This manual covers the Fazer 1000, also known as the FZ1 Fazer, from its first generation (RJ02) produced between 1998 and 2005. This motorcycle is a versatile sport-touring and naked...

29 people are viewing this right now

Tipo: Motorcycle

Proveedor:

Yamaha

SKU: 133180

Etiquetas: Fazer Fazer 1000 Motorcycle Motorcycles Yamaha

Variantes de producto

Descripción

This manual covers the Fazer 1000, also known as the FZ1 Fazer, from its first generation (RJ02) produced between 1998 and 2005. This motorcycle is a versatile sport-touring and naked sportbike, combining the potent performance of an R1-derived engine with comfortable ergonomics. Engineered with a liquid-cooled, 4-stroke, DOHC, 5-valve per cylinder inline-four engine displacing 998 cc, it delivers approximately 135-140 PS. Its robust aluminum die-cast twin-spar frame provides rigidity, while the braking system features dual 298mm front discs and a single 267mm rear disc, with optional ABS available on select models. The Fazer 1000 is recognized for its blend of power and usability, making it a capable machine for both spirited riding and longer journeys. This comprehensive parts catalogue is designed to assist owners, mechanics, and technicians in identifying and sourcing the correct components for the Fazer 1000 (RJ02). It provides detailed exploded views and part numbers for all major assemblies, covering critical systems such as the engine, fuel system, transmission, suspension, braking, electrical components, and bodywork. While not a step-by-step repair guide, this manual is invaluable for part identification, ensuring accuracy in maintenance and restoration projects. Its digital format allows for easy searching and printing of specific sections, empowering users to maintain their vehicle efficiently and effectively.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

Fazer 1000

Model Alias:

FZ1 Fazer

Generation

Generation Designation:

First Generation (RJ02)

Production Years Generation:

1998-2005

Codes

Chassis Code:

RJ02

Engine Code Prefix:

5LV

👋 Introduction

Market Position

Motorcycle Segment:

Sport Touring / Naked Sportbike

Target Audience:

Owners seeking to maintain, repair, or restore their Yamaha Fazer 1000, independent workshops, and mechanics.

Competitive Analysis

Key Competitors:

Suzuki Bandit 1200/1250, Honda CB1000R/CB1300, Kawasaki ZRX1200R, Triumph Speed Triple.

Key Features

Manual Benefit 1:

Model-specific accuracy, ensuring correct parts are ordered.

Manual Benefit 2:

Empowers owners to understand their machine and avoid overpriced or incorrect parts/repairs.

Manual Benefit 3:

Instant download convenience and flexibility to print only necessary sections.

📋 Manual Details

Coverage Areas

Languages:

English (assumed, typical for international parts catalogues)

Region Applicability:

Global (specific market variants may exist, but catalogue often covers all)

Page Count

Estimated Page Count:

300-500 (typical for comprehensive parts catalogues)

Manual Type

Manual Type:

Parts Catalogue / Parts List

Format

Delivery Format:

Digital Download (PDF)

📖 Manual Coverage

Systems Covered

Engine Components:

Cylinder block, cylinder head, crankshaft, pistons, connecting rods, valves, camshafts, timing chain, oil pump, water pump, lubrication system, cooling system.

Fuel System:

Fuel tank, fuel pump, fuel filter, fuel injectors, throttle body, fuel lines, fuel pressure regulator.

Transmission Drivetrain:

Gearbox internals (gears, shafts, bearings), clutch assembly, primary drive, final drive (chain, sprockets).

Suspension Steering:

Front forks (inner/outer tubes, springs, damping components), rear shock absorber, swingarm, linkages, steering head bearings, handlebars, triple clamps.

Braking System:

Front and rear brake calipers, master cylinders, brake lines, brake discs, brake pads, brake levers, brake pedals.

Electrical System:

Ignition system (CDI, coils, spark plugs), starting system (starter motor, solenoid, battery), charging system (alternator, regulator/rectifier), lighting (headlights, taillights, indicators), wiring harness, sensors, ECU.

Bodywork Frame:

Frame components, subframe, fairings, fuel tank, seat, fenders, exhaust system, footpegs, luggage rack provisions.

Wheels Tires:

Front and rear wheels, wheel bearings, wheel spacers, valve stems, tire specifications (though not typically part numbers for tires).

Procedures Included

Part Identification:

Detailed exploded views of all major assemblies with corresponding part numbers and quantities.

Assembly Disassembly Order:

Implied through the logical sequencing of exploded diagrams, crucial for correct reassembly.

Component Listing:

Comprehensive list of all replaceable parts, including fasteners, seals, gaskets, and internal components.

Technical Depth

Diagnostic Support:

Primarily focused on part identification for replacement, not in-depth troubleshooting or diagnostic procedures. However, it aids diagnostics by clearly showing component relationships.

Repair Guidance:

Supports repair by providing the correct parts and illustrating their placement. Detailed repair steps are typically found in a separate service manual.

Restoration Support:

Extremely valuable for restoration projects, ensuring all original parts are identified and sourced correctly.

📊 Manual Specifications

File Format

File Format:

PDF (Portable Document Format)

Searchability:

Likely text-searchable if created from digital sources, aiding quick part number retrieval.

Print Quality

Printability:

High-resolution graphics and diagrams suitable for printing specific pages as needed.

Binding Type

Binding Type:

N/A (Digital Download)

Paper Type

Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, 4-stroke, DOHC, 5-valve per cylinder, inline-four

Displacement:

998 cc

Bore X Stroke:

74.0 mm x 58.0 mm

Compression Ratio:

11.5:1

Performance

Horsepower Crank:

Approx. 135-140 PS (99-103 kW) @ 9,000 rpm (depending on market/version)

Torque Crank:

Approx. 102 Nm (75 lb-ft) @ 7,500 rpm (depending on market/version)

Fuel System

Fuel Delivery:

Fuel Injection (Mikuni or similar, typically 40mm throttle bodies)

Fuel Type:

Unleaded gasoline, minimum 95 RON

Ignition System:

TCI (Transistor Controlled Ignition) with electronic advance

🔧 Transmission

Standard

Transmission Type:

6-speed constant mesh

Clutch Type:

Wet, multi-plate, diaphragm spring

Final Drive:

O-ring sealed chain

Features

Gear Ratios:

Specific ratios available in detailed service manuals, but catalogue confirms component interchangeability.

📐 Dimensions

Exterior

Overall Length:

Approx. 2130 mm (83.9 in)

Overall Width:

Approx. 750 mm (29.5 in)

Overall Height:

Approx. 1190 mm (46.9 in)

Wheelbase:

Approx. 1440 mm (56.7 in)

Ground Clearance:

Approx. 135 mm (5.3 in)

Weights

Dry Weight:

Approx. 194 kg (428 lbs)

Wet Weight:

Approx. 213 kg (470 lbs) (with fluids)

🛡️ Safety Features

Ratings

Safety Certification:

Meets relevant national/regional motorcycle safety standards (e.g., Euro standards, DOT equivalents).

Active Features

Braking System:

Dual 298mm front discs with 4-piston calipers, Single 267mm rear disc with 2-piston caliper. Optional ABS available on some models.

Lighting:

Halogen headlight, LED taillight and brake light, standard turn signals.

Passive Features

Frame Construction:

Aluminum die-cast twin-spar frame for rigidity and weight reduction.

💡 Technology Features

Infotainment

Instrument Cluster:

Analog tachometer, digital speedometer, odometer, trip meters, fuel gauge, coolant temperature gauge, clock. Often includes warning lights for various systems.

Driver Assistance

ABS Availability:

Optional ABS on certain model years and regions.

Connectivity

Connectivity Features:

No integrated smartphone connectivity or advanced electronic rider aids beyond optional ABS.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 5,000-10,000 km (3,000-6,000 miles) or annually, whichever comes first (refer to specific model service manual for precise intervals).

Spark Plug Replacement:

Typically every 10,000-20,000 km (6,000-12,000 miles).

Chain Maintenance:

Clean and lubricate every 1,000 km (600 miles) or after riding in wet conditions. Adjust tension as needed.

Fluid Specifications

Engine Oil Type:

Yamalube 10W-40 or equivalent API SG, JASO MA certified (e.g., Motul 5100 10W-40).

Engine Oil Capacity:

Approx. 3.4 liters (3.6 US qt) without filter change, 3.8 liters (4.0 US qt) with filter change.

Coolant Type:

Ethylene glycol based, 50% mixture with demineralized water (e.g., Yamacool). Do not use methanol or alcohol-based coolants.

Brake Fluid Type:

DOT 4

Clutch Fluid Type:

DOT 4 (Hydraulic clutch)

Known Issues

Common Issue 1:

Stalling at idle/low RPM (often related to TPS adjustment, idle screw, or throttle body synchronization on early models).

Common Issue 2:

Cam chain rattle (can be normal on some models, but excessive noise may indicate tensioner wear).

Common Issue 3:

Wiring harness issues (corrosion or abrasion, particularly around the steering head or under the seat).

Common Issue 4:

Rear shock absorber wear (leaking or loss of damping over time, especially on higher mileage units).

📚 Vehicle History

Brand Heritage

Yamaha Motorcycles:

Yamaha Motor Company, established in 1955, has a long-standing reputation for producing high-performance, innovative motorcycles across various genres.

Model Evolution

Fazer Lineage:

The Fazer name has been used by Yamaha for faired sport-touring versions of their naked bikes. The Fazer 1000 (FZ1 Fazer) evolved from earlier 600cc models and shared its engine with the R1 superbike of its era, providing potent performance in a more comfortable package.

Production

Manufacturing Location:

Primarily Japan (Iwata)

🏆 Awards & Recognition

Recognitions

Awards And Ratings:

While specific major awards for the Fazer 1000 (RJ02) are not widely publicized, it was generally well-regarded for its blend of R1-derived power, comfortable ergonomics, and versatility, earning it a strong following in the sport-touring segment.
