced every 12,000 km (7,500 miles).

Air Filter Cleaning Replacement:

Clean at 6,000 km (3,700 miles), replace as needed based on condition. Recommended replacement at 18,000 km (11,000 miles).

📚 Vehicle History

Brand Heritage

Suzuki Motorcycles:

Suzuki has a long-standing reputation for producing reliable and performance-oriented motorcycles across various segments.

Model Evolution

Bandit Series:

The Bandit series, known for its blend of power, comfort, and value, has evolved significantly since its inception. The GSF1250 represents a major refinement with a larger engine and modern features.

Production

Manufacturing Location:

Japan (primarily Hamamatsu)

Production Period:

2007-2009 for this specific generation/engine configuration.

🏆 Awards & Recognition

Recognitions

Awards And Reviews:

While not tied to specific awards, the GSF1250 Bandit series consistently received positive reviews for its value proposition, comfortable ergonomics, and torquey engine, often praised as an excellent all-arounder for its price point.
