Suzuki LTA700 King Quad 2005 2006 2007 2008 Service Manual

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

This manual covers the LTA700 King Quad, produced for the model years 2005 through 2008. As the flagship ATV of its generation, the LTA700 King Quad was engineered as a...

24 people are viewing this right now

Tipo: Atv

Proveedor:

SKU: 87886

Etiquetas: 2005 2006 2007 2008 Atv LTA700 King Quad Misc Motorcycles Suzuki

Variantes de producto

Descripción

This manual covers the LTA700 King Quad, produced for the model years 2005 through 2008. As the flagship ATV of its generation, the LTA700 King Quad was engineered as a high-performance utility and recreational machine, competing with leading models from other manufacturers. It features a robust 720cc liquid-cooled, single-cylinder engine with electronic fuel injection, an automatic CVT transmission with engine braking, and a selectable 4WD system with a locking front differential. The independent front and rear suspension, coupled with powerful hydraulic disc brakes, ensures capable performance across various terrains. This comprehensive service and repair manual provides detailed information essential for the maintenance and repair of your LTA700 King Quad. It includes step-by-step instructions, diagnostic procedures, and technical specifications for all major systems, including the engine, fuel system, cooling system, transmission, drivetrain, suspension, steering, brakes, and electrical system. Whether performing routine scheduled maintenance, troubleshooting common issues, or undertaking major component overhauls, this manual offers the in-depth guidance needed to keep your ATV operating at its best.

🏷️ Basic Information

Identification

Make:

Suzuki

Model:

LTA700 King Quad

Model Years Covered:

2005, 2006, 2007, 2008

👋 Introduction

Market Position

Positioning:

The LTA700 King Quad was Suzuki's flagship ATV for its generation, positioned as a high-performance utility and recreational machine.

Competitive Analysis

Competitors:

Competed with models such as the Honda FourTrax Foreman/Rancher, Yamaha Grizzly, Polaris Sportsman, and Kawasaki Brute Force.

Key Features

Engine Type:

720cc, liquid-cooled, SOHC, 4-valve, single-cylinder engine

Transmission Type:

Automatic (CVT) with engine braking

Drive System:

Selectable 4WD with locking front differential and shaft drive

Suspension:

Independent front and rear suspension with adjustable shocks

Braking System:

Dual front hydraulic disc brakes, sealed rear hydraulic disc brake

📋 Manual Details

Coverage Areas

Manual Type:

Service Manual / Repair Manual

Language:

English

Format:

PDF Download

📖 Manual Coverage

Systems Covered

Engine:

Complete engine overhaul, diagnostics, and repair

Fuel System:

Fuel injection system, fuel pump, injectors, fuel filter replacement

Cooling System:

Radiator, fan, thermostat, coolant circulation, flushing procedures

Ignition System:

Ignition coil, spark plug specifications, timing checks

Transmission:

Automatic transmission (CVT) overhaul, maintenance, and troubleshooting

Drivetrain:

Front and rear differential, driveshafts, CV joints, U-joints

Suspension:

Front and rear suspension components, shocks, springs, bushings, alignment

Steering:

Steering column, tie rods, steering rack, power steering system (if applicable)

Brakes:

Hydraulic brake system, calipers, master cylinder, brake lines, pads, rotors, bleeding procedures

Electrical System:

Wiring diagrams, battery, starter, alternator, lighting system, fuses, relays

Charging System:

Stator, voltage regulator, battery testing and replacement

Lighting:

Headlights, taillights, brake lights, indicator lights, bulb specifications

Body And Frame:

Frame inspection, body panel removal and installation, plastics

Wheels And Tires:

Tire pressure, wheel torque specifications, tire replacement

Procedures Included

Maintenance:

Scheduled maintenance, oil changes, filter replacements, lubrication

Troubleshooting:

Diagnostic charts for common problems and their solutions

Repair:

Step-by-step instructions for component replacement and repair

Overhaul:

Detailed procedures for major component overhauls (e.g., engine, transmission)

Diagnostics:

Methods for diagnosing electrical and mechanical issues

Specifications Reference:

Torque values, clearances, fluid capacities, electrical specifications

Technical Depth

Depth:

Comprehensive and detailed, suitable for both novice and experienced mechanics

Illustrations:

Illustrated with clear step-by-step instructions

📊 Manual Specifications

File Format

Format:

Searchable:

Likely searchable text content

Printable:

Printable pages

Binding Type

Binding Type:

Digital (PDF Download)

Paper Type

Paper Type:

N/A (Digital)

⚙️ Engine Specifications

Primary Engine

Engine Type:

720cc, Liquid-Cooled, SOHC, 4-Stroke, 4-Valve Single-Cylinder

Bore X Stroke:

102.0 mm x 87.0 mm (approximately)

Compression Ratio:

8.6:1 (typical for this era/class)

Fuel Delivery:

Electronic Fuel Injection (EFI)

Performance

Horsepower:

Estimated 45-50 HP (at crankshaft, actual figures vary)

Torque:

Estimated 40-45 lb-ft (at crankshaft, actual figures vary)

Fuel System

Fuel Type:

Unleaded Gasoline

Fuel Tank Capacity:

4.5 Gallons (17 Liters)

Lubrication

Oil Type:

SAE 10W-40 API SG or higher (check manual for exact specification)

Oil Capacity:

Approximately 2.5 Quarts (2.4 Liters) with filter change (verify in manual)

🔧 Transmission

Standard

Transmission Type:

Automatic Continuously Variable Transmission (CVT)

Drive Modes:

2WD / 4WD (with Electric Front Differential Lock)

Features

Engine Braking:

Yes, inherent to CVT design

Maintenance

Transmission Fluid Type:

Suzuki recommends specific CVT fluid or equivalent (refer to manual for part numbers/specs)

Transmission Fluid Capacity:

Approximately 0.8 Quarts (0.75 Liters) (verify in manual)

📐 Dimensions

Exterior

Overall Length:

86.0 inches (2185 mm)

Overall Width:

48.4 inches (1230 mm)

Overall Height:

49.2 inches (1250 mm)

Wheelbase:

50.2 inches (1275 mm)

Ground Clearance:

10.2 inches (260 mm)

Weights

Dry Weight:

617 lbs (280 kg)

Curb Weight:

Approximately 650 lbs (295 kg)

Cargo

Front Rack Capacity:

99 lbs (45 kg)

Rear Rack Capacity:

176 lbs (80 kg)

Towing

Towing Capacity:

1100 lbs (500 kg)

Trailer Hitch Type:

Standard 2-inch receiver (aftermarket often required)

🛡️ Safety Features

Ratings

Atv Safety Considerations:

ATVs are not toys. Always wear a helmet and appropriate safety gear. Operate responsibly.

Active Features

Braking System Type:

Dual front hydraulic discs, sealed rear hydraulic disc

Engine Braking:

Provided by CVT

Passive Features

Headlights:

Dual halogen headlights

Taillight And Brake Light:

Handlebar Protectors:

Standard

💡 Technology Features

Infotainment

Infotainment System:

N/A (Basic ATV instrumentation)

Driver Assistance

Assist Features:

Electric Power Steering (EPS) was an option on some King Quads of this generation, but not standard on all LTA700 models. Check specific trim. The manual will cover EPS system if equipped.

Connectivity

Connectivity Features:

🔧 Maintenance

Service Intervals

Engine Oil Change:

Every 1,000 miles (1600 km) or 6 months (refer to manual for precise interval and conditions)

Air Filter Inspection:

Inspect every 500 miles (800 km) or 3 months; clean/replace as needed

Spark Plug Replacement:

Check and clean at 1,000 miles (1600 km); replace as needed (refer to manual for specific plug type and gap)

Drive Belt Inspection:

Inspect at 1,000 miles (1600 km) or 6 months; replace as per wear indicators

Cvt Belt Tensioner Inspection:

Inspect as per manual recommendations

Fluid Specifications

Engine Oil:

SAE 10W-40 API SG or higher (Suzuki Motor Oil 4-stroke recommended)

Cooling Fluid:

Permanent type antifreeze coolant (50% mixture with distilled water)

Brake Fluid:

DOT 3 or DOT 4 hydraulic brake fluid

Differential Oil:

Gear Oil SAE 80W API GL-5 (Front and Rear)

Known Issues

Common Wear Items:

CVT belt wear, suspension bushings, wheel bearings, starter motor brushes.

Efi Performance:

Some models may experience minor EFI tuning issues; manual covers troubleshooting.

Radiator Fan Failure:

Fan motor failure can occur; manual details diagnosis and replacement.

📚 Vehicle History

Brand Heritage

Suzuki Atv Legacy:

Suzuki has a long-standing reputation for robust and capable ATVs, dating back to the early days of the ATV market with models like the QuadRunner.

Model Evolution

King Quad Lineage:

The LTA700 King Quad represented a significant step forward for Suzuki's large-bore ATV offerings, introducing a powerful V-twin engine (though the LTA700 has a single-cylinder engine; the LTA750 King Quad introduced the V-twin) and advanced features for its time.

Production

Production Period:

2005-2008 for the LTA700 model. It was succeeded by the LTA750 King Quad.

🏆 Awards & Recognition

Recognitions

Atv Reviews:

The LTA700 King Quad was generally well-received for its power, torque, and comfortable ride, often praised for its utility and capability in challenging terrain.
