Yamaha FZS1000N FAZER Digital Workshop Repair Manual 2001-2002

Precio habitual: $16.99
Precio de venta: $16.99
Precio habitual
Precio unitario: por

19 people are viewing this right now

Tipo: Motorcycle

Proveedor:

SKU: 134800

Etiquetas: 2001 2002 Fazer FZS1000N FAZER Motorcycle Motorcycles Yamaha

Variantes de producto

Descripción

Welcome to the comprehensive guide for the Yamaha FZS1000N FAZER, a sport-touring motorcycle produced between 2001 and 2002. This versatile machine is engineered to blend the exhilarating performance derived from its R1-based engine with the comfort and practicality required for long-distance journeys. Known for its robust inline-four engine, capable of delivering approximately 130-140 PS, and a stable aluminum twin-spar frame, the FZS1000N FAZER offers a compelling package for riders seeking a powerful yet comfortable riding experience. Its design philosophy emphasizes a harmonious combination of supersport DNA and touring prowess, making it a standout choice in its segment. This digital workshop repair manual provides exhaustive coverage for all systems and components specific to the Yamaha FZS1000N FAZER models from 2001-2002. It details essential maintenance procedures, including oil changes, filter replacements, and valve clearance checks, alongside in-depth troubleshooting guides and step-by-step repair instructions for the engine, fuel system, transmission, brakes, suspension, and electrical systems. Furthermore, the manual includes critical technical specifications, wiring diagrams, and information on special tools required for accurate diagnostics and repairs. This resource is designed to empower owners and technicians alike to maintain, service, and restore the FZS1000N FAZER, ensuring its optimal performance and longevity.

🏷️ Basic Information

Identification

Make:

Yamaha

Model:

FZS1000N FAZER

Year:

2001-2002

Engine Variant:

FZS1000N

Codes

Chassis Code:

👋 Introduction

Market Position

Motorcycle Segment:

Sport-touring motorcycle.

Target Audience:

Riders seeking a versatile, powerful, and comfortable motorcycle for both commuting and long-distance touring.

Competitive Analysis

Competitors 2001:

Suzuki Bandit GSF1200, Honda CB1000R (earlier versions), Kawasaki ZRX1100/1200.

Key Features

Engine Basis:

Derived from the acclaimed Yamaha R1 supersport engine, tuned for broader power delivery.

Design Philosophy:

Combination of supersport performance with touring comfort and practicality.

Manual Value Proposition:

Enables owners to perform detailed maintenance and repairs, saving costs and extending the lifespan of a capable motorcycle.

📋 Manual Details

Coverage Areas

Primary Coverage:

Comprehensive mechanical and electrical repair, maintenance, troubleshooting, and restoration.

Scope:

All systems and components specific to the FZS1000N FAZER for the 2001-2002 model years.

Page Count

Estimated Page Count:

Likely 400-600 pages (typical for a comprehensive workshop manual of this era).

Manual Type

Type:

Digital Workshop Repair Manual

Language

Language:

English

Format

Format:

Digital (likely PDF)

📖 Manual Coverage

Systems Covered

Engine:

Complete disassembly, assembly, inspection, and repair of the 1000cc inline-four engine, including valve timing, cooling system, lubrication system, and ignition system.

Fuel System:

Carburetor (likely Mikuni BST40) tuning, cleaning, overhaul, fuel pump, fuel lines, and fuel tank.

Transmission:

Clutch operation, gearbox disassembly, inspection, repair, and lubrication.

Drivetrain:

Chain and sprocket inspection, replacement, and maintenance; rear wheel hub and bearings.

Brakes:

Front and rear brake system inspection, caliper overhaul, master cylinder service, brake fluid replacement, and hydraulic line maintenance.

Suspension:

Front fork disassembly, oil change, seal replacement, spring inspection; rear shock absorber inspection and adjustment.

Electrical System:

Wiring diagrams, charging system (alternator, regulator/rectifier), starting system (starter motor, solenoid), lighting, instrumentation, and ignition system troubleshooting.

Cooling System:

Radiator, cooling fan, water pump, thermostat, hoses, and coolant specifications.

Exhaust System:

Exhaust manifold, mufflers, and heat shields inspection and service.

Chassis And Bodywork:

Frame inspection, fairing removal and installation, seat, fuel tank, and controls.

Procedures Included

Maintenance:

Regular servicing, oil changes, filter replacements, chain adjustment, brake bleeding, and general inspections.

Troubleshooting:

Detailed diagnostic charts and procedures for identifying and resolving common and uncommon issues across all systems.

Repair:

Step-by-step instructions for component disassembly, repair, reassembly, and adjustment.

Rebuilding:

Complete engine, transmission, and carburetor overhaul procedures.

Installation:

Guidance for fitting aftermarket accessories or replacement parts where applicable.

Technical Depth

Depth:

Expert-level, covering complete engine rebuilds, complex electrical diagnostics, and detailed component-level repair.

Diagnostic Tools:

References to required special tools and diagnostic equipment for accurate repairs.

📊 Manual Specifications

File Format

Format Type:

Searchability:

Text-searchable (assuming standard PDF creation).

Print Quality

Printability:

Printable on standard office printers for physical reference.

Binding Type

Digital Binding:

N/A (Digital format)

Paper Type

Digital Paper Simulation:

N/A (Digital format)

⚙️ Engine Specifications

Primary Engine

Engine Type:

Liquid-cooled, 4-stroke, DOHC, 5 valves per cylinder, inline-four.

Displacement:

998 cc (cc)

Bore X Stroke:

74.0 mm x 58.0 mm

Compression Ratio:

11.1:1

Performance

Horsepower:

Approx. 130-140 PS (96-103 kW) at 10,000 rpm (manufacturer-claimed).

Torque:

Approx. 95-100 Nm (70-74 lb-ft) at 7,500 rpm (manufacturer-claimed).

Fuel System

Carburetion:

Four 37mm Mikuni BST40 carburetors with CV (Constant Velocity) mechanism.

Fuel Tank Capacity:

21 Liters (5.5 US gallons)

Ignition

Ignition System:

TCBI (Transistor Controlled Ignition) with electronic advance.

Lubrication

Lubrication Type:

Wet sump.

Cooling System

Cooling Medium:

Liquid (Ethylene Glycol/Water mixture).

🔧 Transmission

Standard

Transmission Type:

6-speed, constant mesh.

Clutch Type:

Wet, multiple disc clutch.

Features

Gear Ratios:

Specific ratios provided within the manual for each gear.

Final Drive:

Enclosed O-ring sealed chain.

Transmission Oil Type:

Yamalube 4 (or equivalent SAE 10W-40, API SE, SF, SG, SH, SJ, SL type motor oil).

📐 Dimensions

Exterior

Length:

2,150 mm (84.6 in)

Width:

770 mm (30.3 in)

Height:

1,215 mm (47.8 in)

Wheelbase:

1,455 mm (57.3 in)

Weights

Dry Weight:

210 kg (463 lbs)

Wet Weight:

Approx. 233 kg (514 lbs) (with all fluids).

Load Capacity:

Refer to manual for specific rider and luggage limits.

🛡️ Safety Features

Ratings

Crash Test Data:

N/A (Motorcycles are not typically subjected to the same crash testing as cars).

Active Features

Braking System:

Dual 298mm hydraulic disc front brakes with 4-piston calipers; Single 267mm hydraulic disc rear brake with 2-piston caliper.

Lighting:

Halogen headlamp, LED taillight.

Passive Features

Frame Construction:

Aluminum die-cast twin-spar frame for rigidity and lightweight.

Handling Stability:

Designed for stable handling and feedback during spirited riding and touring.

💡 Technology Features

Infotainment

Instrument Cluster:

Analog tachometer, digital speedometer, odometer, trip meter, fuel gauge, clock, and various indicator lights.

Driver Assistance

Anti-lock Braking System (ABS) was an optional feature on some models, not standard.

Connectivity

Connectivity Features:

None (This era of motorcycle did not feature advanced digital connectivity).

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 5,000-6,000 km (3,000-4,000 miles) or annually, whichever comes first.

Spark Plug Replacement:

Refer to manual for specific mileage, typically around 20,000-30,000 km.

Valve Clearance Check:

Every 20,000-30,000 km (critical for engine health).

Fluid Specifications

Engine Oil Spec:

Yamalube 4 (or equivalent SAE 10W-40, API SE, SF, SG, SH, SJ, SL type motor oil).

Engine Oil Capacity:

3.4 L (3.6 US qt) without filter change; 3.7 L (3.9 US qt) with filter change.

Coolant Type:

Pre-mixed 50% ethylene glycol and 50% deionized water.

Brake Fluid Type:

DOT 4.

Known Issues

Regulator Rectifier Failure:

Common issue on many bikes of this era, potential for failure leading to battery charging problems.

Carburetor Synchronization:

Can drift over time, requiring regular synchronization for smooth running and optimal performance.

Cam Chain Tensioner:

Some units may develop a noisy cam chain tensioner over time, requiring inspection and potential replacement.

📚 Vehicle History

Brand Heritage

Yamaha Legacy:

Yamaha Motor Company has a long-standing reputation for innovation, performance, and reliability in motorcycles.

Model Evolution

Fazer Lineage:

The FZS1000 FAZER builds on the success of smaller displacement FAZER models, offering increased power and touring capability.

Production

Production Start Year:

Manufacturing Location:

Japan

🏆 Awards & Recognition

Recognitions

Industry Acclaim:

Generally well-received by motorcycle press for its blend of performance and practicality.

Ratings

Performance Reviews:

Often praised for its strong, flexible engine and comfortable riding position suitable for touring.

Certifications

Emissions Compliance:

Compliant with prevailing emissions standards for its model years.
