Segment:
Maxi-scooter (125cc class), urban mobility, commuter vehicle.
Competitors:
Yamaha XMAX 125, Honda Forza 125, Kymco Downtown 125i, SYM Joymax 125i.
Vehicle Appeal:
Comfortable ergonomics, under-seat storage, fuel efficiency, ease of use in urban environments, mature styling.
Value:
Provides professional-grade repair and maintenance information, empowering owners and independent technicians to perform all necessary tasks, saving on dealership costs.
Coverage Scope:
Complete factory service, repair, and troubleshooting procedures.
Estimated Page Count:
Hundreds of pages (exact number not specified in product information, but described as 'very detailed').
Type:
Factory Service Manual / Workshop Manual
Language:
English (implied by typical industry standards and product description)
Format:
Digital Download (PDF compatible with computer, tablet, smartphone)
Engine And Powertrain:
Engine overhaul, diagnostics, tuning, lubrication, cooling system, fuel system, exhaust system.
Transmission And Drivetrain:
Automatic transmission (CVT) service, clutch operation, belt drive maintenance, final drive.
Chassis And Suspension:
Front fork and suspension maintenance, rear shock absorber service, steering system, wheel bearing service.
Brakes:
Brake system diagnostics, hydraulic system service, caliper maintenance, brake fluid replacement, disc and pad replacement.
Electrical And Ignition:
Wiring diagrams, battery maintenance, charging system (stator, regulator/rectifier), ignition system troubleshooting, lighting, starter motor, electrical component testing.
Body And Frame:
Body panel removal and installation, fairing components, seat assembly, luggage storage, chassis integrity checks.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, spark plug service, coolant checks, brake fluid flushes, drive belt inspection/replacement.
Troubleshooting:
Systematic diagnostic procedures for common and complex issues, fault finding charts, electrical diagnostics.
Repair And Rebuild:
Step-by-step instructions for component disassembly, repair, and reassembly, including engine internals, transmission, suspension components.
Depth:
Comprehensive: Covers basic servicing to full engine and transmission rebuilds. Includes detailed diagrams and exploded views for precise component identification and assembly.
Engine Type:
4-stroke, SOHC, 2-valve, Single Cylinder, Liquid-Cooled
Displacement:
124 cc (Cubic Centimeters)
Bore X Stroke:
Approx. 52.0 mm x 57.4 mm (Typical for this engine family)
Compression Ratio:
Approx. 11.3:1 (Typical for this engine family)
Horsepower:
Approx. 8.5 kW (11.4 HP) @ 9,000 rpm (Values may vary by market and specific model year)
Torque:
Approx. 10 Nm (7.4 lb-ft) @ 7,000 rpm (Values may vary by market and specific model year)
Fuel Delivery:
Fuel Injection (Suzuki's SCeS - Suzuki Combi-Injector System)
Fuel Type:
Unleaded Gasoline (91 Octane or higher recommended)
Ignition Type:
Electronic Ignition (CDI or Digital)
Cooling Method:
Liquid-cooled
Oil Type:
API SG, SH, SJ or higher, SAE 10W-40 (Consult manual for exact Suzuki specifications)
Oil Capacity:
Approx. 1.4 Liters (with filter change) (Consult manual for exact specifications)
Transmission Type:
Automatic (CVT - Continuously Variable Transmission)
Drive System:
V-belt drive, Automatic centrifugal clutch
Clutch Type:
Dry, centrifugal, automatic
Length:
Approx. 2,005 mm (78.9 in)
Width:
Approx. 745 mm (29.3 in)
Height:
Approx. 1,355 mm (53.3 in)
Wheelbase:
Approx. 1,425 mm (56.1 in)
Dry Weight:
Approx. 150 kg (331 lbs)
Wet Weight:
Approx. 157 kg (346 lbs) (curb weight)
Fuel Tank Capacity:
Approx. 11 Liters (2.9 US gal)
Seat Height:
Approx. 755 mm (29.7 in)
Crash Safety:
Not applicable for motorcycles/scooters in standard automotive crash ratings.
Braking System:
Disc brakes front and rear. Some models may feature ABS (Anti-lock Braking System) as an optional or standard feature.
Lighting:
Halogen headlight, LED taillight and turn signals (depending on year/trim).
Visibility:
Large fairing for wind protection, integrated mirrors.
Dashboard:
Analog/digital combination display, often including speedometer, tachometer, fuel gauge, odometer, trip meter, clock.
ABS:
Available on some models, refer to specific year/trim. ABS enhances braking safety.
Storage:
Under-seat storage compartment capable of fitting a full-face helmet and other items.
Lighting System:
Often features dual headlights and LED taillights for improved visibility.
Engine Oil Change:
Every 3,000 km or 6 months, whichever comes first (typical guideline, refer to manual for exact specification).
Air Filter Cleaning:
Every 3,000 km or 6 months, cleaning; replacement as needed (typical guideline).
Spark Plug Inspection:
Every 6,000 km or 12 months (typical guideline).
Drive Belt Inspection:
Every 6,000 km or 12 months for inspection, replacement based on wear and condition (typical guideline).
Coolant Replacement:
Every 2 years or 24,000 km (typical guideline).
Coolant Type:
Ethylene glycol-based coolant (50% mixture with distilled water recommended).
Common Wear Items:
Drive belt wear, worn brake pads, spark plug fouling, potential for carburetor issues on older non-FI models (though UH125 is FI).
Electrical Notes:
Regulator/rectifier failure can occur on various scooters, leading to battery charging issues. Check wiring harness integrity.
Manufacturer:
Suzuki Motor Corporation, Japan.
Launch Year:
First generation Burgman 125 (AN125) introduced in 1998. The UH125 designation is associated with later generations. Specific year of the UH125 covered by this manual is not specified, but it likely covers models from the mid-2000s onwards up to recent years depending on the source.
Key Innovations:
The Burgman line is known for its comfortable, car-like ergonomics and ample storage, blurring the lines between scooter and motorcycle.
